Fans
Redundant, hot-swappable fans provide cooling for all enclosure components. Each fan
has two internal high-speed blowers (A in
locking screws (D).
A internal blowers
B LED
C pull tab
D locking screws
Figure 6
Fan
Internal circuitry senses blower motion and triggers a fault when the speed of either
blower falls below a critical level. If a fan failure occurs, the amber fault LED will go on.
Disk Enclosure Components
28
Figure
6), an LED (B), a pull tab (C), and two
