Page 1: Web Tools
53-1002756-01 ® 14 December 2012 Web Tools Administrator’s Guide Supporting Fabric OS v7.1.0...
Page 2 Copyright © 2006-2012 Brocade Communications Systems, Inc. All Rights Reserved. Brocade, Brocade Assurance, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, MLX, NetIron, SAN Health, ServerIron, TurboIron, VCS, and VDX are registered trademarks, and AnyIO, Brocade One, CloudPlex, Effortless Networking, ICX, NET Health, OpenScript, and The Effortless Network are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries.
Page 3 Document Title Publication Number Summary of Changes Publication Date Advanced Web Tools User’s 53-0000522-04 Insistent Domain ID Mode. October 2003 Guide v4.1.2 Port Swapping information. Minor editorial changes. Advanced Web Tools 53-0000522-05 Updates to support new switch types: December 2003 Administrator’s Guide, v4.2.0 Brocade 3250, 3850, 24000.
Page 4 Document Title Publication Number Summary of Changes Publication Date Web Tools Administrator’s Guide 53-1001194-01 Updates to add support for Virtual November 2008 Fabrics, IPsec, and consistency with Brocade Network Advisor. Web Tools Administrator’s Guide 53-1001343-01 Updates to add support for Brocade July 2009 7800 Extension Switch, Brocade 8000, FCOE10-24 DCX Blade, and FX8-24...
Page 5: Table Of Contents
Contents Figures Tables About This Document How this document is organized ......xxi Supported hardware and software .
Page 6 Opening Web Tools ........10 Logging in .
Page 7 Switch configuration ........35 Enabling and disabling a switch .
Page 8 Performing a firmware download ......57 Chapter 5 Managing Ports Port management overview ....... . 59 Opening the Port Admin tab .
Page 9 F_Port trunk groups ........87 Creating and maintaining F_Port trunk groups .
Page 10 Zoning management........105 Refreshing fabric information ......107 Refreshing Zone Administration window information .
Page 11 Port LED interpretation ........130 Port icon colors ........130 Chapter 10 Using the FC-FC Routing Service Fibre Channel Routing overview.
Page 12 Chapter 13 Administering Extended Fabrics Extended link buffer allocation overview.....151 Configuring a port for long distance ......154 Chapter 14 Routing Traffic Routing overview .
Page 13 SNMP configuration ........180 Setting SNMP trap levels......180 Changing the systemGroup configuration parameters .
Page 14 Allow / Prohibit Matrix configuration ......206 Viewing Allow / Prohibit Matrix configurations... . .207 Modifying Allow / Prohibit Matrix configurations .
Page 15 Enabling and disabling QoS priority-based flow control ..227 Enabling and disabling FCoE ports ......227 Chapter 18 Limitations General Web Tools limitations .
Page 16 Web Tools Administrator’s Guide 53-1002756-01...
Page 17 Figures Figure 1 Configuring Internet Explorer ......... 6 Figure 2 Default Java for browsers option .
Page 18 Figure 37 User tab ............165 Figure 38 Add User Account dialog box (VF) .
Page 19 Tables Table 1 Basic Web Tools features and EGM licensed features ..... 2 Table 2 Web Tools functionality moved to Brocade Network Advisor ....3 Table 3 Certified and tested platforms.
Page 20 Web Tools Administrator’s Guide 53-1002756-01...
Page 21: About This Document
About This Document In this chapter • How this document is organized ........xxi •...
Page 22: Supported Hardware And Software
• Chapter 11, “Using the Access Gateway” provides information on how to configure and manage the Brocade Access Gateway. • Chapter 12, “Administering Fabric Watch” provides information on how to use the Fabric Watch feature to monitor the performance and status of switches and alert you when problems arise. •...
Page 23: What's New In This Document
• Brocade DCX 8510-4 • Brocade DCX 8510-8 Backbone • Brocade DCX Backbone • Brocade DCX-4S Backbone • Brocade Encryption Switch • Brocade VA-40FC The following blades are supported by this release: • Brocade CORE 8 blade • Brocade CP8 blade •...
Page 24: Document Conventions
• Switching between virtual fabrics • TACACS+ management • Setting a principal switch • Switch Status Policy changes • Forward Error Correction • Port Admin button grouping • Updated 'Setting a shared secret key pair' section to include HBA • Removed support for admin domain •...
Page 25: Notes, Cautions, And Warnings
Notes, cautions, and warnings The following notices and statements are used in this manual. They are listed below in order of increasing severity of potential hazards. NOTE A note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related information.
Page 26: Additional Information
Additional information This section lists additional Brocade and industry-specific documentation that you might find helpful. Brocade resources To get up-to-the-minute information, go to http://my.brocade.com to register at no cost for a user ID and password. White papers, online demonstrations, and data sheets are available through the Brocade website http://www.brocade.com/products-solutions/products/index.page For additional Brocade documentation, visit the Brocade website: http://www.brocade.com...
Page 27: Document Feedback
• Serial console and Telnet session logs • syslog message logs 2. Switch Serial Number The switch serial number and corresponding bar code are provided on the serial number label, as illustrated below: *FT00X0054E9* FT00X0054E9 The serial number label is located as follows: •...
Page 28 xxviii Web Tools Administrator’s Guide 53-1002756-01...
Page 29: Introducing Web Tools
Chapter Introducing Web Tools In this chapter • Web Tools overview ..........1 •...
Page 30: Web Tools Features Enabled By The Egm License
Web Tools, the EGM license, and Brocade Network Advisor Web Tools features enabled by the EGM license Table 1 describes those Web Tools features that require the EGM license. TABLE 1 Basic Web Tools features and EGM licensed features Feature Basic Web Tools Web Tools with EGM License Active Directory support...
Page 31: Web Tools Functionality Moved To Brocade Network Advisor
Web Tools, the EGM license, and Brocade Network Advisor TABLE 1 Basic Web Tools features and EGM licensed features (Continued) Feature Basic Web Tools Web Tools with EGM License Routing and DLS Configuration Security Policies Tab (like ACL) Switch Info tab Switch Status Switch View right-click options Trace dump...
Page 32: System Requirements
System requirements TABLE 2 Web Tools functionality moved to Brocade Network Advisor (Continued) Function Web Tools 6.1.0 Brocade Network Advisor Comments FCIP Tunnel Port Admin Module > GigE Configure > FCIP Tunnel Viewing FCIP Configuration tunnels is still supported in Web Tools 6.1.1, but New, Edit Config, and delete are...
Page 33: Setting Refresh Frequency For Internet Explorer
System requirements Brocade supports the platforms shown in Table TABLE 4 Supported platforms Operating System Browser Red Hat AS 4.0 (x86 32-bit) Firefox 12.0 RedHat Enterprise Linux 6.1 Adv (32-bit) SUSE Linux Enterprise Server 10 (32-bit) SUSE Linux Enterprise Server 11 (x86 32-bit) Windows 2000 Firefox 12.0, Internet Explorer 9.0 Windows 2003 Server, SP2...
Page 34: Deleting Temporary Internet Files Used By Java Applications
System requirements FIGURE 1 Configuring Internet Explorer Deleting temporary internet files used by Java applications For Web Tools to operate correctly, you must delete the temporary internet files used by Java applications. To delete these files, perform the following steps. 1.
Page 35: Java Installation On The Workstation
Java installation on the workstation Java installation on the workstation Java Plug-in must be installed on the workstation. If you attempt to open Web Tools without any Java Plug-in installed: • Internet Explorer automatically prompts and downloads the proper Java Plug-in. •...
Page 36: Installing The Java Plug-In On Windows
Java plug-in configuration Installing the Java plug-in on Windows To Install the Java plug-in on Windows, perform the following steps. 1. From the Start menu, select Control Panel and select the Java Plug-in Control Panel. 2. Select the About tab. 3.
Page 37: Value Line Licenses
Value line licenses 1. From the Start menu, select Control Panel. 2. Click the Advanced tab and expand the Default Java for browsers option, as shown in Figure 2 on page 9. FIGURE 2 Default Java for browsers option 3. Select Mozilla family and click Apply. 4.
Page 38: Opening Web Tools
Opening Web Tools Opening Web Tools You can open Web Tools on any workstation with a compatible Web browser installed. For a list of Web browsers compatible with Fabric OS v7.1.0, refer to Table 3. Web Tools supports both HTTP and HTTPS protocol.
Page 39: Logging In
Opening Web Tools FIGURE 3 Web Tools interface Logging in When you use Web Tools, you must log in before you can view or modify any switch information. This section describes the login process. Prior to displaying the login window, Web Tools displays a security banner (if one is configured for your switch), that you must accept before logging in.
Page 40 Opening Web Tools 1. Click Run on the signed certificate applet. A warning dialog box may display. If you select the check box Always trust content from this publisher, the warning dialog box is not displayed when you open Web Tools again. 2.
Page 41: Logging Out
Role-Based Access Control 2. Log in to a logical fabric. • To log in to the home logical fabric, select Home Logical Fabric and click OK. • To log in to a logical fabric other than the home logical fabric, select User Specified Logical Fabric, enter the fabric ID number or the context name, and click OK.
Page 42: Session Management
Session management TABLE 5 Predefined Web Tools roles (Continued) Role Description securityadmin You can perform actions that do not affect the stored configuration. switchadmin You can perform all actions on the switch, except the following: • You cannot modify zoning configurations. •...
Page 43: Web Tools System Logs
Web Tools system logs Web Tools system logs Web Tools uses the log4j framework to write the logs into a file When you launch Web Tools for the first time, it automatically creates the following directories. These directories are created under Web Tools directory if they are not available: •...
