Web – Click Port, Port Configuration or Trunk Configuration. Modify the
required interface settings, and click Apply.
CLI – Select the interface, and then enter the required settings.
Console(config)#interface ethernet 1/13
Console(config-if)#description RD SW#13
Console(config-if)#shutdown
.
Console(config-if)#no shutdown
Console(config-if)#no negotiation
Console(config-if)#speed-duplex 100half
Console(config-if)#flowcontrol
.
Console(config-if)#negotiation
Console(config-if)#capabilities 100half
Console(config-if)#capabilities 100full
Console(config-if)#capabilities flowcontrol

Creating Trunk Groups

You can create multiple links between devices that work as one virtual,
aggregate link. A port trunk offers a dramatic increase in bandwidth for
network segments where bottlenecks exist, as well as providing a
fault-tolerant link between two devices. You can create up to six trunks at a
time.

Figure 3-50. Configuring Port Attributes

P C
ORT ONFIGURATION
4-146
4-146
4-151
4-148
4-147
4-150
4-149
3-113
