Download this manual See also: Administrator's Manual, Reference
53-1002153-02
®
15 December 2011
Fabric Watch
Administrator's Guide
Supporting Fabric OS v7.0.x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN3000B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems SN3000B

Summary of Contents for Brocade Communications Systems SN3000B

  • Page 1 53-1002153-02 ® 15 December 2011 Fabric Watch Administrator’s Guide Supporting Fabric OS v7.0.x...
  • Page 2 Copyright © 2000, 2002-2011 Brocade Communications Systems, Inc. All Rights Reserved. Brocade, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, NetIron, SAN Health, ServerIron, and TurboIron are registered trademarks, and AnyIO, Brocade Assurance, Brocade NET Health, Brocade One, CloudPlex, MLX, VCS, VDX, and When the Mission Is Critical, the Network Is Brocade are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries.
  • Page 3 Document History Title Publication Number Summary of Changes Date Fabric Watch User’s Guide 53-0001559-02 New document May 2000 Fabric Watch User’s Guide 53-0000186-02 March 2002 Fabric Watch User’s Guide 53-0000504-02 April 2003 Fabric Watch User’s Guide 53-0000524-02 April 2003 Fabric Watch User’s Guide 53-0000524-03 Updated default values and restructured December 2003...
  • Page 4 Title Publication Number Summary of Changes Date Fabric Watch Administrator’s Guide 53-1001770-01 Updates to support Fabric OS v6.4.0: March 2010 portThConfig, sysMonitor, thConfig, and portFencing commands (recommended for use in configuring class areas instead of the fwConfigure command); recommended class settings added. Fabric Watch Administrator’s Guide 53-1002153-01 Updates to support Fabric OS v7.0.0:...

  • Page 5: Table Of Contents

    Contents About This Document In this chapter ......... . . xv How this document is organized .
  • Page 6 Switch monitoring components ......5 Fabric events monitoring ....... . 5 Performance monitoring .
  • Page 7 Interfaces for activating Fabric Watch ......25 Activating Fabric Watch using a Telnet session ... . . 25 Activating Fabric Watch using SNMP .
  • Page 8 Port class areas......... . 57 Port class guidelines and default settings .
  • Page 9 Chapter 9 Fabric Watch Configuration Using Web Tools In this chapter ......... . . 89 Fabric Watch Configuration Using Web Tools .
  • Page 10 Fabric Watch Administrator’s Guide 53-1002153-02...
  • Page 11 Tables Table 1 Fabric Watch classes ..........22 Table 2 Fabric Watch configuration tasks .
  • Page 12 Fabric Watch Administrator’s Guide 53-1002153-02...
  • Page 13 Figures Figure 1 In-between buffer values ..........16 Figure 2 Time base set to none .
  • Page 14 Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 15: About This Document

    About This Document In this chapter • How this document is organized ........xv •...

  • Page 16: Supported Hardware And Software

    • Chapter 8, “System Monitoring,” describes how to configure system memory and CPU values using the sysMonitor command. This chapter also lists the switch status policy factors that affect the health of the switch, describes how to set and view switch status policies, and details how to configure FRUs.

  • Page 17: Deprecated Hardware Platform Support

    What’s new in this document Hardware Platform Access Gateway? Brocade DCX 8510-8 Backbone (8-slot) Brocade DCX 8510-4 Backbone (4-slot) • FC8-64 port blade • FC16-32 port blade • FC16-48 port blade • FS8-18 encryption blade • FX8-24 DCX extension blade Deprecated hardware platform support The following hardware platforms are not supported in the Fabric OS 7.0.0 release.

  • Page 18: Changed Information

    What’s new in this document • Packet loss monitoring enhancements on the VE_Port. Changed information • Updated port fencing section and included moderate, aggressive, and conservative threshold settings. • Recommended settings for Port areas using the portThConfig command. • Buffer settings which now enable the user to configure “in-between” buffer values for thresholds that fall between the below high threshold and the above low threshold boundaries.

  • Page 19: Notes, Cautions, And Warnings

    What’s new in this document Notes, cautions, and warnings The following notices and statements are used in this manual. They are listed below in order of increasing severity of potential hazards. NOTE A note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related information.

  • Page 20: Other Industry Resources

    What’s new in this document Other industry resources For additional resource information, visit the Technical Committee T11 website. This website provides interface standards for high-performance and mass storage applications for Fibre Channel, storage management, and other applications: http://www.t11.org For information about the Fibre Channel industry, visit the Fibre Channel Industry Association website: http://www.fibrechannel.org Getting technical help...

  • Page 21: Document Feedback

    What’s new in this document If you cannot use the licenseIdShow command because the switch is inoperable, you can get the WWN from the same place as the serial number, except for the Brocade DCX. For the Brocade DCX, access the numbers on the WWN cards by removing the Brocade logo plate at the top of the nonport side of the chassis.
  • Page 22 What’s new in this document xxii Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 23: In This Chapter

    Chapter Fabric Watch In this chapter • Fabric health ........... 1 •...