Page 44: Requirements For Ipv6 Support
Requirements for IPv6 support The default path for Windows is C:\Documents and Settings\<<user>>\Webtools\<log file>. The default path for Linux is /root/WebTools/<switch log file>. 3. Click Capture to start collecting the SupportSave logs. A zipped-up SupportSave folder is saved in the defined location. SupportSave zip file name format is “WT-SS-switchIP-dd-mm-yy-hh-mm-ss.zip”.
Page 45: Using The Web Tools Interface
Chapter Using the Web Tools Interface In this chapter • Viewing Switch Explorer ......... 17 •...
Page 46 Viewing Switch Explorer NOTE To perform monitoring tasks such as performance monitoring the EGM license must be installed on the switch; otherwise, access to this feature is denied and an error message displays. Reporting tasks, such as viewing the status of a switch. Tools tasks, such as opening the Telnet or SSH client window, beaconing a switch or chassis, and access to technical SupportSave.
Page 47: Persisting Gui Preferences
Viewing Switch Explorer Tabs and Fabric Tree Menu bar Switch View buttons Switch Events and Switch Information Indicator bar Professional Management Tool offering Switch View FIGURE 5 Switch Explorer Persisting GUI preferences Web Tools persists your GUI preferences across sessions for the Switch Explorer, Port Admin, Switch Admin, Name Server, and Zone Admin dialog boxes on all web-browser platforms.
Page 48: Tabs
Viewing Switch Explorer • Basic or Advance mode • Last selected tab by the user • Table column sorting • Table column positions The Switch Admin GUI preferences that persist are: • Basic or Advance modes • Last selected tab •...
Page 49: Switch View Buttons
Viewing Switch Explorer Although Fabric Tree displays all the switches in the fabric, you can manage switches that support Fabric OS v6.1 and later versions because it does not requires Web Tools license. If a switch is launched from Fabric Tree, preference will be given to IPv4, even though both IPv4 and IPv6 are configured for that particular switch.
Page 50 Viewing Switch Explorer When you mouse over a port, a yellow color toggling effect is available to identify the selected port. The port LEDs in the Switch View match the LEDs on the physical switch. However, the blink rate of the LEDs in the Switch View does not necessarily match the blink rate of the LEDs on the physical switch.
Page 51: Switch Events And Switch Information
Viewing Switch Explorer Switch Events and Switch Information Switch Events and Switch Information display as tab forms under Switch View. The information in the Switch Information tab is polled every 60 seconds. NOTE You can click the column head to sort the events by a particular column, and drag the column divider to resize a column.
Page 52: Free Professional Management Tool
Displaying tool tips • RNID Type Type of the switch. Model Model of the switch. Tag of the switch. Sequence number Sequence number of the switch. Insistent Domain ID Current status of the Insistent Domain ID mode of the switch. Mode Manufacturer Manufacturer of the switch.
Page 53: Right-Click Options
Right-click options Right-click options You can right-click a port to quickly perform some basic port administration tasks, as shown in Figure FIGURE 7 Right-click menu for ports (from Switch Explorer) The tasks are: • The Port Admin option displays the Port Admin tab. •...
Page 54: Displaying Switches In The Fabric
Displaying switches in the fabric For these reasons, the time displayed in the port statistics tab might not be refreshed as expected. The counter time indicates only that “this statistics data is retrieved from the switch in this time period.” To ensure the correct information, the time field is updated along with the port statistics data after every refresh.
Page 55: Opening A Telnet Or Ssh Client Window
Opening a Telnet or SSH client window • If you receive an error when saving changes in the Switch Administration window, note the error messages, refresh the window, and make your changes again. Do not continue making changes without refreshing the window and determining which changes were saved correctly. •...
Page 56: Collecting Logs For Troubleshooting
Collecting logs for troubleshooting To close the session, enter exit at the prompt and press the Enter key. Collecting logs for troubleshooting If you encounter problems using the Web Tools interface, collect Java logs for use in troubleshooting. From Microsoft Windows, perform this procedure. 1.
Page 57: Managing Fabrics And Switches
Chapter Managing Fabrics and Switches In this chapter • Fabric and switch management overview ......29 •...
Page 58 Fabric and switch management overview FIGURE 8 Switch Administration window, Switch tab, Basic mode With the exception of switch time, information displayed in the Switch Administration window is not updated automatically by Web Tools. To update the information displayed in the Switch Administration window, click the Refresh button.
Page 59: Opening The Switch Administration Window
Configuring IP and subnet mask information Opening the Switch Administration window Most of the management procedures in this chapter are performed from the Switch Administration window. To open the Switch Administration window, perform the following steps. 1. Click Configure > Switch Admin. The Switch Administration dialog box displays in basic mode, as shown in Figure 8 on page 30.
Page 60: Configuring Netstat Auto Refresh
Configuring Netstat Auto Refresh Configuring Netstat Auto Refresh The Netstat Performance window displays the details about Ethernet management port statistics like the Interface, MTU, Met, RX-OK, RX-ERR, RX-DRP, RX-OVR, TX-OK, TX-ERR, TX-DRP, TX-OVR, and Flag. To configure Auto Refresh, perform the following steps. 1.
Page 61: Configuring Ip Filtering
Configuring IP Filtering You can click Clear All to remove all of the syslog IP addresses from the table. 4. Click Apply. Configuring IP Filtering Web Tools provides the ability to control what client IP addresses may connect to a switch or fabric. To set up IP Filtering, perform the following steps.
Page 62: Enabling Or Disabling A Blade
Blade management Enabling or disabling a blade The Firmware Version columns display the firmware loaded onto each blade. A blade can have more than one firmware image loaded onto it. The Blade State column in the Blade tab pane indicates whether the blade is enabled. NOTE The blade state is always shown as enabled, even if you perform a blade disable operation.
Page 63: Viewing Ip Addresses
Switch configuration 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the Blade tab. 3. Click Set IP address. 4. Select a slot number from the list. 5. Enter the IP address, subnet mask, and Gateway IP address. 6.
Page 64: Enabling And Disabling Switch Persistent
Switch configuration 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the Switch tab. 3. In the Switch Status section, click Enable to enable the switch or Disable to disable the switch. 4.
Page 65: Changing The Switch Domain Id
Switch configuration Changing the switch domain ID Although domain IDs are assigned dynamically when a switch is enabled, you can request a specific ID to resolve a domain ID conflict when you merge fabrics. To change the switch domain ID, perform the following steps. 1.
Page 66: Switch Restart
Switch restart 3. In the Principal Switch section, perform one of the following to set the switch as a principal switch. • Select Set as preferred Principal Switch - The switch is set as principal switch in the next fabric rebuild. •...
Page 67: Performing A Reboot
System configuration parameters 4. Click Apply. Performing a reboot To reboot the CP and execute the normal power-on booting sequence, perform the following steps. 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2.
Page 68: Configuring Fabric Settings
System configuration parameters TABLE 7 Switches that support WWN-based Persistent PID on Web Tools Platform Default switch Logical switch Area mode FICON mode Yes, if dynamic If 8-bit dynamic area addressing mode is DCX/DCX-4S is enabled in the enabled, FMS is DCX 8510-4 Enabled default switch.
Page 69: Enabling Insistent Domain Id Mode
System configuration parameters Datafield size The largest possible data field size (in bytes). The range of valid values is from 256 through 2112. Address mode Displays the addressing mode present in the switch. Sequence Level Select this box to enable frames of the same sequence from a particular group to be Switching transmitted together.
Page 70: Configuring Arbitrated Loop Parameters
System configuration parameters 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Disable the switch as described in “Enabling and disabling a switch” on page 35. 3. Select the Configure tab. 4.
Page 71: Configuring Signed Firmware
Licensed feature management 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Disable the switch as described in “Enabling and disabling a switch” on page 35. 3. Select the Configure tab. 4.
Page 72: Assigning Slots For A License Key
Licensed feature management To activate a license, perform the following steps. 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the License tab and click Add. The Add License dialog box displays. 3.
Page 73: Universal Time-Based Licensing
High Availability overview Universal time-based licensing After v6.3.0, Web Tools supports universal time-based licensing. Each universal key is for a single feature, and can be used on any product that supports the feature, for a defined trial period. At the end of the trial period, the feature gets disabled.
Page 74: Synchronizing Services On The Cp
High Availability overview 1. Select a Brocade DCX, DCX-4S, DCX 8510-4 or DCX 8510-8 platforms from the Fabric Tree. The Switch View displays. 2. Click the HA button in the Switch View. The High Availability dialog box displays. The High Availability window contains the following two tabs: •...
Page 75: Initiating A Cp Failover
Event monitoring If the HA Status field displays HA enabled, Heartbeat Up, HA State not in sync, continue with step 3. 3. Click Synchronize Services. The Warning dialog box displays. 4. Click Yes and wait for the CPs to complete a synchronization of services, so that a nondisruptive failover is ready.
Page 76 Event monitoring • Alert • Critical • Error • Warning • Marginal • Notice • Information • Debug Table 8 lists the event message severity levels displayed on the Switch Events tab and explains what qualifies event messages to be certain levels. On the Switch Events tab, you can click Filter to launch the Event Filter dialog box.
Page 77: Displaying Switch Events
Event monitoring Displaying Switch Events The Switch Events tab displays a running log of events for the selected switch. Switch events are polled and updated every 15 seconds; there is no refresh-on-demand option for switch events. For two-switch configurations, all chassis-related events are displayed in the event list of each logical switch for convenience.
