Installing the Disk Enclosures

Disk enclosures should be installed in the rack starting at the bottom and proceeding
upward. When all disk enclosures are installed, the controller enclosure is installed at the
top, directly above the disk enclosure. Installation instructions for the disk enclosure SC10
are provided below; installation instructions for the controller enclosure FC60 follow this
section.

Step 1: Collect Required Tools

•
Torx T25 screwdriver
•
Torx T15 screwdriver
•
Small flat-blade screwdriver

Step 2: Unpack the Product

1. Lift off the overcarton and verify the contents of the box (see
Table 16
Disk Enclosure SC10 Accessories
Figure Label Part (part number)
Disk Enclosure (with power supplies, fans, and BCC modules)
A
B Rail kit (A5251A) for System/E cabinets
C Rail kit (A5656A) for Rittal racks
D Rack filler panel, 1/2 EIA Unit, 1 ea.
E Disks or fillers (A5234A or A5235A), pack of 10
F SCSI terminators, 2 ea.
G Power cords, 2ea
H ESD strap (9300-2170), 1 ea.
I Documentation
Table 16 and Figure
Installing the Disk Enclosures
47).
