Making and Receiving Data Calls

Calling with Analog Data Equipment

The instructions supplied with your
equipment may list the call progress
messages your modem uses.
Making Direct Data Calls
To Call Inside Analog
Stations
5-2
Calling with Analog Data Equipment
You can use analog data equipment to
call directly to another analog station
call through a modem pool
answer a data call
How you make data calls depends on the type of data station you are calling
and where it is located.
If your analog data station is connected to an analog multiline telephone via a
General Purpose Adapter (GPA), use your telephone dialpad to dial. If your
analog data station is connected to an MLX telephone via a Multi-Function
Module (MFM), or if you have an analog data-only station (connected directly to
a 012 or 008 OPT module), use your data terminal keyboard to dial (if your
modem supports a terminal).
Your data terminal screen may report the status of your call. The wording of call
progress messages depends on your modem and data communication software.
Use the following instructions
to call inside and outside analog data stations
to call the modem connected to a local host computer's communication ports
to call the modem connected to workstations on a local area network (LAN)
to call outside analog data stations including calls made over the regular
analog telephone network and calls to ISDN facilities (T1 or PRI)
To Call an Analog Multiline Telephone from an Analog Data Station
Connected via GPA:
Enter modem commands and dial the number using the telephone dialpad:
1. If the red light next to the Ring (ICOM or SA) button is not on, press the
FIeature button.
Note: The GPA must be in Auto Mode.
Lift the handset or press Speaker.
2.
Dial the extension for the analog data station or data hunt group you are
3.
calling.
4. When you hear a steady tone, a data connection has been made. Put your
modem in the interactive mode using the instructions provided with it.
Note: The data call is automatically private.
5. Use the instructions supplied with your modem and data communications
software to send data, receive data, and disconnect the call.
