Replaceable Parts
A5635A Controller Enclosure Replaceable Parts
Table 45 Controller Enclosure Replaceable Parts
Part Number
Field Replaceable Units
A5635-60002
Windows NT
(no cache DIMMs)
Includes Windows NT NVSRAM settings
A5278-60002
128 MB DIMM
A5278-60004
16MB SIMM Module
A5277-60009
Battery Backup Module
A5277-60003
Controller Fan Module
A5277-60004
Power Supply Modules
A5277-60002
Power Supply Fan Module
A5277-60001
Front Door Assembly
5021-1121
Terminator, SCSI, 68 pin, LVD
5064-2464
Media Interface Adapter (MIA)
1
Controller modules have operating-specific firmware installed and are not interchangeable.
348-0038143
+5v Power Harness
348-0038144
+12v Power harness
348-0038145
Battery Harness
348-0038942
Power Supply & Fan Housing
348-0037572
Controller Cage/Midplane Assy.
348-0038142
Controller Enclosure (No FRUs)
Replaceable Parts
366
1
Controller Module w/32 MB SIMM
Exchange
Part #
A5635-69002
n/a
n/a
A5277-69009
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