  • Page 24: Fabric Watch Overview

    Fabric Watch overview Fabric Watch overview Fabric Watch is an optional storage area network (SAN) health monitor that allows you to enable each switch to constantly monitor its SAN fabric for potential faults and automatically alerts you to problems long before they become costly failures. Fabric Watch tracks a variety of SAN fabric elements and events.

  • Page 25: Reasons To Customize Fabric Watch Settings

    Reasons to customize Fabric Watch settings Universal temporary license support The Fabric Watch license is available as a Universal Temporary or a regular temporary license, meaning the same license key can be installed on any switch running Fabric OS version 6.3 or later. Universal temporary license keys can only be installed once on a switch, but can be applied to as many switches as required.

  • Page 26: Monitoring

    Reasons to customize Fabric Watch settings Time base configuration The time base specifies the time interval between two samples to be compared. The fwSetToCustom command allows you to switch from default to custom settings. Valid intervals are day, hour, or minute. See “Setting Fabric Watch custom and default values”...

  • Page 27: Class, Area, And Element Hierarchy

    Class, area, and element hierarchy Class, area, and element hierarchy Fabric elements and events are organized in a hierarchy by class, area, and element. There is a class, area, and element associated with every monitored behavior. Classes are the highest level in the system, subdivided into one or more areas.

  • Page 28: Security Monitoring

    Switch monitoring components The Performance Monitor class is divided into the following areas: • EE (end-to-end) Performance Monitor - Monitors RX and TX performance between two devices. • Filter Performance Monitor - Measures the number of frames transmitted through a port that match specific values in the first 64 bytes of the frame.

  • Page 29: Port Persistence

    Switch monitoring components For complete information about port monitoring, including configuration examples, port setting guidelines, and default settings, refer to “Port Monitoring” on page 55. Port persistence The data collected in port monitoring can vary a great deal over short time periods. Therefore, the port can become a source of frequent event messages (the data can exceed the threshold range and return to a value within the threshold range).

  • Page 30: System Resource Monitoring

    Logical switch support System resource monitoring System resource monitoring enables you to monitor your system’s RAM, flash, and CPU. You can use the sysMonitor command to perform the following tasks: • Configure thresholds for Fabric Watch event monitoring and reporting for the environment and resource classes.

  • Page 31: Threshold Monitoring Using Snmp Tables

    Threshold monitoring using SNMP tables Threshold monitoring using SNMP tables Understanding the components of SNMP makes it possible to use third-party tools to view, browse, and manipulate Brocade switch variables remotely. Every Brocade switch and director supports SNMP. When an event occurs and its severity level is at or below the set value, the Event Trap traps (swFabricWatchTrap), are sent to configured trap recipients.

  • Page 32: Fabric Watch Notification Types

    Fabric Watch notification types Fabric Watch notification types Fabric Watch provides event notifications in several different formats to ensure that event details are accessible from all platforms and operating systems. In response to an event, Fabric Watch can record event data as any (or all) of the following alarm options. E-mail alert An e-mail alert sends information about a switch event to a one or multiple specified e-mail address.

  • Page 33: Raslog (Switch Event)

    Fabric Watch audit messages You must configure the software to receive trap information from the network device. You must also configure the SNMP agent on the switch to send the trap to the management station. You can configure SNMP notifications using the snmpConfig command and you can configure notifications using Fabric Watch.

  • Page 34: Data Values

    Data values NOTE Audit messages are generated for port fencing configuration changes, whether port fencing is enabled or disabled. You can set up an external host to receive Audit messages so you can easily monitor unexpected changes. For information on error messages generated by Fabric Watch, see the Fabric OS Message Reference.

  • Page 35: In This Chapter

    Chapter Fabric Watch Thresholds In this chapter • Threshold values ..........13 •...

  • Page 36: In-Between Buffer Values

    Threshold triggers In-between buffer values The below high threshold is the term used to configure “in between” buffer values, as shown in Figure 1. In this example, the high threshold value is 5 and the buffer value is 1. Therefore, the “in-between”...

  • Page 37: Audit And Raslog Messages

    Threshold triggers Above event trigger Set the Above event trigger for an element that requires only high threshold monitoring. In the Above event trigger, Fabric Watch triggers an event immediately after the data value becomes greater than the high threshold. Define a buffer zone within the operational limit of an area to suppress multiple events when the counter value goes above the high threshold and fluctuates around it.

  • Page 38: Figure 3 Event Trigger

    Time bases Time bases Time bases specify the time interval between two samples to be compared. You can set the time base to day (samples are compared once a day), hour (samples are compared once an hour), minute (samples are compared every minute). This configurable field affects the comparison of sensor-based data with user-defined threshold values.

