If disconnecting the cable is difficult, the power supply cage/ midplane assembly may
need to be loosened and moved forward
a. Remove the eight screws, four each side, from the power supply cage/ midplane
assembly (see
Figure
b. Pull the cage back a couple of inches to gain access to the power harness connectors
and disconnect the connectors from the back of the power supply/midplane cage.
4.
Install the new harnesses.
5.
Reinstall the power supply cage/ midplane assembly, if removed, by installing the eight
screws
6.
Slip the harness cover plate over the four screws in the controller rear shield and press
it down then tighten the screws.
7.
Install the controller enclosure into the rack. See
For more complete installation instructions, see
(Figure
123).
Chapter 3,
Internal Controller Enclosure Assemblies
123). To loosen power supply cage:
"Controller Enclosure" on page
Installation.
342.
351
