Models and Options
The HP SureStore E Disk Array FC60 consists of two products: theA5635A controller
enclosure and theA5636A SureStore E Disk System SC10, or disk enclosure. Each of these
products have their own options as indicated below.
A5635A Controller Enclosure
The A5635A controller enclosure is integrated into the disk array by qualified service -
trained personnel. The A5636A can be ordered with up to six A5636A. disk enclosures. The
A5635A includes the following components:
– Rackmount enclosure
– Two disk array controllers, each with 256 Mbytes of cache
– Two power supplies
– Two fan modules
– One battery backup unit (BBU)
– Two power cords (w/ ferrite bead)
– Mounting rail kit for HP cabinets
– Mounting rail kit for Rittal 9000 racks
– Terminators for unused SCSI ports
– Two 1/2 EIA Filler Panels
– User documentation
Models and Options
361
