5. To replace the backplane:
a. Stand the new backplane inside the chassis and push it over the alignment pins (B in
Figure 103). Connectors automatically align with floating fan connectors inside the
chassis.
b. Insert and tighten ten screws into the backplane and chassis.
6. To replace the mezzanine:
a. Attach the new mezzanine to the backplane connector (C in
b. Insert and tighten five Torx T-10 screws through the mezzanine and into the
backplane.
7. Replace the top cover. See
8. Reseat and secure the power supplies.
9. Reseat and secure the BCCs. See
10. Re-install the disk enclosure. See
Internal Disk Enclosure Assemblies
316
"Top Cover Removal/Replacement" on page
"BCC Module Removal/Replacement" on page
"Installing the Disk Enclosure SC10" on page
Figure 102).
310.
300.
307.