Page 78: Filtering Events By Message Id
Displaying the Name Server entries The filter is enabled and the window is refreshed to show the filtered information. Filtering events by message ID To filter events by message ID, perform the following steps. 1. Open the Switch Events tab as described in “Displaying Switch Events”...
Page 79: Printing The Name Server Entries
Displaying the Name Server entries 1. In the Switch Explorer window, select Name Server. The Name Server tab displays. 2. To set an autorefresh rate for the Name Server entries, select the Auto Refresh check box in the Name Server window, and enter an auto-refresh interval (in seconds). The minimum interval is 45 seconds and the default interval is 60 seconds.
Page 80: Physically Locating A Switch Using Beaconing
Physically locating a switch using beaconing Physically locating a switch using beaconing Use the Beacon button to physically locate a switch in a fabric. The beaconing function helps to physically locate a switch by sending a signal to the specified switch, resulting in an LED light pattern that cycles through all ports for each switch (from left to right).
Page 81: Selecting A Logical Switch From The Switch View
Virtual Fabrics overview • Brocade DCX 8510-4 • Brocade DCX 8510-8 Virtual Fabrics cannot be configured or managed from Web Tools. Configuration and management is done from either the Brocade Network Advisor, or the Fabric OS command line interface. For information about configuring and managing Virtual Fabrics, refer to the Brocade Network Advisor User Manual if you are using Brocade Network Advisor, or Fabric OS Administrator’s Guide if you are using the Fabric OS command line interface.
Page 82 Virtual Fabrics overview 1. Select Port Admin tab. The Port Admin tab displays. Logical ports are displayed in the FC Ports Explorer tree structure. 2. To view logical port properties, expand the Logical Ports branch, and select a port. The General properties are displayed.
Page 83: Maintaining Configurations And Firmware
Chapter Maintaining Configurations and Firmware In this chapter • Creating a configuration backup file ....... 55 •...
Page 84: Restoring A Configuration
Restoring a configuration If you select USB as the configuration file source, the network parameters are not needed and are not displayed. You can skip to step 6. 6. Use the Fabric ID selector to select the fabric ID of the logical switch from which the configuration file is to uploaded.
Page 85: Uploading And Downloading From Usb Storage
Uploading and downloading from USB storage An info link is enabled when USB is chosen as the source of the configuration file. If you click info, an information message displays. 6. Enter the configuration file with a fully-qualified path, or select the configuration file in the Configuration File Name field.
Page 86 Performing a firmware download The download source can be located on the Network or a USB device. NOTE When you select the USB button, you can specify only a firmware path or directory name. No other fields on the tab are available. The USB button is available if the USB is present on the switch.
Page 87: Managing Ports
Chapter Managing Ports In this chapter • Port management overview ........59 •...
Page 88: Opening The Port Admin Tab
Port management overview Opening the Port Admin tab Select Port Admin tab in the Switch Explorer window. The Port Admin tab displays information about the ports on the switch. Refer to “Switch View” on page 21 for information about accessible ports.
Page 89 Port management overview • MTU Size • Compression Mode • Data L2COS Value • DSCP Data • IKE Policy Number • IPsec Policy Enabled • Keep Alive Timeout • MaximumCommunicationRate • MinimumCommunicationRate • MaxRetransmitRate • MinRetransmitRate • Metric • Pre-Shared key •...
Page 90 Port management overview • General—All ports View Details Rename Edit Configuration Enable/Disable (port) Persistent Enable/Persistent Disable (port) • SFP—Physical ports only (FC, CEE, and GbE) Basic information about the port equipment • QSFP—Quad Small Form-factor Pluggable ports Basic Information about the port. UnitNumber ChannelIndex DeviceTech...
Page 91: Controllable Ports
Port management overview • General—All ports Rename Edit Configuration Re-Authenticate Port—Enable/Disable/Swap PID—Bind/Un-Bind Persistent—Enable/Disable F-Port—BB Credit/Trunking Trunking—Enable/Disable NPIV—Enable/Disable/Max Login QoS—Enable/Disable (requires Adaptive Networking License) CSCTL—Enable/Disable (requires Adaptive Networking License) Beacon—Enable/Disable Speed combination (applicable only to the Brocade 6520, Brocade 6510 and Brocade DCX 8510-4,8510-8 with the FC16-32 or FC16-48 Compression—Enable/Disable Encryption—Enable/Disable...
Page 92: Configuring Fc Ports
Configuring FC ports The Controllable attribute is Yes, if your role gives you Modify permission for ports. If a port is controllable, all configuration functionality is enabled. Configuring FC ports With the FC Port Configuration wizard, you can configure allowed port types, port speed, and long distance mode for physical ports.
Page 93: Allowed Port Types
Configuring FC ports NOTE If you configure a disabled port as an EX-Port, the wizard displays the Enable Port after configuration check box. If you select the check box, the disabled port is automatically enabled after configuration; otherwise, the port remains in the same state after configuration. Allowed port types For FC ports, the Port Admin tab displays the following values relating to port type: Port Type...
Page 94: Ingress Rate Limit
Configuring FC ports • 300, 5300, and 5100 switches • Brocade VA-40FC • Brocade 8000 • Brocade 7800 For non-8 Gbps platforms, all functionality is available without EGM license. Ingress rate limit Ingress rate limiting is a licensed feature that requires the Adaptive Networking license. NOTE For Brocade 6520, ingress rate limit can be configured without Adaptive Networking (AN) and Server Application Optimization (SAO) licenses.
Page 95: Assigning A Name To A Port
Assigning a name to a port • Brocade VA-40FC • Brocade 8000 To configure the ingress rate limit feature, perform the following steps. 1. Select View > Advanced. 2. In the Port Admin tab, select a port, or multiple ports, to configure. 3.
Page 96: Port Beaconing
Port beaconing Port beaconing Individual FC ports can be set to beacon using the Port Admin tab. Port beaconing status displays in the Port Beaconing column. The Switch View reflects the port beaconing status by flashing the port amber and green for 2.5 seconds each, in an alternating pattern. To configure beaconing for an FC port, perform the following steps.
Page 97: Considerations For Enabling Or Disabling A Port
Persistent enabling and disabling ports NOTE If the Enable or Disable option is gray (unavailable), the port is already in the enabled or disabled state. For example, if the Enable option is unavailable, the port is already enabled. If you select multiple ports in both enabled and disabled states, both options are active. When you click either option, the action is applied to all selected ports.
Page 98: Configuring Npiv Ports
Configuring NPIV ports 5. Select either Enable or Disable from the Persistent drop-down button. NOTE Persistent Enable or Disable is not supported in FMS mode. NOTE If the Enable or Disable option is gray (unavailable), the port is already in that state or FMS mode is enabled on the switch, the port is already in the enabled or disabled state.
Page 99: Port Activation
Port activation 6. Set the number of logins to allow on the selected port and click OK. Click Enable to bring the port back online. Port activation Brocade switches come with a preset number of ports enabled. Additional ports can be enabled using the Ports on Demand (POD) licenses and the Dynamic Ports on Demand (DPOD) feature (for supported switches only).
Page 100: Enabling Ports On Demand
Port activation TABLE 9 Ports enabled with POD licenses and DPOD feature (Continued) Switch name Enabled by Enabled with Ports on Demand Enabled with the Dynamic Ports on default licenses Demand feature Brocade 4016 0-7, 10-13 8, 9, 14, 15 Any available ports Brocade 300 8-15, 16-23...
Page 101: Disabling Dynamic Ports On Demand
Port activation 4. Click Enable DPOD to enable the licensing mechanism to be dynamic. If the button is labeled Disable DPOD, the licensing mechanism is already set to dynamic. The existing POD associations and assignments are set as the initial Dynamic POD associations.
Page 102: Reserving And Releasing Licenses On A Port Basis
Port swapping index Reserving and releasing licenses on a port basis NOTE The Dynamic PODs feature is supported on the Brocade 4018, 4020, and 4024 switches only. To reserve and release licenses on a port basis, perform the following steps. 1.
Page 103: Port Swapping
Port swapping index Port swapping In the Port Admin list view and detailed view, swapped ports are indicated with the “(Swapped)” label appended to the Port Index column and field (Figure 14). FIGURE 14 Port swapped label To swap ports, perform the following steps. 1.
Page 104: Configuring Bb Credits On An F_Port
Configuring BB credits on an F_Port 1. Select a port in the Switch View to open the Port Admin tab. 2. Select the FC Ports tab. 3. Select View > Advanced. 4. From the tree on the left, select the port you want to swap. 5.
Page 105: Configuring Alpa
Configuring ALPA Configuring ALPA PID is the address assigned to the host when it performs a login with a fabric. The 24 bits of the PID are built from three 1 byte fields. The most significant byte is the Domain ID, the second byte is the Area which that device belongs to, and the least significant byte is the ALPA.
Page 106: Configuring Port Octet Speed Combination
Configuring port octet speed combination FIGURE 16 ALPA Map selection A dialog box launches listing the Port WWN to ALPA Map with the host. The Port WWN map automatically populates. FIGURE 17 ALPA Map dialog 9. Optional: Click Remove All to clear all of the Port WWN maps. Configuring port octet speed combination The Port Admin tab provides an option to set the Port Octet Speed Combination.
Page 107 Configuring port octet speed combination NOTE For FC8-32E and FC8-48E port blades, the port octet speed combination is Auto or Fixed 8G|4G|2G. You can change the octet combination for the octet associated with first eight ports of a blade or switch.
