Programming from a PC with SPM
Console/Display Instructions
6 Press any key to display the SPM Main Menu shown below.
1
2
3
4
5
If the SPM Main Menu does not appear or if the information about the screen is
garbled, press any key again.
If the COMM PORT (communications port) screen appears instead of the SPM
Main Menu, the SPM software has not been initialized. See Chapter 2 of System
Programming.
NOTE:
The function keys shown on either side of the display are included here for quick
reference. On the PC screen, the system programming keys do not look like actual
keys.
7 To reach the System Programming menu, select
8 Perform the procedures contained in the task descriptions later in this chapter.

With a Local or Remote Modem Connection

The method you use to access SPM by modem depends on whether you are
programming on site (locally) or from a remote location.
If you are on site, the modem must be connected to a 012 or an 016
(Release 4.0 and later only) module on the control unit. To establish a
connection to the control unit's internal modem, dial
If you are at a remote location, do one of the following:
— Place a call to the system on a remote access line, enter the barrier
code (if required), and dial the code for the internal modem (
— Place a voice call to the system on a regular line and ask the operator
to transfer you to the modem (by dialing
modem answer tone, switch to data mode.

Modem Connections

You must make a data connection to a modem. The following modem dialing
commands work for most modems. These may not be the commands your
modem uses; refer to the user guide that came with your modem for specific
information.
6–20
Managing the System
Additional Information
6
7
8
9
0
by pressing 1.
.
).
). When you hear the
