SMC Networks 6608M INT User Manual

Tigerswitch 100 8-port fast ethernet switches
Hide thumbs Also See for 6608M INT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
TigerSwitch 100
User Guide
From SMC's Tiger line of feature-rich workgroup LAN solutions
March 1998
900.168 Rev. B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6608M INT and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks 6608M INT

Summary of Contents for SMC Networks 6608M INT

  • Page 1 TigerSwitch 100 User Guide From SMC’s Tiger line of feature-rich workgroup LAN solutions March 1998 900.168 Rev. B...
  • Page 2 TigerSwitch 100 8-port Fast Ethernet Switches Two models featuring either: Eight fixed Auto-Negotiating 100BASE-TX ports Two 4-port replaceable modules with 100BASE-TX and/or 100BASE-FX ports 1.6 Gbps internal bandwidth In-band and out-of-band management User Guide SMC6608T SMC6608M...
  • Page 3 All rights reserved. Printed in U.S.A. Trademarks: SMC is a registered trademark; and TigerSwitch, TigerStack, EZ Hub, EZ Switch and EliteFax are trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
  • Page 4 STANDARD WARRANTY SERVICE: Standard warranty service for hardware products may be obtained by delivering the defective product, accompanied by a copy of the dated proof of purchase, to SMC’s Service Center or to an Authorized SMC Service Center during the applicable warranty period. Standard warranty service for software products may be obtained by telephoning SMC’s...
  • Page 5 IMITED ARRANTY SMC with a Return Material Authorization (RMA) number marked on the out- side of the package, and sent prepaid, insured, and packaged appropriately for safe shipment. The repaired or replaced item will be shipped to Customer, at SMC’s expense, not later than thirty (30) days after receipt by SMC.

  • Page 6: Table Of Contents

    ABLE OF ONTENTS Compliances ............v About The TigerSwitch 100......1-1 TigerSwitch 100 Overview ..........Switch Architecture ............. 1-10 Management Options ............1-12 Key Features and Benefits..........1-13 Planning............2-1 Introduction to Switching ........... Sample Applications ............Installation............. 3-1 Selecting a Site ..............Equipment Checklist............

  • Page 7: Able Of

    ABLE OF ONTENTS Appendices Troubleshooting..........A-1 Switch Indicators..............Diagnostic Tests ..............System Diagnostics ............. Pin Assignments..........B-1 RJ-45 Pin Assignments ............Console Port Pin Assignments ........... Specifications ..........C-1 All Models ................SMC6608T................SMC6608M ................Glossary ............D-1...
  • Page 8 ABLE OF ONTENTS List of Figures 1-1. TigerSwitch 100T with 8 10BASE-T/100BASE-TX Ports (Model SMC6608T)............. 1-2. TigerSwitch 100M Base Unit........1-3. 4-Port Fast Ethernet Modules ........1-4. 10BASE-T/100BASE-TX Ports ........1-5. 100BASE-FX Ports ............1-6. Front Panel LEDs............1-7. Front Panel LED Arrays..........1-8.
  • Page 9 ABLE OF ONTENTS 4-8. Virtual LAN Configuration Screen ......4-18 4-9. System Information Screen........4-21 4-10. Port Status Screen............4-22 4-11. Statistics Screen ............4-23 4-12. Address Table Screen..........4-25 4-13. Spanning Tree Information Screen ......4-26 4-14. TFTP Download Screen..........4-28 4-15.
  • Page 10 EC Conformance Declaration SMC contact for these products in Europe is: SMC (Europe) Limited 1st Floor, Pyramid House, Easthampstead Road Bracknell, Berkshire RG12 1NS, United Kingdom This information technology equipment complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/336/EEC.

  • Page 11: Compliances

    : "Appareils Numériques", NMB-003 édictée par l’Industrie. Japan VCCI Class A Australia AS/NZS 3548 (1995) - Class A SMC contact for products in Australia is: SMC Communications Pty. Ltd. LVL 10, 201 Miller Street, North Sydney, NSW 2060...
  • Page 12 OMPLIANCES Wichtige Sicherheitshinweise 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4.
  • Page 13 OMPLIANCES 13. Öffnen sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet werden. 14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu überprüfen: a.
  • Page 14 HAPTER BOUT THE IGER WITCH TigerSwitch 100 Overview ....1-3 Fast Ethernet Modules for Model SMC6608M ......1-5 Switch Ports .
  • Page 15 BOUT THE IGER WITCH Management Options ....1-12 Serial Console Port ....1-12 Telnet .