Page 108: Configuring Csctl
Configuring CSCTL Configuring CSCTL Unlike QoS Zone-based FC flow prioritization method, CSCTL enables the same SID/DID pair exchange frames with different priorities. To be able to prioritize a frame flow between two end nodes, Fabric OS v7.0.0 and later provide support for up to 32 Virtual Channels (VCs) per port.
Page 109: Configuring Compression And Encryption
Configuring compression and encryption 4. Select Disable from the CSCTL drop-down button. Configuring compression and encryption Encryption provides security for the frames while they are in-flight and Compression allows better bandwidth utilization over long distance. Total bandwidth supported per blade for encryption is 32 Gbps and compression is 64 Gbps.
Page 110: Displaying Compression Ratio
Forward Error Correction Either of the following compression status is displayed in the General tab of the port. Enabled (Active) - Compression is enabled on a port and the configuration is Active. Enabled (Inactive) - Compression is enabled on a port and the configuration is Inactive. Disabled - Compression is not enabled on a port.
Page 111 Inband Management The Inband Management interface is protocol independent, so any traffic destined for these Inband Management interfaces is passed through the distribution point to the control processor. It is then handled on the control processor, according to the rules set forth for the normal management interface and following any security rules that may be in place on the control processor.
Page 112: Gige Port Modes
GigE port modes GigE port modes Web Tools allows you to set the GigE port mode for the FX8-24 DCX Extension Blades to 1G, 10G, or dual modes. To configure the GigE port mode, perform the following steps: NOTE You must install the FX8-24 DCX Extension Blade in a slot containing 10GE license to configure the mode.
Page 113: Enabling Isl Trunking
Chapter Enabling ISL Trunking In this chapter • ISL Trunking overview ......... . . 85 •...
Page 114: Viewing Trunk Group Information
Viewing trunk group information 1. Select a port in the Switch View to open the Port Admin tab. 2. Select the FC Ports tab. 3. From the tree on the left, select the switch name or slot name. 4. From the table, select the port that you want to trunk. You can select multiple ports from the table.
Page 115: F_Port Trunk Groups
F_Port trunk groups • Trunk Index (applies only to F_Port trunking). • Trunking Enabled F_Port trunk groups F_Port trunking provides extra bandwidth and robust connectivity for hosts and targets connected by switches in Access Gateway mode. There are five general criteria for establishing F_Port trunking: •...
Page 116 F_Port trunk groups A trunk group is created, identified by the trunk index, and containing the port you selected. Select the trunk group you just created. Add Members becomes active. 8. Additional ports can be added by selecting a port from Ports for trunking table and then clicking Add Members.
Page 117: Monitoring Performance
Chapter Monitoring Performance In this chapter • Performance Monitor overview........89 •...
Page 118: Advanced Monitoring
Performance Monitor overview Advanced monitoring The Advanced Monitoring menu is an optionally licensed feature. To utilize the Advanced Monitoring feature you must have a Performance Monitor license installed and you must log in using an account with an admin, switchadmin, fabricadmin role, and properly configured user defined roles.
Page 119 Performance Monitor overview TABLE 11 Basic performance graphs Graph type Display description Port Throughput The performance of a port, in bytes per second, for frames received and transmitted. Switch Aggregate Throughput The aggregate performance of all ports on a switch. Blade Aggregate Throughput The aggregate performance of all ports on a port card.
Page 120 Performance Monitor overview TABLE 13 Supported port types for Brocade switches (Continued) Graph type Physical FC ports Logical FC ports GbE ports Switch Percent Utilization Port Snapshot Error SID/DID Performance SCSI Commands SCSI vs. IP Traffic The Blade Aggregate Throughput graph is supported only on the Brocade DCX and DCX-4S enterprise-class platforms.
Page 121: User-Defined Graphs
Performance Monitor overview FIGURE 21 Accessing performance graphs User-defined graphs You can modify the predefined graphs to create your own customized graphs (refer to “Customizing basic monitoring graphs” on page 95 for more information). These user-defined graphs can be added and saved to canvas configurations. Canvas configurations A canvas is a saved configuration of graphs.
Page 122: Opening The Performance Monitor Window
Opening the Performance Monitor window FIGURE 22 Canvas of six performance monitoring graphs Opening the Performance Monitor window To perform performance monitoring, you must use Web Tools with the EGM license; otherwise, access to this feature is denied and an error messages displays. To open the Performance Monitor window, perform the following steps.
Page 123: Customizing Basic Monitoring Graphs
Customizing basic monitoring graphs NOTE For the Brocade 300, 5100, 5300, 6510, 6520, VA-40FC, 7800 Extension, 8000, and the Encryption Switch, enter only a port number. 4. Click OK. The graph is displayed in a window in the Performance Monitor window. Customizing basic monitoring graphs You can customize some of the basic performance monitoring graphs to display information for particular ports.
Page 124 Customizing basic monitoring graphs FIGURE 23 Select Ports for customizing the Switch Throughput Utilization graph You can perform the following in the dialog box: a. Double-click the domain to expand the slot or port list. NOTE For the Brocade 8510-8, Brocade 8510-4, and Brocade DCX and Brocade DCX-4S enterprise-class platforms, click the plus (+) signs to expand the ports under each slot, as shown in Figure...
Page 125: Advanced Performance Monitoring Graphs
Advanced performance monitoring graphs Advanced performance monitoring graphs This section describes how to create the advanced performance monitor graphs listed in Table 12 on page 91. Because the procedure for creating these graphs differs depending on the type of graph, each type is described separately in the sections that follow. The advanced monitoring graphs are not supported for GbE ports.
Page 126: Creating The Scsi Vs. Ip Traffic Graph
Advanced performance monitoring graphs If you selected multiple EE monitors, SIDs, or PIDs, a confirmation dialog box displays, reminding you that one graph is opened for each selection. Click Yes to display the graphs. 8. When you close a graph, a dialog box asks if you want to save the monitor. If you click OK, the monitor is saved, and persists if the switch is restarted.
Page 127: Tunnel And Tcp Performance Monitoring Graphs
Tunnel and TCP performance monitoring graphs 3. Navigate to a switch > slot > port in the Port Selection List. 4. Click the port from the Port Selection List and drag it into the Enter/drag port field. 5. Optional: For the LUN per port graphs, enter a LUN number, in hexadecimal notation. For the Brocade Encryption Switch, you can enter up to eight LUN masks For the Brocade 5100, 5300, 300, 7800, and 8000, you can enter up to eight LUN masks For all other switches running Fabric OS 4.x or v5.x, you can enter up to two LUN masks.
Page 128: Tunnel And Tcp Graph Chart Properties
Saving graphs to a canvas 4. In the Tunnel and TCP area at the bottom of the screen, select the required check boxes for the statistic you want to graph. Note that each column represents a different graph. 5. Click Options to set the display options for the graphs. •...
Page 129: Adding Graphs To An Existing Canvas
Adding graphs to an existing canvas 3. Select File > Save Current Canvas Configuration. The Save Canvas Configuration dialog box displays. 4. Enter a name and description for the configuration and click Save Canvas. A message displays, confirming that the configuration was successfully saved to the switch. Adding graphs to an existing canvas The following procedure assumes that a canvas is already created.
Page 130 Modifying graphs 1. Open the Performance Monitor window. 2. Select File > Display Canvas Configurations. The Canvas Configuration List displays. A message “No Canvas configuration to display” displays if there are no saved canvas configurations. 3. Select a canvas from the list and click Edit. The Performance Monitor Canvas: Canvas Name dialog box displays.
Page 131: Administering Zoning
Chapter Administering Zoning In this chapter • Zoning overview ..........103 •...
Page 132: Lsan Zone Requirements
Zoning configurations LSAN zone requirements An LSAN zone enables device connectivity between fabrics connected in Fibre Channel Routing (FCR) configurations without forcing you to merge fabrics. Extension switches provide multiple mechanisms to manage interfabric device connectivity. Zones that contain hosts and targets that are shared between the two fabrics need to be explicitly coordinated.
Page 133: Setting The Default Zoning Mode
Zoning management Setting the default zoning mode The default zoning mode has two options: • All Access—All devices within the fabric can communicate with all other devices. • No Access—Devices in the fabric cannot access any other device in the fabric. NOTE You should not change the default zone mode from No Access to All Access if there is no effective zone configuration and more than 120 devices are connected to the fabric.
Page 134 Zoning management FIGURE 24 Zone Administration window ATTENTION Any changes you make in the Zone Administration window are held in a buffered environment and are not updated in the zoning database until you save the changes. If you close the Zone Administration window without saving your changes, your changes are lost.
Page 135: Refreshing Fabric Information
Zoning management The Member Selection List panel displays only physical FC ports. To verify whether you have any unzoned devices, you must use Brocade Network Advisor to analyze zone configurations. In the Member Selection List, you can diferentiate between node WWN and port WWN with their icons as shown in Figure 25 Figure...
Page 136: Refreshing Zone Administration Window Information
Zoning management Refreshing Zone Administration window information The information displayed in the Zone Administration window is initially a snapshot of the contents of the fabric zoning database at the time the window is launched. Any changes you make to this window are saved to a local buffer;...
Page 137: Selecting A Zoning View
Zoning management To save the local zone changes, perform the following steps. 1. Make the zoning changes in the Zone Administration window. 2. Select Zoning Actions > Save Config. NOTE If you have made changes to a configuration, you must enable the configuration before the changes are effective.
Page 138: Adding And Removing Members Of A Zone Alias
Zoning management 1. Open the Zone Administration window as described in “Opening the Zone Admin window” page 104. 2. Select a format to display zoning members in the Member Selection List as described in “Selecting a zoning view” on page 109. 3.
