Caution – IMPORTANT - If the XSB associated with the specified LSB has been
configured in the domain configuration, the information that is set for the LSB
cannot be changed. Also, if the specified domain is running, the value of
configuration policy cannot be changed. To change the value, first turn off power to
the domain.
TABLE 2-23
showboards(8) command.
XSB Status Information
TABLE 2-23
Item
XSB number
DID
LSB
assignment
(Assignment)
power
(Pwr)
connectivity
(Conn)
configuration
(Conf)
test
(Test)
2-100 SPARC Enterprise Mx000 Servers XSCF User's Guide • August 2009
lists the XSB status information. This information can be displayed by the
Explanation
XSB number.
Domain ID.
LSB number that is used for domain.
Status of pre-arranged registration in a domain
unavailable:
• XSB not yet mounted or assigned.
• XSB not yet configured.
available: ..... XSB in the system board pool state.
assigned: ..... XSB assigned to the domain.
Indicates the XSB power status.
n: ..... XSB power off state
y: ..... XSB power on state
Indicates the state of a hardware connection to a domain.
n: ..... System board pool state
The XSB has been deleted from the domain by hardware. (This includes a domain
shutdown.)
y: ..... XSB connected by hardware to the domain.
(The XSB is active in the domain or ready to be added to the Solaris OS.)
Status of a logical connection to a domain.
n: ..... Not added to the domain (Solaris OS).
y: ..... Active and added to the domain (Solaris OS).
Indicates the diagnosis status. (Note)
Unmount: ..... XSB not yet mounted or defined.
Unknown: ..... Diagnosis not yet performed.
Testing: ..... Diagnosis in progress.
Passed: ..... Diagnosis completed normally.
Failed: ..... A diagnosis error was detected and XSB continuous operation is not
possible.
