Power Supply Cage/Midplane Assembly
The power supply cage/ midplane assembly houses both the power supply modules and the
power supply fan module. These modules plug into the midplane board located at the back
of the power supply cage. The midplane board also provides connectors for the power
supply harnesses that distribute power to the controller cable midplane.
To replace the power supply cage/ midplane assembly, complete the following steps:
Figure 122
Power Supply
Electrostatic discharge can damage sensitive components. Use a grounding
C
AUTION
wrist strap or other antistatic precautions before removing or handling the
components in the controller enclosure.
1.
Remove the controller enclosure from the rack. See
2.
Remove the harness cover plate. See
Internal Controller Enclosure Assemblies
352
Cage/ Midplane
Assembly
"Harness Cover Plate" on page
"Controller Enclosure" on page
349.
342.