  • Page 16: About The Tigerswitch 100

    RS-232 console port or in-band via Telnet. Also included is an on-board SNMP agent, which can be used to manage the switch with SMC’s EliteView™ or any other SNMP-based management application. The TigerSwitch 100 units support an optional Redundant Power Unit to minimize downtime in the event of an AC power failure.

  • Page 17: Tigerswitch 100T With 8 10Base-T/100Base-Tx Ports

    BOUT THE IGER WITCH Figure 1-1. TigerSwitch 100T with 8 10BASE-T/100BASE-TX Ports (Model SMC6608T) Figure 1-2. TigerSwitch 100M Base Unit (Model SMC6608M) Figure 1-3. 4-port Fast Ethernet Modules...

  • Page 18: 4-Port Fast Ethernet Modules

    BOUT THE IGER WITCH 4-Port Fast Ethernet Modules for Model SMC6608M The avalable slide-in modules are listed below: Module Ports Connectors Description SMC6600T RJ-45 100BASE-TX, fixed crossover RJ-45 100BASE-TX, switch- selectable crossover SMC6600F 100BASE-FX, fiber SMC6600FSCT 100BASE-FX, fiber RJ-45 100BASE-TX, fixed crossover RJ-45 100BASE-TX, switch-...

  • Page 19: 10Base-T/100Base-Tx Ports

    BOUT THE IGER WITCH Switch Ports 10BASE-T/100BASE-TX Ports These ports are dual-speed RJ-45 ports with built-in wiring crossovers. Each TigerSwitch 100 equipped with 10BASE-T/ 100BASE-TX ports will contain at least one straight-through (daisy-chain) port. This port is used for straight-through cable connections to other devices (i.e., hubs or switches) which have ports with built-in crossovers.

  • Page 20: Status Leds

    BOUT THE IGER WITCH Status LEDs The LEDs on the TigerSwitch 100 models are located on the front panel for easy viewing. For a more complete discussion of the front-panel LEDs, see Chapter 4, “Configuration and Management.” Figure 1-6. Front Panel LEDs Figure 1-7.

  • Page 21: Configure Button

    BOUT THE IGER WITCH Console Port Both TigerSwitch 100 units contain a Console port on the front panel. This is an RS-232 serial port with a DB-9 connector. A PC may be connected to this port for configuration and monitoring purposes out-of band via a full-handshaking null modem cable.

  • Page 22: Power Supply Receptacles

    IGER WITCH Optional Redundant Power Unit SMC’s Redundant Power Units (RPUs) are separate devices and each has its own power cord. These devices can supply power to the unit in the event of a failure of the internal power supply.

  • Page 23: Switch Architecture

    WITCH Switch Architecture Switching Methods Adaptive Cut-Through SMC’s TigerSwitch 100 models employ a dynamic forwarding architecture that enables them to support adaptive cut-through frame forwarding mode. This approach allows the switch to automatically alternate between three different switching methods to provide the best possible performance in response to current network conditions.

  • Page 24: Spanning Tree Protocol

    BOUT THE IGER WITCH Spanning Tree Protocol The TigerSwitch 100 switches support the ANSI/IEEE 802.1d Spanning Tree Protocol. This protocol adds a level of fault tolerance by allowing two or more redundant connections to be created between a pair of LAN segments. When there are multiple physical paths between segments, the protocol will choose a single path and disable all others to ensure that only one route exists between any two stations on the network.

  • Page 25: Management Options

    Another method by which these switches may be managed is in-band from a workstation via an SNMP-based manager (i.e., SMC’s EliteView). Simple Network Management Protocol (SNMP) is the most popular management protocol in use today. It defines the structure of information maintained on a device being managed and the operations used to access that information.

  • Page 26: Key Features And Benefits

    BOUT THE IGER WITCH Key Features and Benefits Connectivity • Slide-in, replaceable 4-port modules for added flexibility (Model SMC6608M only) • 100BASE-FX ports with SC or ST connectors (Model SMC6608M only) • Auto-Negotiation on 10BASE-T/100BASE-TX ports automatically selects optimum communication mode (half or full duplex and 10 Mbps or 100 Mbps) if this feature is supported by the attached device;...

  • Page 27: Practical Management

    BOUT THE IGER WITCH • Operates at maximum packet filtering and forwarding rate • Supports cut-through, store-and-forward, fragment-free and adaptive cut-through packet transport techniques • Routing table with over 4 K MAC address entries for attached network nodes • Automatically learns MAC addresses to build the routing information database •...

  • Page 28: Planning

    HAPTER PLANNING Introduction to Switching ....2-2 Sample Applications ....2-3 Collapsed Backbone .

  • Page 29: Introduction To Switching

    PLANNING Introduction to Switching An Ethernet or Fast Ethernet switch allows simultaneous transmission of multiple packets via high-bandwidth shared memory. This means that it can partition a network more efficiently than bridges or routers. The switch is, therefore, fast being recognized as one of the most important building blocks for today’s networking technology.

