C L
OMMAND INE
map ip dscp (Interface Configuration)
This command sets IP DSCP priority (i.e., Differentiated Services Code
Point priority). Use the no form to restore the default table.
Syntax
map ip dscp dscp-value cos cos-value
no map ip dscp
• dscp-value - 8-bit DSCP value. (Range: 0-255)
• cos-value - Class-of-Service value (Range: 0-7)
Default Setting
The DSCP default values are defined in the following table. Note that
all the DSCP values that are not specified are mapped to CoS value 0.

Table 4-64 Mapping IP DSCP to CoS Values

IP DSCP Value
0
8
10, 12, 14, 16
18, 20, 22, 24
26, 28, 30, 32, 34, 36
38, 40, 42
48
46, 56
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP DSCP, and default
switchport priority.
• DSCP priority values are mapped to default Class of Service values
according to recommendations in the IEEE 802.1p standard, and
then subsequently mapped to the eight hardware priority queues.
• This command sets the IP DSCP priority for all interfaces.
4-230
I
NTERFACE
CoS Value
0
1
2
3
4
5
6
7