  • Page 39: Fabric Watch Alarm Behavior

    Fabric Watch alarm behavior Figure 4 shows a sample graph of data obtained by Fabric Watch (the type of data is irrelevant to the example). A high threshold of 2 is specified to trigger an event. A time base of minute is defined.
  • Page 40 Fabric Watch alarm behavior Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 41: Chapter 3 Fabric Watch Threshold Components

    Chapter Fabric Watch Threshold Components In this chapter • Fabric Watch classes, areas, and elements ......19 Fabric Watch classes, areas, and elements Fabric Watch uses a hierarchical organization to track the network device information it monitors.

  • Page 42: Elements

    Fabric Watch classes, areas, and elements • Chapter 8, “System Monitoring” The Resource class and Environment class areas and actions are configured using the sysMonitor command. The FRU class actions are configured using the fwFruCfg command Elements Fabric Watch defines an element as any fabric or switch component that the software monitors. Within each area, the number of elements is equivalent to the number of components being monitored.
  • Page 43 Fabric Watch classes, areas, and elements TABLE 1 Fabric Watch classes (Continued) Class Description Port Enables you to set additional thresholds specific to different types of ports. The Port class is made up of the following sub-classes: • E_Port class—Represents ports connected to another switch. •...
  • Page 44 Fabric Watch classes, areas, and elements Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 45: Interfaces For Activating Fabric Watch

    Chapter Fabric Watch Activation In this chapter • Interfaces for activating Fabric Watch ......23 Interfaces for activating Fabric Watch This section provides a brief overview of the available user interfaces for activating Fabric Watch.

  • Page 46: Activating Fabric Watch Using Snmp

    Interfaces for activating Fabric Watch If the Fabric Watch license is not listed, continue to step 4; otherwise, you are ready to use Fabric Watch. 4. Enter the license key with the licenseAdd key command, where key is the Fabric Watch license key.
  • Page 47 Interfaces for activating Fabric Watch Figure 5, the MIB browser populated the left side of the screen with a MIB tree that you can navigate. 3. Open Web Tools and select Tasks > Manage > Switch Admin. 4. Click Show Advanced Mode. 5.
  • Page 48 Interfaces for activating Fabric Watch Trap Recipient's IP address in dot notation: [0.0.0.0] Community (rw): [OrigEquipMfr] Trap Recipient's IP address in dot notation: [0.0.0.0] Community (rw): [private] Trap Recipient's IP address in dot notation: [0.0.0.0] Community (ro): [public] Trap Recipient's IP address in dot notation: [0.0.0.0] 1080::8:800:200C:417A Trap recipient Severity level : (0..5) [0] Community (ro): [common] Trap Recipient's IP address in dot notation: [0.0.0.0]...

  • Page 49: Figure 6 Example Oid Tree

    Interfaces for activating Fabric Watch 10. Expand the tree on the left to find the Fabric Watch OID information. To find the OID, navigate the following hierarchy: SW-MIB. bcsi. commDev; fibrechannel, fcSwitch, sw, swFWSystem. Fabric Watch displays a screen similiar to the one shown in Figure FIGURE 6 Example OID tree...

  • Page 50: Activating Fabric Watch Using Web Tools

    Interfaces for activating Fabric Watch Activating Fabric Watch using Web Tools You can open Web Tools on any workstation with a compatible Web browser installed. 1. Open the Web browser and type the IP address of the device in the Address field: http://10.77.77.77 https://10.77.77.77 2.

  • Page 51: Chapter 5 Fabric Watch Configuration

    Chapter Fabric Watch Configuration In this chapter • Fabric Watch configuration tasks ........29 •...
  • Page 52 Fabric Watch configuration tasks TABLE 2 Fabric Watch configuration tasks (Continued) Configuration task Command Location of procedure Set the following parameters for port portThConfig “Port Monitoring” on page 55 monitoring: portFencing • Port type • Area type • Time base •...

  • Page 53: Setting Fabric Watch Custom And Default Values

    Setting Fabric Watch custom and default values Setting Fabric Watch custom and default values Use the following commands to switch between custom and default values. These commands reset all thresholds for all classes: • fwSetToCustom - Sets the boundary and alarm level to custom. •...

  • Page 54: Disabling An E-Mail Alert

    E-mail notification configuration The Config Show menu lists each class for which you can provide a separate e-mail address. 2. Enter the number corresponding to the class for which the e-mail configuration should be displayed. Fabric Watch displays e-mail alert information such as: Mail Recipient Information ____________________________________ Email Alert...

