C
ONFIGURING THE
Web – Click VLAN, Private VLAN, Information. Select the desired port
from the VLAN ID drop-down menu.
CLI – This example shows the switch configured with primary VLAN 5
and secondary VLAN 6. Port 3 has been configured as a promiscuous port
and mapped to VLAN 5, while ports 4 and 5 have been configured as a
host ports and are associated with VLAN 6. This means that traffic for
port 4 and 5 can only pass through port 3.
Console#show vlan private-vlan
Primary
--------
--------------------------------------
5
5
3-178
S
WITCH

Figure 3-75. Private VLAN Information

Secondary
----------- ----------
primary
6 community
Type Interfaces
Eth1/ 3
Eth1/ 4 Eth1/ 5
4-153