Page 139: Renaming Zone Aliases
Zoning management Renaming zone aliases The new alias name cannot exceed 64 characters and can contain alphabetic, numeric, and underscore characters. For more information on enabling the configuration, refer to “Enabling zone configurations” page 118. To change the name of a zone alias, perform the following steps. 1.
Page 140: Adding And Removing Members Of A Zone
Zoning management To create a zone, perform the following steps. 1. Open the Zone Administration window as described in “Opening the Zone Admin window” page 104. 2. Select a format to display zoning members in the Member Selection List as described in “Selecting a zoning view”...
Page 141: Renaming Zones
Zoning management The zone members for the selected zone are listed in the Zone Members list. 4. Highlight an element in the Member Selection List that you want to include in your zone, or highlight an element in the Zone Members list that you want to delete. 5.
Page 142: Deleting Zones
Zoning management Select Zoning Actions > Save Config to save the configuration changes. Because no changes were made to the effective configuration, you do not need to enable the configuration. Deleting zones For information on enabling the configuration, refer to “Enabling zone configurations”...
Page 143: Zone Configuration And Zoning Database Management
Zone configuration and zoning database management NOTE All switches in the fabric must be running Fabric OS v6.4.0 or later and all the ports in the TI zones must be in the same failover mode. Optional: Repeat steps 5 and 6 to add more elements to your TI zone. 8.
Page 144: Creating Zone Configurations
Zone configuration and zoning database management Creating zone configurations To create a zone configuration, perform the following steps. After creating a zone configuration, you must explicitly enable it for it to take effect. For information on enabling the configuration, refer to “Enabling zone configurations”...
Page 145: Renaming Zone Configurations
Zone configuration and zoning database management 5. Click the right arrow to add a configuration member or the left arrow to remove a configuration member. 6. Select Zoning Actions > Save Config to save the configuration changes. Renaming zone configurations The new name cannot exceed 64 characters and can contain alphabetic, numeric, and underscore characters.
Page 146: Enabling Zone Configurations
Zone configuration and zoning database management NOTE You cannot delete a enabled configuration. 1. Open the Zone Administration window as described in “Opening the Zone Admin window” page 104. 2. Select the Zone Config tab. 3. Select the configuration you want to delete from the Name list and click Delete. 4.
Page 147: Displaying Enabled Zone Configurations
Zone configuration and zoning database management The Disable Config warning message displays. 3. Click Yes to save and disable the current configuration. Displaying enabled zone configurations The enabled zone configuration screen displays the actual content of the single zone configuration that is currently enabled on the fabric, whether it matches the configuration that was enabled when the current Zone Admin session was launched or last refreshed.
Page 148: Adding A Wwn To Multiple Aliases And Zones
Zone configuration and zoning database management 2. To identify the most recently effective zone configuration without saving or applying any changes you made in the Zone Administration window, select Print > Print Effective Zone Configuration in the Zone Administration window. NOTE If no zone is enabled, a message displays, indicating that there is no active zoning configuration on the switch.
Page 149: Replacing A Wwn In Multiple Aliases And Zones
Zone configuration and zoning database management 4. Click items in the list to select or unselect, and click Delete to delete the WWN from all the selected zoning elements. The WWN is deleted from the selected items in the Zone Admin buffer. Replacing a WWN in multiple aliases and zones This procedure enables you to replace a WWN throughout the Zone Admin buffer.
Page 150: Clearing The Zoning Database
Best practices for zoning Clearing the zoning database Use the following procedure to disable the active zoning configuration, if one exists, and delete the entire zoning database. You must disable any active configuration before you can delete the zoning database. ATTENTION This action not only disables zoning on the fabric, but also deletes the entire zoning database.
Page 151: Working With Diagnostic Features
Chapter Working with Diagnostic Features In this chapter • Trace dumps ..........123 •...
Page 152: How A Trace Dump Is Used
Trace dumps How a trace dump is used The generation of a trace dump causes a CRITICAL message to be logged to the system error log. When a trace dump is detected, issue the supportSave command on the affected switch. This command packages all error logs, the supportShow output, and trace dump, and moves these to your FTP server.
Page 153: Disabling Automatic Trace Uploads
Displaying switch information 5. Click Apply. Disabling automatic trace uploads If automatic uploading of a trace dump is disabled, you must manually upload the trace dump or else the information is overwritten when a subsequent trace dump is generated. To disable automatic trace uploads, perform the following steps. 1.
Page 154: Viewing Detailed Fan Hardware Status
Displaying switch information Viewing detailed fan hardware status The icon on the Fan button indicates the overall status of the fans. For more information about the switch fan, refer to the appropriate hardware documentation. You can display status information about the fans, as shown in Figure FIGURE 29 Fan States window...
Page 155: Viewing The Power Supply Status
Displaying switch information The detailed temperature sensor states for the switch are displayed, as shown in Figure Viewing the power supply status The icon on the Power button indicates the overall status of the power supply status. For more information regarding switch power modules, refer to the appropriate hardware documentation. FIGURE 30 Power States window To view the power supply status, perform the following steps.
Page 156: Defining Switch Policy
Defining Switch Policy FIGURE 31 Switch Report window To check the physical health of the switch, perform the following steps. 1. Select a logical switch from the Logical Switch drop-down list in the top-right corner of the Switch Explorer window. The selected switch displays in the Switch View.
Page 157 Defining Switch Policy Use this dialog box to set policy parameters for calculating the overall status of the switch. The policy parameter values determine how many failed or faulty units of each contributor are allowed before triggering a status change in the switch from “Healthy” to “Marginal” or “Down”. The existence of policies such as WWN, CP, and Blade might differ from platform to platform.
Page 158: Port Led Interpretation
Port LED interpretation Port LED interpretation Switch View displays port graphics with blinking LEDs, simulating the physical appearance of the ports. One of the LEDs indicates port status; the other indicates port speed. For LED information, refer to the hardware documentation for the switch you are viewing. (The blink rate of the LEDs in the Switch View does not necessarily match the blink rate of the LEDs on the physical switch.) NOTE...
Page 159: Using The Fc-Fc Routing Service
Chapter Using the FC-FC Routing Service In this chapter • Fibre Channel Routing overview ........131 •...
Page 160: Supported Switches For Fibre Channel Routing
Supported switches for Fibre Channel Routing VEX-Port A virtual port that enables routing functionality through an FCIP tunnel. A VEX-Port is similar to an EX-Port. A device is shared between: • The backbone fabric and edge fabric 1 • Edge fabric 1 and edge fabric 2 •...
Page 161: Fc-Fc Routing Management
FC-FC routing management FC-FC routing management You can perform Fibre Channel Routing operations using Web Tools, Web Tools with the EGM license, and Integrated Routing license. You can manage FC-FC Routing through the FC Routing module. The FC Routing module has tabbed panes that display EX-Ports, LSAN fabrics, LSAN zones, LSAN devices, and general FCR information.
Page 162: Viewing And Managing Lsan Fabrics
Viewing EX-Ports 1. Select a logical switch from the Logical Switch drop-down list in the top-right corner of the Switch Explorer window. The selected switch displays in the Switch View. 2. Click Configure > FCR. The FC Routing module displays. If FC-FC Routing is disabled, a message to that effect displays on all the tabs in the module.
Page 163: Configuring An Ex-Port
Configuring an EX-Port • Enable or disable trunking • Configure router port cost ATTENTION During EX-Port configuration, the port is automatically disabled, and then re-enabled when the changes are applied. Be sure that you do not physically connect a port to a remote fabric before configuring it as an EX-Port;...
Page 164: Configuring Fcr Router Port Cost
Configuring FCR router port cost NOTE If you decide to configure a disabled port, the wizard provides the Enable Port after configuration check box. If you select this check box, the disabled port is automatically enabled after configuration. If you leave this box cleared, the port remains in the same state after configuration.
Page 165: Configuring The Backbone Fabric Id
Configuring the backbone fabric ID Click the Physical Devices or Proxy Devices element in the tree to see a detailed list of the physical or proxy devices. Click the device name in the tree for more detailed information about a specific device.
Page 166 Configuring the backbone fabric ID Web Tools Administrator’s Guide 53-1002756-01...
Page 167: Using The Access Gateway
Chapter Using the Access Gateway In this chapter • Access Gateway overview ........139 •...
Page 168: Access Gateway Mode
Access Gateway mode FIGURE 33 Switch Explorer view for Access Gateway mode The Access Gateway mode Switch Explorer is divided into the following areas: • Menu bar • Switch View buttons • Switch View, Port Admin, and Access Gateway Devices tabs •...
Page 169: Restricted Access In The Port Admin Tab
Enabling Access Gateway mode Restricted access in the Port Admin tab When Access Gateway mode is enabled, the following options can be configured in access gateway mode: • Port Configuration Policy — You can select Auto or Advanced mode (default mode). When auto mode is selected, options like Trunking, Configure N-Port Groups, Configure F-N Port Mappings, and N Port configuration are disabled.
Page 170: Disabling Access Gateway Mode
Disabling Access Gateway mode 4. Click Enable in the Access Gateway Mode section. 5. Click Apply. 6. Click Yes to restart the switch in Access Gateway mode. Disabling Access Gateway mode To disable Access Gateway mode, perform the following steps. 1.
Page 171: Creating Port Groups
Port configuration Creating port groups You can group a number of N_Ports (and its mapped F_Ports) together to connect to multiple independent fabrics or to create performance optimized ports. To group a number of ports, you must create a new port group and assign desired N_Ports to it. The N_Port grouping option is enabled by default, and all N_Ports are members of a default port group 0 (pg0).
