Scenario 2: A Professional Office
Other System Features and Applications. Direct Voice Mail feature,
password-protected voice and fax mail services (AUDIX Voice Power and
Fax Attendant, Integrated Solutions); Integrated Administration; Remote
Access (with barrier codes) for partners to access the system from off-
site; PassageWay Direct Connect Solution for MLX-10DP and MLX-16DP
users. The Remote Call Forward feature for associates to forward calls to
their cellular phones.
Other system equipment includes an Uninterruptible Power Supply (UPS) to
supply backup power in the event of a commercial power failure.

Equipment

This section describes the system equipment used to meet the staff members'
needs. Included are the types of telephones and adjuncts.
The system includes the following telephones for staff members, as well as in
common areas:
MLX-20L telephones for all partners for maximum functionality and for the
Queued Call Console (QCC) operator console for operator/receptionist
MLX-28D telephones for executive secretaries to provide display screen,
maximum number of buttons (to include SSA button for each of the
partners' lines), and maximum functionality
MLX-16DP telephones for associates' secretaries
MLX-10DP telephones for associates, paralegals, as well as some
bookkeeping and word processing pool members; used in some cases
with the custom PassageWay Direct Connect Solution applications
Single-line telephones for reception, word processing, and bookkeeping
areas
The following adjuncts are included in the system:
Group IV and analog (slower speed) fax machines
ExpressRoute 1000 ISDN Terminal Adapters for high-speed data
communications by fax, PC, or videoconferencing system
PictureTel 4000 videoconferencing system for use by partners and
associates in meeting with key clients
Modems and fax/modem for office/system manager
Direct Station Selector (DSS) for office/system manager and Queued Call
console (QCC) operator/receptionist
Headset for QCC operator/receptionist
Recording machine for executive secretaries
