Brocade Communications Systems StoreFabric SN6500B User Manual page 1320

H
Database tables and fields
TABLE 254
Field
ID
DESCRIPTION
NETWORK_ADDRESS
CIM_NAMESPACE
PORT
SSL_ENABLED
USER_ID
PASSWORD
STATUS
LAST_CONTACTED_TIME
ERROR_MESSAGE
TABLE 255
Field
ID*
NAME
TYPE
THRESHOLD_LIMIT
THRESHOLD_DURATION
DEFAULT_POLICY
B_THRESHOLD_LIMIT
B_THRESHOLD_DURATION
1272
PORT_COMMISSION_CIMOM_SERVER
Definition
Primary key for the table.
User defined description of the CIMOM Server.
IPv4 or IPv6 address or Host name of the CIMOM server. varchar
Name of the namespace where this CIM_FCPort CIM
Class is located.
Port number which CIMOM server is listening.
Protocol used for connecting CIMOM server. Default
protocol will be HTTPS. If HTTPS is not reachable fall
back to HTTP. Supported values 0 - HTTP, 1 - HTTPS
User Id to be used for authenticating CIMOM Server.
Password to be used for authenticating. Stored in
encrypted format.
Status before and after contacting the CIMOM Server.
Possible values are
0 - OK, 1- Not Contacted Yet , 2 - Credentials Updated, 3
- Credentials Failed, 4 - Not Reachable.
Last time CIMOM server contacted. This will be updated
when we test the reachablity of the CIMOM Server and
when we perform port decommission/recommission.
Detailed error message. Applicable when
communication to CIMOM Server failed.
PORT_FENCING_POLICY
Definition
Unique generated database identifier.
Name of the policy. The length of the field should be
62 because M-Model switch supports only maximum
62 characters.
•
0 = ISL Protocol
•
1 = Link
•
2 = Security
Threshold Limits for M-Model Switch.
Duration In minutes for M-Model Switch.
•
1 = the default port fencing policies.
•
0 = the non-default policies.
The default port fencing policies are:
For ISL - Default Protocol Error Policy
For Link Violation type - Default Link Level Policy
For Security - Default Security Policy
Threshold Limits for B-Model Switch (Not Supported). int
Duration in minutes for B-Model Switch (Not
Supported).
Format
int
varchar
varchar
int
int
varchar
varchar
int
timestamp
varchar
Format
int
varchar
smallint
int
int
smallint
int
Brocade Network Advisor SAN User Manual
53-1002696-01
Size
1024
64
256
128
512
2048
Size
62