  • Page 55: Sending A Test E-Mail Message

    E-mail notification configuration Sending a test e-mail message 1. Enter 4 in the fwMailCfg menu to test the e-mail configuration for a specific class. The Config Show menu displays. 2. Select a class to test. If the e-mail configuration for the class is complete, the following confirmation message displays: Email has been sent If the e-mail configuration for the class is not complete, the following error message displays:...

  • Page 56: Displaying The Relay Host Configuration

    Notification configuration The following message displays: Setting 192.168.39.118 as Relay Host.. 4. Enter the Domain Name (example: Brocade.com). Displaying the relay host configuration 1. Enter 6 in the fwMailCfg menu to display the relay host configuration menu. 1 Display Relay Host configuration 2 Set Relay Host IP 3 Remove Relay Host configuration 4 Quit...
  • Page 57 Notification configuration 2. Enter the following command if you decide not to have notifications sent. switch:admin> fwAlarmsFilterSet 0 The 0 option turns the alarm notification off. All notifications are suppressed when alarm notifications are turned off, except for the Environment class and Resource class. 3.
  • Page 58 Notification configuration Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 59: In This Chapter

    Chapter Fabric, Security, SFP, and Performance Monitoring In this chapter • Fabric monitoring guidelines and default settings ....37 • Security monitoring guidelines and default settings....40 •...

  • Page 60: Fabric Monitoring Setting Guidelines

    Fabric monitoring guidelines and default settings TABLE 3 Fabric class areas (Continued) Area Description Segmentation changes Tracks the cumulative number of segmentation changes. Segmentation changes occur (SC) because of one of the following: • Zone conflicts. • Incompatible link parameters. During E_Port and VE_Port initialization, ports exchange link parameters, and incompatible parameters result in segmentation.

  • Page 61: Fabric Class Default Settings

    Fabric monitoring guidelines and default settings Fabric class default settings Table 4 provides default settings for areas in the Fabric class. TABLE 4 Fabric class default settings Area Description Default threshold settings Default alarm Threshold state settings Domain ID changes Monitors forcible Unit: D_ID Changes Below: 0...

  • Page 62: Security Monitoring Guidelines And Default Settings

    Security monitoring guidelines and default settings Security monitoring guidelines and default settings The Security class monitors all attempts to breach your SAN security, helping you fine-tune your security measures. Security class areas Table 5 lists Product Name areas in the Security class and describes what each area indicates. Although it is recommended that you leave the entire Security class in its default state (no alerts), you can configure the Security class using the thConfig command.

  • Page 63: Security Monitoring Default Settings

    Security monitoring guidelines and default settings Security monitoring default settings Use the Security class default settings shown in Table 6 for area and notification configuration. There is no reason to alter the default settings. TABLE 6 Security class area default settings Area Description Default threshold settings Default alarm...
  • Page 64 Security monitoring guidelines and default settings TABLE 6 Security class area default settings (Continued) Area Description Default threshold settings Default alarm Threshold state settings SLAP failures (FSLAP) Monitors SLAP Unit: Violations Below: 0 Informative failures Time Base: minute Above: 3 Out_of_range Low: 1 High: 2...

  • Page 65: Sfp Monitoring Guidelines And Default Settings

    SFP monitoring guidelines and default settings SFP monitoring guidelines and default settings The SFP class groups areas that monitor the physical aspects of SFPs. An SFP class alarm alerts you to an SFP malfunction fault. SFP performance monitoring is not supported on VE_Ports. When a port goes offline, the RXP and TXP area values of the SFP become zero.

  • Page 66: Sfp Monitoring Default Settings

    SFP monitoring guidelines and default settings SFP monitoring default settings The SFP default settings are shown in Table 8. The default alarm configuration (log all alarms only to the error log) is sufficient. It is recommended that you do not allow alerts to go out as SNMP traps.

  • Page 67: Performance Monitoring Guidelines And Default Settings

    Performance monitoring guidelines and default settings Performance monitoring guidelines and default settings Performance monitoring serves as a tuning tool. The Performance Monitor class groups areas that track the source and destination of traffic. Use the Performance Monitor class thresholds and alarms to determine traffic load and flow and to reallocate resources appropriately.

  • Page 68: Thconfig Command

    thConfig command Table 11 provides default settings for areas in the End-to-End Performance Monitor class. TABLE 11 End-to-End Performance Monitor class default settings Area Description Default threshold settings Default alarm Threshold state settings End-to-end receive Monitors the Unit: KBps Below: 0 Informative performance receiving traffic...

  • Page 69: Table 12 Configuration Options For Thconfig Command

    thConfig command TABLE 12 Configuration options for thConfig command Class name Valid area types Threshold Threshold Configuration recommendation action Fabric ED - Number of E_Ports Default or Default or It is recommended that you leave the down Custom Custom entire Fabric class in its default state (no alerts).

