Ip Acls; Table 4-34 Ip Acl Commands - SMC Networks 6152L2 - annexe 1 Management Manual

C L
OMMAND INE
The following restrictions apply to ACLs:
• Each ACL can have up to 60 rules.
• This switch supports ACLs for ingress filtering only. However, you can
only bind one IP ACL to any port for ingress filtering. In other words,
only one ACL can be bound to an interface - Ingress IP ACL.
The order in which active ACLs are checked is as follows:
1. User-defined rules in the Ingress IP ACL for ingress ports.
2. Explicit default rule (permit any any) in the ingress IP ACL for ingress
ports.
3. If no explicit rule is matched, the implicit default is permit all.
Command Groups

IP ACLs

ACL Information
IP ACLs
Command
access-list ip
permit, deny
permit, deny
4-114
I
NTERFACE
Table 4-33 Access Control List Commands
Function
Configure ACLs based on IP addresses, TCP/
UDP port number, protocol type, and TCP control
code
Display ACLs and associated rules; shows ACLs
assigned to each port

Table 4-34 IP ACL Commands

Function
Creates an IP ACL and enters
configuration mode for standard or
extended IP ACLs
Filters packets matching a specified
source IP address
Filters packets meeting the specified
criteria, including source and
destination IP address, TCP/UDP port
number, protocol type, and TCP
control code
Page
4-114
4-123
Mode Page
GC 4-115
STD-ACL 4-116
EXT-ACL 4-117
