Power Interface Board
Introduction
This section describes procedures to troubleshoot the controller enclosure power interface
board. For troubleshooting procedures, refer to the
page 275
Servicing Notes
The controller enclosure's power supply assembly must be serviced by a
C
AUTION
trained service technician ONLY.
The power supply assembly has a modular design. It is a single, removable unit, that
consists of the Power Interface Board and attached sheet metal frame. If you need to
replace the Power Interface Board, you must replace the entire power supply assembly, not
just the board.
If there is an intermittent or complete power loss to the controller module, Battery Backup
Unit, or controller enclosure fan module, it might be caused by either a defective power
harness or Power Interface Board. The procedure in this section explains how to replace
the power supply assembly, which includes the Power Interface Board. It assumes that you
have already checked the power cords, checked for a failed power supply (see
Supply Module" on page
Controller Enclosure Troubleshooting
274
267), and replaced the power harnesses.
"Master Troubleshooting Table" on
"Power
