Controller Cage/ Midplane Assembly / Battery Harness
Inside the chassis is the controller enclosure cage/midplane assembly
(Figure
125), a
modular structure consisting of controller module slots and the controller midplane. Both
controller modules plug directly into the midplane. The midplane provides interface and
power connections between the components inside the controller cage (controller
modules, power interface board, and fans), as well as to LVD-SCSI connections to the disk
enclosures, and Fibre Channel connections to the Fibre Channel network.
Figure 125 Controller Cage/ Midplane Assembly
Internal Controller Enclosure Assemblies
355