Page 172: Deleting Port Groups
Port configuration Upon selecting the Login Balancing check box, the F Port Auto Rebalancing and N-Port Auto Rebalancing check boxes and Manual Balancing button become enabled. 6. Click Failover Enable. A confirmation dialog box displays. Click Yes to enable failover to all the ports in the port group or click No if you do not want to enable failover.
Page 173: Defining Custom Static F-N Port Mapping
Port configuration 4. Select the Primary Mappings subtab on the right side of the dialog. 5. In the Primary Mappings area, select ports and use the Add (right arrow) button to map F_Ports or U_Ports to N_Ports. 6. Optional: Use the Remove (left arrow) button to delete an F_Port mapping from an N_Port. Optional: Define a secondary N_Port in the Secondary Failover Mappings area, by selecting the ports using the Add and Remove buttons to set up the secondary mappings.
Page 174: Access Gateway Policy Modification
Access Gateway policy modification 6. Optional: Expand the port in the right page and select the WWN and then use the Remove (left arrow) to remove the mapping. Optional: Define a failover in the Secondary Failover Mappings area, by selecting the ports using the Add and Remove buttons to set up the secondary mappings.
Page 175 Access Gateway policy modification NOTE When port configuration is in auto mode, the Configure N port groups, Configure F-N port mapping, and Configure WWN-N port mapping buttons are disabled. To enable auto rebalancing from the Switch Administration window, perform the following steps. 1.
Page 176: Access Gateway Limitations On The Brocade 8000
Access Gateway limitations on the Brocade 8000 • Click Manual Balancing and a confirmation dialog box displays. Click Yes to change F Port-N Port Mapping or click No to cancel the changes. Click Apply to apply the changes. Access Gateway limitations on the Brocade 8000 The following list the is a compilation of the limitations of using Access Gateway with the Brocade 8000 switch: •...
Page 177: Administering Fabric Watch
Chapter Administering Fabric Watch In this chapter • Fabric Watch overview......... . 149 Fabric Watch overview Fabric Watch is an optional Brocade licensed feature that monitors the performance and status of switches.
Page 178 Fabric Watch overview Web Tools Administrator’s Guide 53-1002756-01...
Page 179: Administering Extended Fabrics
Chapter Administering Extended Fabrics In this chapter • Extended link buffer allocation overview ......151 •...
Page 180 Extended link buffer allocation overview • Buffer Needed—The number of buffers needed. You can edit the buffer needed for LD and LS modes. When you change Buffer Needed value, Frame Size and Desired Distance(km) value cannot be changed. • Buffer Allocated—The number of buffers actually allocated. •...
Page 181 Extended link buffer allocation overview FIGURE 35 Extended Fabric tab For the Brocade DCX, DCX-4S, DCX 8510-4, and DCX 8510-8 the slots for CPs are not available. The Brocade Encryption Switch and the FS8-18 Encryption blade support auto-negotiated link speeds of 1, 2, 4, and 8 Gbps. TABLE 15 Long-distance settings and license requirements Value...
Page 182: Configuring A Port For Long Distance
Configuring a port for long distance TABLE 15 Long-distance settings and license requirements (Continued) Value Description Extended Fabrics License Required? Dynamic setting is enabled. Buffer credits for the given E_Port are dynamically configured based on the actual link distance, as long as this is less than the desired distance.
Page 183 Configuring a port for long distance • If the port capability is 4 GB, type a number between 10 and 125, inclusive. • If the port capability is 2 GB, type a number between 10 and 250, inclusive. • If the port capability is 1 GB, type a number between 10 and 500, inclusive. •...
Page 184 Configuring a port for long distance Web Tools Administrator’s Guide 53-1002756-01...
Page 185: Routing Traffic
Chapter Routing Traffic In this chapter • Routing overview ..........157 •...
Page 186: Viewing Fabric Shortest Path First Routing
Viewing fabric shortest path first routing FIGURE 36 Routing tab Viewing fabric shortest path first routing The Routing tab of the Switch Administration window displays information about routing paths. To view the fabric shortest path first routing, perform the following steps. 1.
Page 187: Configuring Dynamic Load Sharing
Configuring dynamic load sharing Configuring dynamic load sharing The exchange-based routing policy depends on the Fabric OS dynamic load sharing feature (DLS) for dynamic routing path selection. When this policy is in force, DLS is always enabled and cannot be disabled. When the port-based policy is in force, you can enable DLS to optimize routing.
Page 188: Specifying Frame Order Delivery
Specifying frame order delivery You can enable this loss less feature from WT. If you try to enable loss less when DLS is OFF, an error message displays. To enable or disable loss less DLS, perform the following steps. 1. Open the Switch Administration window as described in “Opening the Switch Administration window”...
Page 189 Configuring the link cost for a port Every ISL has a default cost that is inversely proportional to its bandwidth. Use this procedure to set a non-default, “static” cost for any port. 1. Open the Switch Administration window as described in “Opening the Switch Administration window”...
Page 190 Configuring the link cost for a port Web Tools Administrator’s Guide 53-1002756-01...
Page 191: Configuring Standard Security Features
Chapter Configuring Standard Security Features In this chapter • User-defined accounts ......... 163 •...
Page 192: Virtual Fabrics Considerations
User-defined accounts The User tab of the Switch Administration window (Figure 37 on page 165) displays account information. You can create and manage accounts depending on your role. The roles and permissions are listed in Table TABLE 16 User role and permissions Role Permissions admin...
Page 193: Viewing User Account Information
User-defined accounts FIGURE 37 User tab Viewing user account information To view user account information, perform the following steps. 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the User tab. A list of the default and user-defined accounts displays.
Page 194 User-defined accounts FIGURE 38 Add User Account dialog box (VF) 4. Enter the user name. The user name must begin with an alphabetic character. The name can be up to 40 characters long. It is case-sensitive and can contain alphabetic and numeric characters, the dot (.) and the underscore (_).
Page 195: Deleting User-Defined Accounts
User-defined accounts Selecting All makes the target user account a physical fabric administrator. 11. Select a home logical fabric ID if Virtual Fabrics are enabled. The default home logical fabric ID is 128. 12. For Virtual Fabrics environments, select a Chassis Role. The chassis role determines the RBAC role and permissions of the user for performing all chassis-level operations in all logical fabrics.
Page 196: Maintaining Passwords
User-defined accounts You can change the description only on user-level accounts. You cannot change the description of the default accounts. You cannot change the description of your own account. Click Enabled or Disabled to enable or disable the account. You can enable and disable user- and admin-level accounts, but not your own account. You cannot enable or disable your own account or the factory account.
Page 197 User-defined accounts The Set User Account Password dialog box displays. 5. Enter the current password of the account. This step is required only if you are changing the password of your own or a peer admin account. 6. Enter the new password of the account. The new password must have at least one character different from the old password.
Page 198: User-Defined Roles
User-defined roles 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the User tab. 3. Select the account. 4. Click Expire Password. If the button is unavailable, the password is already expired. 5.
Page 199: Creating A User-Defined Role
User-defined roles • In order for the user-defined role to be able to edit the Port Admin and FCR configuration, you must assign the RBAC_SwitchPortManagement and RBAC_SwitchPortConfiguration RBAC classes to the role. • In order for the user-defined role to be able to set the Fabric ID, you must assign the RBAC_FabricRouting and RBAC_SwitchConfiguration RBAC classes to the role.
Page 200: Editing A User-Defined Role
User-defined roles FIGURE 39 Switch Admin:Add User Defined Role dialog 5. Enter a role name in the Name field. 6. Enter a description of the role in the Description field. To grant the role a read/write privilege, select the privilege and click the right-arrow next to the Read &...
Page 201: Access Control List Policy Configuration
Access control list policy configuration The Switch Admin:Edit User Defined Role dialog box displays. FIGURE 40 Switch Admin:Add User Defined Role dialog 6. To grant the role a read/write privilege, select the privilege and click the right-arrow next to the Read &...
Page 202: Virtual Fabrics Considerations
Access control list policy configuration Virtual Fabrics considerations ACL policies can be implemented at the logical switch/logical fabric level. Creating an SCC, DCC, or FCS policy You can create the FCS policy only once. To create an SCC, DCC, or FCS policy, perform the following steps. 1.
Page 203: Deleting All Scc, Dcc, Or Fcs Policies
Access control list policy configuration 8. Select a switch or highlight multiple switches to add to the policy by clicking Add or Add All. 9. Select a switch or highlight multiple switches to remove a policy by clicking Remove. 10. Click Next and click Finish to confirm the changes to the switch. Deleting all SCC, DCC, or FCS policies You cannot delete the FCS policy from non-primary or non-FCS switches.
Page 204: Moving An Fcs Policy Switch Position
Access control list policy configuration 4. Click Distribute Policy. 5. Select the switches that will receive the policy. 6. Select OK. If the policy distribution fails, an error dialog box displays. Moving an FCS policy switch position You can move the position of a primary switch in the FCS policy list. To move an FCS policy switch position, perform the following steps.
Page 205: Fabric-Wide Consistency Policy Configuration
Fabric-Wide Consistency Policy configuration 3. Select the Security Policies tab to configure the ADS policy in Access Gateway mode. 4. Select the ADS option. 5. Select the Enable ADS Policy option. The Configure Advanced Device Security Port WWN table displays. 6.
