ONFIGURING THE
Web – Click VLAN, Private VLAN, Port Information or Trunk
Information.
CLI – This example shows the switch configured with primary VLAN 5
and community VLAN 6. Port 3 has been configured as a promiscuous
port and mapped to VLAN 5, while ports 4 and 5 have been configured as
host ports and associated with VLAN 6. This means that traffic for port 4
and 5 can only pass through port 3.
Console#show vlan private-vlan
Primary
--------
5
5
Console#

Configuring Private VLAN Interfaces

Use the Private VLAN Port Configuration and Private VLAN Trunk
Configuration menus to set the private VLAN interface type, and assign
the interfaces to a private VLAN.
Command Attributes
Port/Trunk - The switch interface.
PVLAN Port Type - Sets private VLAN port types.
- Normal – The port is not assigned in a private VLAN.
3-182
S
WITCH

Figure 3-78. Private VLAN Port Information

Secondary
-----------
----------
primary
6
community
Type
Interfaces
------------------------------
Eth1/ 3
Eth1/ 4 Eth1/ 5
4-57
