Note: You can also select any configuration file as the start-up
configuration by using the System/File Management/Set Start-Up
page.

Figure 3-13. Setting the Startup Configuration Settings

CLI – Enter the IP address of the TFTP server, specify the source file on
the server, set the startup file name on the switch, and then restart the
switch.
Console#copy tftp startup-config
TFTP server ip address: 192.168.1.19
Source configuration file name: config-1
Startup configuration file name [] : startup
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#reload
To select another configuration file as the start-up configuration, use the
boot system command and then restart the switch.
Console#config
Console(config)#boot system config: startup-new
Console(config)#exit
Console#reload

Console Port Settings

You can access the onboard configuration program by attaching a VT100
compatible device to the switch's serial console port. Management access
through the console port is controlled by various parameters, including a
password, timeouts, and basic communication settings. These parameters
can be configured via the web or CLI interface.
B C
ASIC ONFIGURATION
4-84
4-90
4-30
3-29