Page 206: Authentication Policy Configuration
Authentication policy configuration 8. Click Close. Authentication policy configuration You can configure an authentication protocol policy for E_Port and F_Port authentication, and then distribute the authentication policy to other switches in the fabric. You can also set shared secret keys. Configuring authentication policies for E_Ports To configure authentication policies for E_Ports, perform the following steps.
Page 207: Distributing Authentication Policies
Authentication policy configuration 5. Set the switch authentication mode to either off or passive and click Apply. Distributing authentication policies Authentication policies are distributed only if all the selected switches accept the distribution. Only the policy mode is distributed to the selected switches. The switch initiating the distribution must accept distribution.
Page 208: Modifying A Shared Secret Key Pair
SNMP configuration 6. Enter the Switch or HBA WWN, name, or domain ID, or use the Browse button to select a switch. In the Peer Secret and Confirm Peer Secret fields, enter the peer secret value. 8. In the Local Secret and Confirm Local Secret fields, enter the local secret value. 9.
Page 209: Changing The Systemgroup Configuration Parameters
SNMP configuration 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the SNMP tab. 3. Select a trap level for a recipient from the corresponding Trap Level menu in the SNMPv1 and SNMPv3 sections.
Page 210: Changing The Access Control Configuration
RADIUS management 3. Select a user name from the User Name menu in the SNMPv3 section. NOTE The list is scrollable. If you do not see your user name, scroll down using the scroll bar or by clicking the User Name heading. 4.
Page 211: Enabling And Disabling Radius
RADIUS management The following are the three choices in the drop-down menu when RADIUS is selected as the primary service: • Switch Database when RADIUS Authentication Fails—When selected, the switch user login database is checked whenever RADIUS authentication fails. • Switch Database When RADIUS Times Out—Switch user login database is checked only if the physical connection to the RADIUS server fails.
Page 212: Modifying The Radius Server
RADIUS management You can configure RADIUS even if it is disabled. You can configure up to five RADIUS servers. You must be logged in as admin, switchadmin, or securityadmin to configure RADIUS. To configure RADIUS, perform the following steps.. 1. Open the Switch Administration window as described in “Opening the Switch Administration window”...
Page 213: Modifying The Radius Server Order
Active Directory service management Modifying the RADIUS server order The RADIUS servers are contacted in the order they are listed, starting from the top of the list and moving to the bottom. To modify the RADIUS server order, perform the following steps. 1.
Page 214: Modifying Active Directory Service
Active Directory service management 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the AAA Service tab. 3. To enable Active Directory service, select Active Directory from the Primary AAA Service menu. 4.
Page 215: Tacacs+ Management
TACACS+ management TACACS+ management TACACS+ provides user authentication and authorization using TACACS as authentication protocol. You can add, remove, and modify settings of TACACS+ Server. Enabling and disabling TACACS+ At least one TACACS+ server must be configured before you can enable TACACS+. To enable or disable TACACS+, perform the following steps.
Page 216: Removing Tacacs
IPsec concepts 1. Open the Switch Administration window as described in “Opening the Switch Administration window” on page 31. 2. Select the AAA Service tab. 3. Select a server from the TACACS+ Configuration list. 4. Click Modify. The RADIUS/ADLDAP/TACACS+ Configuration dialog box displays. 5.
Page 217: Transport Mode And Tunnel Mode
IPsec concepts There are several protocols and algorithms that can be applied. Choosing the protocols and algorithms you want to use may be a matter of adapting to an implementation that is already in place in your LAN, or you may need to do a significant amount of research and planning. The supported protocols and algorithms are defined and described in the RFCs listed in Table TABLE 17...
Page 218: Ipsec Header Options
IPsec concepts FIGURE 41 Transport mode and tunnel mode comparison IPsec header options IPsec adds headers to an IP datagram to enable authentication and privacy. There are two options: • Authentication Header (AH) • Encapsulating Security Payload (ESP) Authentication Header AH can be used to authenticate a data stream, but does not provide encryption needed for privacy.
Page 219: Basic Ipsec Configurations
IPsec concepts Encapsulating Security Payload ESP provides authentication, and also provides privacy by encrypting the IP datagram. The use of an ESP header is similar to the use of the AH header. A hash algorithm is used to calculate an authentication value, the authentication value is sent in an IP datagram, and the same hash algorithm is used by the receiver to verify the authentication value.
Page 220: Internet Key Exchange Concepts
IPsec concepts Gateway to Gateway In a gateway to gateway configuration, IPsec protection is implemented between network nodes. Tunnel mode is commonly used in a gateway to gateway configuration. A tunnel endpoint represents a set of IP addresses associated with actual endpoints that use the tunnel. IPsec is transparent to the actual endpoints.
Page 221 IPsec concepts Hash algorithms Hash message authentication codes (HMAC) check data integrity through a mathematical calculation on a message using a hash algorithm combined with a shared, secret key. Table 19 lists the available encryption algorithms. The sending computer uses the hash function and shared key to compute a checksum or code for the message, and sends it to the receiving computer.
Page 222: Ipsec Over Management Ports
IPsec over management ports DH group choices are 1(modp768), 2(modp1024), 14(modp2048), and 18(modp8192). Each group provides an incrementally more secure key exchange by providing more bits (768, 1024, 2048, 8192). Authentication methods The methods used to authenticate the IKE peer are preshared key (psk), DSS digital signature (dss), and RSA digital signature (rsasig): •...
Page 223: Establishing An Ike Policy
IPsec over management ports 1. Open the Switch Administration window. 2. Select Show Advanced Mode. 3. Select the Security Policies tab. 4. Under Security Policies, select Ethernet IPsec. The Ethernet IPsec Policies screen displays. 5. Ethernet IPsec policies can be configured only after enabling IPsec by clicking the Enable button below the Ethernet IPsec policies table.
Page 224: Creating An Sa Proposal
IPsec over management ports To create a security association, perform the following steps. 1. Select the IPsec tab. The IPsec Policies screen displays. 2. Select the SA tab. 3. Select Add. The Add SA dialog box displays. 4. Enter a name for the SA in the SA Name field. 5.
Page 225: Adding An Ipsec Transform Policy
IPsec over management ports The SA lifetime may be defined as a time value in seconds (LifeTime in seconds), as the number of bytes transmitted before the SA is rekeyed (LifeTime in bytes), or both. When both are used, the SA lifetime is determined by the threshold that is first reached. 6.
Page 226: Manually Creating An Sa
IPsec over management ports The Add Selector dialog box displays. 3. Enter a name in the Selector Name field. 4. Select the Traffic Flow Direction (in or out). IPsec policies are unidirectional, and must be applied separately to inbound and outbound flows.
Page 227: Editing An Ike Or Ipsec Policy
IPsec over management ports The choices are ah (for authentication header) and esp (for encapsulated security protocol). 10. Select the IPsec Protection Type option. 11. Select the Authentication Algorithm option. 12. Enter or copy a generated encryption key in the Encryption Key field. 13.
Page 228: Establishing Authentication Policies For Hbas
Establishing authentication policies for HBAs Establishing authentication policies for HBAs To establish and enable authentication policies for HBAs as the log in to a fabric, perform the following steps. 1. Open the Switch Administration window. 2. Click Show Advanced Mode. 3.
Page 229: Administering Ficon Cup Fabrics
Chapter Administering FICON CUP Fabrics In this chapter • FICON CUP fabrics overview ........201 •...
Page 230: Enabling Port-Based Routing
Enabling port-based routing • Install a FICON CUP license on the Brocade switch. • Configure CUP attributes (FMS parameters) for the FICON director. FMS mode enable failed due to ports with areas 0xFE or 0xFF are connected to devices. You can use Web Tools for all of these tasks. You can also use Web Tools to manage FICON directors (when FMS mode is enabled on those directors) to do the following: •...
Page 231: Enabling Or Disabling Ficon Management Server Mode
Enabling or disabling FICON Management Server mode Enabling or disabling FICON Management Server mode FICON Management Server (FMS) is used to support switch management using CUP. To be able to use the CUP functionality, all switches in the fabric must have FICON Management Server mode (FMS mode) enabled.
Page 232: Configuring Fms Mode Parameters
FMS parameter configuration TABLE 20 FMS mode parameter descriptions Parameter Description Programmed Controls whether host programming is allowed to set the switch offline. The parameter is set Offline State as enabled by the hardware after system installation, and can be reset by Web Tools. Control Active=Saved Controls the IPL file update.
Page 233: Displaying Code Page Information
Displaying code page information 3. Select the FICON CUP tab. The FICON CUP page displays the FICON Management Server page. All attributes on this page are read-only until FMS mode is enabled. 4. To enable or disable an FMS mode parameter, click the check box next to the parameter. A checked check box indicates that the parameter is enabled.
Page 234: Allow / Prohibit Matrix Configuration
Allow / Prohibit Matrix configuration • Mode Register • Port Names (also called Port Address Name) • Allow/Prohibit Matrix and Port Connectivity Attributes • Switch enable/disable • Switch name change To access the FICON CUP tab, perform the following steps. 1.
Page 235: Viewing Allow / Prohibit Matrix Configurations
Allow / Prohibit Matrix configuration The Port Connectivity table (shown in Figure 45 on page 209) displays the Port number (in physical-location format), Port Name (port address name), Block attribute, Prohibit attribute, and Area Id (port address, displayed in hexadecimal) in fixed columns. The right side is a port matrix, that lists all ports by Area ID and identifies prohibited ports.
Page 236 Allow / Prohibit Matrix configuration The Allow / Prohibit Matrix Configuration dialog box displays all ports and port names on the selected switch (similar to the dialog box shown in Figure 45). The Block column, Prohibit column, and prohibited ports matrix are displayed as empty, for you to configure. •...
