Removing/Reinstalling the Control Unit Housing

Installing the Control Unit Housing

Installing the control unit's housing involves two tasks: installing the top cover
and then installing the front cover.
This section contains instructions for both tasks.
Installing the Top Cover
To install the top cover, see Figure E 2 and follow these steps:
1. Be sure the cords have been pressed through the wire managers at the
base of the modules.
2. Hold the top cover with the hooks facing you.
3. Engage the tabs at the rear of the top cover with the carrier.
4. Lower the top cover so the legs lock into the vents on the module.
