HP Surestore Disk Array 12h - And FC60 Service Manual page 320

6. Align the holes in the carrier with the holes in the disk drive. When properly installed
there is about ½ inch between the inside edge of the latch and the disk drive.
7. Set the insertion guides (B) on the sides of the carrier, aligning holes in the guide with
holes in the carrier and disk drive. Nubs on the carrier fit dimples on the guides and help
to hold the guides in position on the carrier.
8. Insert and tighten two screws and washers through the guide, carrier, and drive on each
side.
When the carrier has been replaced, the disk module can be reinstalled into the disk
enclosure. See "Installing a Disk Module or Filler Module" on page
Internal Disk Enclosure Assemblies
320
293.