Page 237: Activating An Allow / Prohibit Matrix Configuration
Allow / Prohibit Matrix configuration FIGURE 45 Allow / Prohibit Matrix Configuration dialog box Activating an Allow / Prohibit Matrix configuration When you activate a saved Allow / Prohibit Matrix configuration on the switch, the preceding configuration (currently activated) is overwritten. To activate an Allow / Prohibit Matrix configuration, perform the following steps.
Page 238: Deleting An Allow / Prohibit Matrix Configuration
CUP logical path configuration 3. Click Copy. The Allow / Prohibit Matrix Configuration dialog box displays. 4. In the dialog box, enter a name and description for the new configuration and click OK to save the configuration to the target file; click Cancel to cancel copying the configuration. The file name must be in alphanumeric characters and can contain only dashes or underscores as special characters.
Page 239: Link Incident Registered Recipient Configuration
Link Incident Registered Recipient configuration The FICON CUP page displays the FICON Management Server page in front. All attributes on this page are read-only until FMS mode is enabled. 5. Click the CUP Logical paths subtab. 6. Select a logical path and click Set Current. Link Incident Registered Recipient configuration The Link Incident Registered Recipient (LIRR) receives Link Incident Reports (RLIR) on the source N_Port.
Page 240: Displaying Request Node Identification Data
Displaying Request Node Identification Data Displaying Request Node Identification Data Web Tools displays Request Node Identification Data (RNID) information for the local switch, and for attached FICON devices and FICON channel paths. RNID information for the switch displays in the Switch Information tab (Figure 46).
Page 241: Configuring Fcoe With Web Tools
Chapter Configuring FCoE with Web Tools In this chapter • Web Tools and FCoE overview ........213 •...
Page 242: Web Tools, The Egm License, And Brocade Network Advisor
Web Tools, the EGM license, and Brocade Network Advisor A limited set of features is accessible using Web Tools without a license, and is available free of charge. Additional switch management features are accessible using Web Tools with the Enhanced Group Management (EGM) license.
Page 243: Switch Administration And Fcoe
Switch administration and FCoE Switch administration and FCoE The DCB tab on the Switch Administration window is specific to DCE and DCB configuration and management. The DCB tab has five subtabs (Figure 47) that are used for FCoE switch administration: •...
Page 244: Editing The Dcb Map
Quality of Service configuration • You can edit the DCB map. The DCB map defines priority and priority group tables that support Enhanced Transmission Selection (ETS). ETS allows allocation of bandwidth to different traffic classes. DCB maps also allow you to enable Priority Flow Control (PFC). •...
Page 245: Lldp-Dcbx Configuration
LLDP-DCBX configuration 1. Select the DCB tab on the Switch Administration window. 2. Select the QoS tab. 3. Select the Traffic Class Map tab. 4. Select Add. The Traffic Class Map Configuration dialog box displays. NOTE This dialog box has the same structure as the Priority Group Map in the DCB Configuration dialog box.
Page 246 LLDP-DCBX configuration The Hello value sets the interval between hello bridge protocol data units sent by the root switch configuration messages. The range of valid values is from 4 to 180 seconds. The default is 30 seconds. 9. In the Multiplier field, set the number of consecutive misses allowed before LLDP considers the interface to be down.
Page 247: Adding An Lldp Profile
LLDP-DCBX configuration Adding an LLDP profile The LLDP profile determines LLDP settings per port. To add an LLDP profile, perform the following steps. 1. Select the DCB tab on the Switch Administration window. 2. Select the LLDP-DCBX tab. 3. Select the LLDP Profile tab. 4.
Page 248: Configuring Dcb Interfaces
Configuring DCB interfaces • management-address—The IP address of the management port on the 8000 switch. Advertise dot1-tlv—Advertises to any attached device to send IEEE 802.1 LLDP type, length, and values. Advertise dot3-tlv—Advertises to any attached device to send IEEE 802.3 LLDP type, length, and values.
Page 249: Configuring A Link Aggregation Group
Configuring a link aggregation group 8. Enter the profile name in the LLDP-DCBX Profile field for using a specific profile for the interface. 9. In the FC0E Priority Bits field, enter a value that indicates the desired user priority. Each bit represents a user priority that is associated with FCoE traffic.
Page 250: Configuring Vlans
Configuring VLANs The L2 mode setting determines operation within a VLAN: Access mode allows only one VLAN association, and all frames are untagged. Trunk mode allows more than one VLAN association, and allows tagged frames. 9. Select the operational Status. The choices are Administratively Up and Administratively Down.
Page 251: Configuring Fcoe Login Groups
Configuring FCoE login groups NOTE The FCoE check box is selected by default for FCoE VLAN. The FCoE check box is read-only, you must use the CLI to make any changes to the FCoE VLAN. 11. Click OK to enable FCoE. Clear the check box to disable FCoE. Configuring FCoE login groups FCoE login groups control which FCoE devices are allowed to log in to a switch or fabric.
Page 252: Displaying Lag Information
Displaying LAG information 1. Select the FCoE Ports tab on the Port Admin tab. The initial view displays a summary of all FCoE ports on the switch (Figure 48). FIGURE 48 FCoE Ports tab, Port Administration panel 2. To view information for a specific port, select the trunk in the FC E Ports Explorer or select the port in the FCoE Port Configuration and Management table and click View Details.
Page 253: Displaying Vlan Information
Displaying VLAN information Displaying VLAN information To display VLAN information, perform the following steps. 1. Select the DCB tab on the Switch Administration window. 2. Select the VLAN tab. The VLAN information displays. Displaying FCoE login groups To display FCoE login group information, perform the following steps. 1.
Page 254: Configuring A Dcb Interface From The Switch View
Configuring a DCB interface from the Switch View • Toggle between showing Absolute Values or Delta Values (values that have changed since the last data collection). • Use the Clear Counters button to clear the counters in port statistics. • Change the retrieval interval.
Page 255: Enabling And Disabling Lldp
Enabling and disabling LLDP 3. Click Add. The LAG Configuration dialog box displays. 4. Change the Status to Administratively Up or Administratively Down. Enabling and disabling LLDP To enable or disable LLDP on a DCB interface, perform the following steps. 1.
Page 256 Enabling and disabling FCoE ports Web Tools Administrator’s Guide 53-1002756-01...
Page 257: General Web Tools Limitations
Chapter Limitations In this chapter • General Web Tools limitations ........229 General Web Tools limitations Table 21 lists general Web Tools limitations that apply to all browsers and switch platforms.
Page 258 General Web Tools limitations TABLE 21 Web Tools limitations (Continued) Area Details Firmware download There are multiple phases to firmware download and activation. When Web Tools reports that firmware download completed successfully, this indicates that a basic sanity check, package retrieval, package unloading, and verification was successful. Web Tools forces a full package install.
Page 259 General Web Tools limitations TABLE 21 Web Tools limitations (Continued) Area Details Loss of Connection Occasionally, you might see the following message when you try to retrieve data from the switch or send a request to the switch: Switch Status Checking The switch is not currently accessible.
Page 260 General Web Tools limitations TABLE 21 Web Tools limitations (Continued) Area Details Refresh option in If you change the switch name using the Web Tools Switch Administration page or browsers SNMP and then open a Telnet window to verify the name change, the CLI prompt (for example, switch:admin >) displays the previous name.
Page 261 Index Numerics 2 domain/4 domain fabric licenses backbone fabric ID, configuring 7800 switch backing up configuration file basic performance monitoring graphs BB credit beaconing, enabling best practices for zoning Access Control List. Refer to ACL blades, enabling and disabling access control. Refer to RBAC. browsers Access Gateway mode limitations...
Page 262 configuring deleting Allow / Prohibit Matrix Allow / Prohibit Matrix configuration arbitrated loop parameters user accounts backbone fabric ID zone aliases default heap size zone configurations EX_Ports zones fabric parameters device probing FAN frame notification parameters devices only view FC ports devices only zoning FCR router cost disabling...
Page 263 enabling FCS policy Access Gateway mode activate automatic trace dump transfer create beaconing deactivate blades delete distribute FICON Management Server mode moving switch position insistent domain ID mode feature licenses ports FICON Management Server Ports on Demand mode, enabling and disabling RADIUS parameters RLS probing...
Page 264 installing media type Java Plug-in GigE message severity levels JRE patches on Solaris MetaSAN Solaris patches modifying Internet Explorer 7.0 performance graphs IOD, frame delivery RADIUS server IP address RADIUS server order filtering zone aliases ISL trunking zone configurations zones monitoring performance mouse over information Java Plug-ins...
Page 265 polling rates removing port menu licenses RADIUS server port names, assigning zone alias members port speed, configuring zone configuration members port swapping zone members port type, configuring renaming port-based routing zone aliases ports zone configurations buffer-limited zones configuring replacing a WWN in zoning database disabling requirements, Web Tools enabling...
Page 266 switch viewing 7800 EX_Ports changing the name of LSAN devices enabling and disabling LSAN fabrics mouse over information LSAN zones rebooting swapped ports Switch Administration window Switch Explorer switch status opening viewing FCR router cost Switch Events and Switch Information virtual channel settings, configuring switch events, displaying switch name, changing...
Page 267 zones about adding WWNs best practices creating deleting description LSAN modifying removing WWNs renaming replacing WWNs selecting a view zoning all access default zoning no access zoning database clearing maximum size zoning views zoning, disabling zoning, saving changes Web Tools Administrator’s Guide 53-1002756-01...
Page 268 Web Tools Administrator’s Guide 53-1002756-01...
