BCC Module Removal/Replacement

The BCC is not a hot-swappable component. The disk enclosure must be powered off when
removing or replacing the BCC. Powering down the disk enclosure will impact the
operation of any LUNs using disks in the enclosure. The loss of the disks may initiate a
rebuild for any LUN included on the disks.
When the BCC replacement is completed and the disk enclosure is powered up,
Note
the array may perform a rebuild or copy-back to the disks. depending on the
amount of data involved, this process may take some to complete.
To replace a BCC module, complete the following steps:
Do not remove a BCC until you have a replacement. An empty slot will cause
C
AUTION
uneven cooling and possible overheating.
1. Open the disk enclosure front door.
2. Power the disk enclosure down by setting the power switch to off.
3. Disconnect the SCSI cable from the controller enclosure connector.
4. Disconnect the SCSI cable from the BCC.
5. Loosen the two locking screws from the back of the BCC. See
6. Attach the ESD wrist strap to your wrist and the clip end to the ground connector
located at the top, front, left corner of the disk enclosure.
Touching the BCC pins can cause high energy discharge and permanently
C
AUTION
damage the BCC.
7. Open the cam levers by pulling them out and away from the center of the module, then
pull the BCC out of its slot. See
Disk Enclosure Modules
300
Figure 95.