  • Page 70: Thconfig Command Examples

    thConfig command thConfig command examples With the exception of setting thresholds for the RX area of an end-to-end (EE) performance monitor, which requires special licensing in Access Gateway mode, it is recommended that you use the default settings for these classes. Setting the high threshold of the RX area of an EE monitor The thConfig command provides the ability to monitor thresholds for frame monitoring and end-to-end (EE) performance on both Access Gateway (AG) switches and non-AG switches.
  • Page 71 thConfig command Fabric Watch also monitors the Brocade Quad SFP (QSFP) and, as with the 16 Gbps SFP, if configured thresholds are crossed, Fabric Watch generates an SNMP alarm, a RASlog message, and an e-mail alert for the following SFP areas: •...
  • Page 72 thConfig command Specifying the 16 Gbps SFP type You can use the sfpType operand to manage the actions and thresholds for the Current, Voltage, RXP, TXP, and Temperature areas of the 16 Gbps SFPs. If you do not provide the SFP type parameters, the existing thresholds and actions of the SFP class are changed to the default.

  • Page 73: Table 13 16 Gbps And Qsfp Configurable Sfp Types

    thConfig command TABLE 13 16 Gbps and QSFP configurable SFP types (Continued) SfpType Serial number Area Default Value Others Temperature (Centigrade) Voltage (mVoltage) 3630 2970 RXP (uW) 5000 TXP (uW) 5000 Current (mAmp) Displaying the number of 16 Gbps SFP operational hours To show the number of hours that the 16 Gbps SFP is operational, enter the thConfig command using the following parameter.

  • Page 74: Recommended Settings For Fabric, Sfp, Performance, Security Classes

    Recommended settings for Fabric, SFP, Performance, Security classes Recommended settings for Fabric, SFP, Performance, Security classes Table 14 lists the recommended settings for the Fabric, SFP, Security, and Performance classes discussed in this chapter. For all of these classes, it is recommended that you use the default settings.
  • Page 75 Recommended settings for Fabric, SFP, Performance, Security classes TABLE 14 Recommended settings for Fabric, SFP, Performance, and Security classes (Continued) E=Error_Log, S=SNMP_Trap, P=Port_LOG_LOCK, M=EMAIL_ALERT, F=Port Fence Trait Configuration Security Telnet violations Violations Minute HTTP violations Violations Minute SCC violations Violations Minute DCC violations Violations...
  • Page 76 Recommended settings for Fabric, SFP, Performance, Security classes Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 77: Table 15 Port Class Areas

    Chapter Port Monitoring In this chapter • Port class areas ..........55 •...
  • Page 78 Port class guidelines and default settings TABLE 15 Port class areas (Continued) Area Description Protocol errors (PE) The number of times a protocol error occurs on a port. Invalid state due to LRR on an online link. Occasionally these errors occur due to software glitches. Persistent errors occur due to hardware problems.

  • Page 79: Table 16 Port Class Default Settings

    Port class guidelines and default settings Port class default settings Table 16 provides default settings for areas in the Port class. TABLE 16 Port class default settings Area Description Default threshold Default alarm settings Threshold state settings Cyclic redundancy Monitors the Unit: Errors Below: 0 Informative...

  • Page 80: Port Class Areas

    Port configuration TABLE 16 Port class default settings (Continued) Area Description Default threshold Default alarm settings Threshold state settings Transmitted packets Monitors Unit: Percentage (%) Below: 0 Informative (TXP) transmission rate, by Time Base: minute Above: 0 Informative percentage. Low: 0 High: 100 Buffer: 0 Link reset...

  • Page 81: Using The Nosave Command

    portThConfig command procedures Using the nosave command The nosave command prevents the configuration changes from being saved persistently. This option allows you to make and view changes without overwriting the saved configuration. CAUTION When you use --set with the --nosave option and the switch reboots, your changes are lost. portThConfig command procedures The following sections provides specific examples for the Port class.
  • Page 82 portThConfig command procedures 2. Apply the new custom settings so they become effective: switch:admin> portthconfig apply port -area crc -action cust -thresh_level custom 3. To display the port threshold configuration for the Port class and all areas: switch:admin>portthconfig show port Configuring all physical ports to monitor for invalid transmission words Invalid transmission words (ITW) occur when a word does not transmit successfully, resulting in encoding errors.

  • Page 83: E_Port Subclass Setting Guidelines

    portThConfig command procedures E_Port subclass setting guidelines E_Port guidelines for the areas listed below represent a more aggressive approach in most areas, because failing or failed E_Ports in a large fabric can cause serious fabric-wide issues if not detected early. NOTE The E_Port class represents ports connected to another switch.

