Specify the host name or the IP address of the XSCF during the network
■
configuration, in a web browser running on a PC with an XSCF-LAN port used to
establish a connection to the XSCF.
<Web browser screen image>
URL https://192.168.111.111/ (The IP address of XSCF is input by number)
Alternatively:
https://XSCF-host-name/ (Not the host name of a domain)
(This screen image is an example and differs from the actual screen display.)
Note – The web browser window for the XSCF Web is called the XSCF Web console.
Log in.
■
<Web browser screen image>
login:yyyy
Password:xxxxxxxx
(This screen image is an example and differs from the actual screen display.)
Note – When connecting using https, a warning message appears in the web
browser until the certificate is installed.
11. Open the XSCF Administration window.
<Web browser screen image>
XSCF Web console
- Remote Maintenance Service Administration
- Firmware Update
(This screen image is an example and differs from the actual screen display.)
The remaining setting items are the same as those applicable to setup using the
■
XSCF Web. Referring to the setup flow, proceed to
Section 2.1.1, "Setup Summary by the XSCF Shell" on page
commands used to make settings, see the corresponding parts of
"Specifying the XSCF Settings" on page
Step 9 and later steps in
2-3. For details on the
2-14.
Chapter 2 Setting Up XSCF
Section 2.2,
2-13
