6.
Slide the power supply cage/ midplane assembly all the way into the chassis and install
the eight screws (four each side). See
7.
Install the controller enclosure into the rack (reverse the procedure
Enclosure" on page
Battery Harness
The controller module contains one battery harness. The battery harness
ribbon cable that provides a power connection between the Battery Backup (BBU) module
and the controller enclosure midplane. The harness also carries battery status information.
Removal and replacement of the battery harnesses is described as part of the controller
cage/ midplane assembly procedure. To replace the battery harnesses, refer to
Cage/ Midplane Assembly / Battery Harness" on page
Figure 124
Battery Harness
Internal Controller Enclosure Assemblies
354
Figure
342).
123.
355.
Battery Harness
"Controller
(Figure
124) is a
"Controller