  • Page 84: E_Port Class Default Settings

    portThConfig command procedures • Area: Trunk Utilization Set the high boundary to 75 percent and the alarms to Above and In-Between conditions. These settings indicate if the 75 percent threshold is exceeded and for how long. • Areas: Primitive Sequence Protocol Error, State Changes, Utilization, Packet Loss Use the default settings.
  • Page 85 portThConfig command procedures TABLE 17 E_Port class default settings (Continued) Area Description Default threshold Default alarm settings Threshold state settings Sync loss Monitors the Unit: Errors Below: 0 Informative number of loss of Time Base: minute Above: 0 Out_of_range synchronization Low: 0 errors.

  • Page 86: Fop_Port And Fcu_Port Subclass Setting Guidelines

    portThConfig command procedures FOP_Port and FCU_Port subclass setting guidelines FOP_Port and FCU_Port guidelines for the areas listed below represent a more aggressive approach in most areas. NOTE The settings in these subclasses include settings for the host bus adapter (HBA) ports as well as the storage ports.

  • Page 87: Table 18 Fop_Port And Fcu_Port Class Default Settings

    portThConfig command procedures • Area: Class 3 (C3) Discards Unlike the other areas, take a conservative approach for the C3 Discards area. Use the default settings and configure the alarms for Above. The goal is to locate issues with the device or its infrastructure, so monitor the data to help isolate issues.
  • Page 88 portThConfig command procedures TABLE 18 FOP_Port and FCU_Port class default settings (Continued) Area Description Default threshold Default alarm settings Threshold state settings Signal loss Monitors the Unit: Errors Below: 0 Informative number of signal Time Base: minute Above: 0 Out_of_range loss errors.

  • Page 89: Ve_Port Class Default Settings

    portThConfig command procedures VE_Port class default settings Table 19 provides default settings (per minute) for areas in the VE_Port class. TABLE 19 VE_Port class default settings Area Description Default threshold Default alarm settings Threshold state settings Packet loss The number of Unit: Errors Below: 0 Informative...

  • Page 90: Port Fencing

    Port fencing 1. Use the fwSet --port -persistence command to set the port persistence time. switch:admin> portthconfig show [port_type] 2. Set the port persistence time. switch:admin> fwSet port -persistence seconds Port fencing Port fencing monitors ports for erratic behavior and disables a port if specified error conditions are met.

  • Page 91: Port Fencing Configuration

    Port fencing NOTE The execution of the portFencing command is subject to Virtual Fabric (VF) or Admin Domain restrictions that may be in place. For example, in non-VF chassis environments, the state change counter of a trunked slave port gets incremented by more than 1 when the master EX_Port changes its state.

  • Page 92: Port Fencing Configuration Using Dcfm

    Port fencing TABLE 21 Recommended port fencing thresholds Area Moderate/recommended Aggressive threshold Conservative threshold threshold Cyclic redundancy check Low 5 Low 0 Low 5 (CRC) High 20 High 2 High 40 Invalid transmission word Low 25 Low 0 Low 25 (ITW) High 40 High 25...

  • Page 93: Recommended Port Configuration Settings

    Recommended port configuration settings Port fencing requirements To configure port fencing using the DCFM management application, all Fabric OS devices must have Fabric Watch and must be running firmware Fabric OS 6.2 or later. Port fencing threshold areas supported on DCFM You can add, edit, view, or remove thresholds on the following area types using DCFM.

  • Page 94: Table 22 Recommended Configuration For The Port Class

    Recommended port configuration settings TABLE 22 Recommended configuration for the Port class E=Error_Log, S=SNMP_Trap, P=Port_LOG_LOCK, M=EMAIL_ALERT, pf=Port Fence Trait Configuration Port Link Loss Errors Minute Sync Loss Errors Minute Signal Loss Errors Minute Protocol Error Errors Minute Invalid Words Errors Minute Invalid CRCs Errors...
  • Page 95 Recommended port configuration settings TABLE 22 Recommended configuration for the Port class (Continued) E=Error_Log, S=SNMP_Trap, P=Port_LOG_LOCK, M=EMAIL_ALERT, pf=Port Fence Trait Configuration FOP_Port and Link Loss Errors Minute FCU_Port Sync Loss Errors Minute Signal Loss Errors Minute HOST Protocol Error Errors Minute Invalid Words Errors...
  • Page 96 Recommended port configuration settings Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 97: System Monitoring

    Chapter System Monitoring In this chapter • Environment monitoring ......... 75 •...

  • Page 98: Environment Monitoring Setting Guidelines

    Environment monitoring Environment monitoring setting guidelines Use Environment Class default settings. Temperature settings are switch-dependent and there is no need to alter them. The default alarm configuration, sending alerts to the error log and SNMP, is sufficient. Environment class default settings Table 24 provides default Environment class settings for all switches.

  • Page 99: Resource Class Settings

    Resource class settings TABLE 24 Environment class default settings (Continued) Area Description Default threshold Default alarm settings Threshold state settings Brocade 8000 Low: 0 High: 73 Buffer: 10 Brocade DCX Low: 0 High: 70 Buffer: 10 Brocade DCX-4S Below: 3 Informative Low: 0 Above: 3...

