CLI – The following example enables LACP for ports 1 to 6. Just connect
these ports to LACP-enabled trunk ports on another switch to form a
trunk.
Console(config)#interface ethernet 1/1
Console(config-if)#lacp
Console(config-if)#exit
. .
.
Console(config)#interface ethernet 1/6
Console(config-if)#lacp
Console(config-if)#end
Console#show interfaces status port-channel 1
Information of Trunk 1
Basic information:
Port type: 1000T
Mac address: 22-22-22-22-22-2d
Configuration:
Name:
Port admin status: Up
Speed-duplex: Auto
Capabilities: 10half, 10full, 100half, 100full, 1000full,
Flow control status: Disabled
Port security: Disabled
Max MAC count: 0
Port security action: None
Current status:
Created by: Lacp
Link status: Up
Port operation status: Up
Operation speed-duplex: 1000full
Flow control type: None
Member Ports: Eth1/1, Eth1/2, Eth1/3, Eth1/4, Eth1/5, Eth1/6,
Console#

Configuring LACP Parameters

Dynamically Creating a Port Channel
Ports assigned to a common port channel must meet the following criteria:
Ports must have the same LACP System Priority.
Ports must have the same LACP port Admin Key.
However, if the "port channel" Admin Key is set (page 4-142), then the
port Admin Key must be set to the same value for a port to be allowed
to join a channel group.
Note: If the port channel admin key (lacp admin key, page 4-171) is
P
C
ORT
ONFIGURATION
4-146
4-166
4-153
3-119