  • Page 100: System Monitoring Using The Sysmonitor Command

    System monitoring using the sysMonitor command System monitoring using the sysMonitor command Use the sysMonitor command to configure temperature and system resource settings at the chassis level. For detailed information about the sysMonitor command, refer to the Fabric OS Command Reference Manual. The following operations are supported by the sysMonitor command: •...

  • Page 101: Examples Of The Sysmonitor Command

    Examples of the sysMonitor command Examples of the sysMonitor command The following sections provide specific examples for the Environment class, CPU, and memory. Environment class settings Temperature settings are switch-dependent and there is no need to alter them. The default alarm configuration, sending alerts to the error log and SNMP, is sufficient.

  • Page 102: Cpu And Memory

    Examples of the sysMonitor command CPU and memory When configuring CPU monitoring, specify a value in the 1-100 range. When the CPU usage exceeds the limit, a Fabric Watch alert is triggered. The default CPU limit is 75 percent. When configuring memory, the limit specifies a usage limit as a percentage of available resources. When used to configure memory monitoring the limit value must be greater than the low limit and smaller than the high limit.

  • Page 103: Recommended Environment And Resource Monitoring Settings

    Recommended environment and resource monitoring settings Configuring the system memory usage monitoring threshold Enter the sysMonitor command using the following parameters: switch:admin> sysmonitor config mem -poll 10 -retry 1 -limit 20 -action snmp, raslog -high_limit 80 Recommended environment and resource monitoring settings Table 27 lists the recommended settings for Environment and Resource classes.

  • Page 104: Switch Status Policy Planning

    Switch monitoring Switch status policy planning Fabric Watch monitors the health of the switch under various classes. Table 28 lists the current overall switch status policy parameters in a switch and identifies the factors that affect their health. Note that not all switches use the listed monitors. Use the switchstatusPolicySet command to manually change the policy setting.

  • Page 105: Table 28 Switch Status Policy Factors

    Switch monitoring TABLE 28 Switch status policy factors Monitor Health factors Marginal Ports Port, E_Port, FOP_port (optical), and FCU_Port (copper) port thresholds. Whenever these thresholds are persistently high, the port is Marginal. Faulty Ports Hardware-related port faults. Missing SFPs Ports that are missing SFP media. Error Ports1 Ports with errors.

  • Page 106: Fru Monitoring

    FRU monitoring • Missing SFPs—Monitors the number of ports without SFPs. • Error Ports—Ports that are disabled because of segmentation, an authentication failure, port fencing, or bottleneck detection. The policy you defined determines the output in the Switch Status Policy Report. Chapter 10, “Fabric Watch Reports,”...

  • Page 107: Specifying Triggers For Fru Alarms

    FRU monitoring 4. In the prompt that follows your current FRU configuration, you are asked to provide values for each FRU alarm state and alarm action. To accept the default value for each FRU, press Return. After you have configured a FRU alarm state and alarm action, the values apply to all FRUs of that type.

  • Page 108: Table 30 Recommended Fru Settings

    FRU monitoring Recommended FRU settings Table 30 lists the recommended settings for field-replaceable units (FRUs). TABLE 30 Recommended FRU settings E=ERROR_LOG, M=EMAIL_ALERT Class Area Absent Inserted Faulty Below Above Slot Power Supply Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 109: Chapter 9 Fabric Watch Configuration Using Web Tools

    Chapter Fabric Watch Configuration Using Web Tools In this chapter • Fabric Watch Configuration Using Web Tools ......87 Fabric Watch Configuration Using Web Tools You can use Web Tools to define the following Fabric Watch configurations: •...

  • Page 110: System Monitor

    Fabric Watch Configuration Using Web Tools NOTE Unless the switch is a member of the current Admin Domain context, Fabric Watch is view-only. FIGURE 7 Fabric Watch dialog box Fabric Watch Explorer, on the left side of the window, displays the available classes. Not all classes are available for all switches.

  • Page 111: Fabric Watch Threshold Configuration

    Fabric Watch Configuration Using Web Tools 4. Click the Alarm Configuration tab. 5. Select SNMP Trap, RAS log, or both options. 6. Click Apply. Fabric Watch threshold configuration using Web Tools The Threshold Configuration tab enables you to configure event conditions. From this tab, you configure threshold traits, alarms, and e-mail configurations.
  • Page 112 Fabric Watch Configuration Using Web Tools 9. Enter the highest boundary of the normal zone in the High Boundary field. 10. Enter the size of the buffer zone in the Buffer Size field. 11. Click Apply. Configuring threshold alarms After you update the threshold information, use the Alarm Configuration subtab to customize the notification settings for each event setting.
  • Page 113 Fabric Watch Configuration Using Web Tools • Click Custom Defined to specify new settings and proceed to the next step. 6. Select the check box for the type of notification method you want to use for each event type. The available alarm actions are: •...

  • Page 114: Configuring Alarms For Frus

    Fabric Watch Configuration Using Web Tools Configuring alarms for FRUs using Web Tools Configuration for the FRU class is different from configuration for the other classes. Because FRUs are not monitored through a threshold-based system, they have a simpler interface for configuration.

  • Page 115: Fabric Watch Alarm Information

    Fabric Watch Configuration Using Web Tools Fabric Watch alarm information From Fabric Watch, you can view two types of reports: • Alarm notifications—Displays the alarms that occurred for a selected class or area. • Alarm configuration—Displays threshold and alarm configurations for a selected class or area. Viewing an alarm configuration report Use the Threshold Configuration tab, Configuration Report subtab to display a report of the configuration for a selected class or area with the following information:...

  • Page 116: E-Mail Notification

    Fabric Watch Configuration Using Web Tools To display the alarms page, perform the following steps. 1. Open the Fabric Watch window. 2. In Fabric Watch Explorer, select the class that you want to check for alarms. 3. Select the Alarm Notification tab. 4.
  • Page 117 Fabric Watch Configuration Using Web Tools To enable an e-mail alerts recipient, perform the following steps. 1. Open the Fabric Watch window. 2. Select the Email Configuration tab. 3. Select a FRU class in the Fabric Watch Explorer tree. 4. Click Enable. 5.
  • Page 118 Fabric Watch Configuration Using Web Tools Fabric Watch Administrator’s Guide 53-1002153-02...

  • Page 119: In This Chapter

    Chapter Fabric Watch Reports In this chapter • Fabric Watch reports ..........97 •...

  • Page 120: Switch Availability Monitor Report

    Switch Availability Monitor report Switch Availability Monitor report The Switch Availability Monitor (SAM) report lets you see the uptime and downtime for each port. It also enables you to check if a particular port is failing more often than the others. NOTE SAM report details do not display the health status of GbE ports.

  • Page 121: Switch Health Report

    Switch Health report 2/12 2/13 2/14 2/15 3/10 Switch Health report The Switch Health report lists the following information: • Current health of each port, based on the currently-configured policy settings. • High-level state of the switch, the power supplies and temperature monitor. •...

  • Page 122: Switch Status Policy Report

    Switch Status Policy report The final portion of the report, detailing port health, is not available without a Fabric Watch license. Switch Status Policy report The Switch Status Policy report displays the current policy parameter. The following example of the switchStatusPolicyShow command output is for enterprise-class platforms such as the DCX Backbone.

  • Page 123: Port Detail Report

    Port Detail report Port Detail report If the Switch Health report shows marginal throughput or decreased performance, use the Port Detail report to see statistics on each port. The Port Detail report is a Fabric Watch licensed product. You can also see port details by health. For example, you can see only healthy ports, only marginal ports, only faulty ports, or only offline ports.

  • Page 124: Table 33 Port Detail Report Columns

    Port Detail report HEALTHY 003:37 HEALTHY 002:48 HEALTHY 061:19 HEALTHY 061:19 HEALTHY 061:19 NOTE Output of the Port Detail report depends on the ports that belong to the current Admin Domain context. If a port does not belong to the current Admin Domain, nothing other than the port number is displayed for that port.

  • Page 125: Index

    Index above event triggers class access gateway mode, restrictions in Fabric Watch environment fabric action configuration guidelines activating Fabric Watch Performace Monitor using a Telnet session port using SNMP resource using Web Tools security alarm behavior alarm configuration report for Fabric Watch classes, description of alarm notification configuration command...

  • Page 126: Switch Monitoring Components

    data values fabric class DCFM, port fencing configuration areas default settings default settings fabric event monitoring E_Port Fabric health concepts environment class Fabric class fabric monitoring FOP_Port and FCU_Port guidelines performance monitor class recommended settings default settings setting guidelines port class Fabric Watch VE_Port actions...
  • Page 127 FCU_Port default settings FCU_Port setting guidelines FOP_Port default settings notification configuration FOP_Port setting guidelines alarms FRU alarms, configuring notification methods FRU class e-mail areas e-mail alert configuration port log lock recommended settings notification type specifying triggers for alarms e-mail alert FRU configuration locked port log FRU monitoring...

  • Page 128: Security Monitoring

    sysMonitor command command examples QSFP system monitoring description of system monitoring configuration monitoring support for Telnet, using to activate Fabric Watch temperature, configuring using sysMonitor command RASlog notification type thConfig command RASlog, generation when core blade is removed configuration options RBAC, permissions required for Fabric Watch thMonitor command relay host configuration...

This manual is also suitable for:

Fabric watch

Table of Contents