  • Page 30: Sample Applications

    PLANNING Sample Applications The TigerSwitch 100 is not only designed to segment your network, but also to provide a wide range of options in setting up network connections. Some typical applications for the TigerSwitch 100 are described below. Collapsed Backbone The TigerSwitch 100 is an excellent choice for Ethernet installa- tions where significant growth is expected in the near future.

  • Page 31: Multiport Bridging

    In the figure below, the 10BASE-T/100BASE-TX ports on the TigerSwitch 100T (Model SMC6608T) are providing 100 Mbps connectivity for up to 16 segments through SMC’s TigerStack™ 100 hubs. In addition, the switch is also connecting servers at 200 Mbps.
  • Page 32 PLANNING Server Farm Aggregation The advantages of mixed-media can also be easily exploited with the TigerSwitch 100M because of the various port configu- rations available among its 4-port modules. In the following example, a TigerSwitch 100M, equipped with modules featuring 10BASE-T/100BASE-TX and 100BASE-FX ports, is providing localized Fast Ethernet connectivity between an expanding server farm and associated LANs.

  • Page 33: High-Speed Switch Links

    In the following figure, the TigerSwitch 100M (Model SMC6608M) is cascaded via the 10BASE-T/100BASE-TX daisy- chain port to an 8-port Fast Ethernet switch, SMC’s EZ Switch™ 100, forming a high-speed 200 Mbps, full-duplex backbone. The other 10BASE-T/100BASE-TX ports are connected to power users, and the 100BASE-FX ports are connected to servers.

  • Page 34: Collapsed Backbone

    PLANNING Collapsed Backbone with Fiber Cable Fiber optic technology allows for a longer cable run distance (up to 2 km in full-duplex) than any other media type. The TigerSwitch 100M, used as a collapsed backbone to interconnect multiple Fast Ethernet segments with fiber cable, is a convenient way to provide direct connectivity for a wide-spread LAN.

  • Page 35: High-Speed Fiber Backbone

    PLANNING High-Speed Fiber Backbone When maximum network reach is required, the TigerSwitch 100M (Model SMC6608M) can be used to help create a high- speed fiber backbone. In the figure below, a TigerSwitch 100M employed as a collapsed backbone is also part of a full-duplex, 200 Mbps fiber backbone.

  • Page 36: Application Notes

    PLANNING Application Notes 1. Full-duplex operation only applies to point-to-point access (e.g., when the switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode. 2. For network applications that actually require routers (e.g., interconnecting dissimilar network types), attaching switches directly to a router can significantly improve overall network performance.

  • Page 38: Installation

    HAPTER NSTALLATION Selecting a Site ..... . . 3-2 Equipment Checklist ....3-3 Package Contents .

  • Page 39: Selecting A Site

    NSTALLATION Selecting a Site Before you start actual hardware installation, make sure you can provide the right operating environment, including power requirements, sufficient physical space and proximity to other network devices. Verify the following installation requirements: The site should: • be located in a cool, dry place, with at least 4 in. (10 cm) of space at the front and back for ventilation •...

  • Page 40: Equipment Checklist

    (2) brackets with screws for rack mounting the unit four (4) rubber foot pads appropriate power cord(s) SMC Warranty Registration Card — be sure to complete and return this card within 90 days Required Rack-Mounting Equipment Be sure to have the following equipment available when...

  • Page 41: Mounting

    NSTALLATION Mounting The TigerSwitch 100 is suitable for desktop or rack-mount installation. A good location is at the center of all the devices you want to link and near a power outlet. This switch can also be stacked with other switches on a flat surface or in a rack.

  • Page 42: Attaching The Brackets

    NSTALLATION To rack mount the switch: 1. Attach the brackets to the device using the screws provided. Figure 3-1. Attaching the Brackets 2. Mount the device in the rack, using four rack-mounting screws. Figure 3-2. Installing the Switch in a Rack...

  • Page 43: Mounting And Stacking The Switch On A Flat Surface

    NSTALLATION Mounting and Stacking the Switch on a Flat Surface 1. Attach the four adhesive feet to the hollow spaces on the bottom of the switch. Figure 3-3. Attaching the Adhesive Feet 2. Set the switch on a flat surface near an AC power source, making sure there are at least 4 inches (10 cm) of space in the front and back for proper air flow.

  • Page 44: Powering Up

    NSTALLATION Powering Up Connecting to a Power Source 1. Power on the switch by plugging one end of the power cord into the power socket on the rear panel, and the other end into a power outlet. (See Chapter 2 for a description of the rear-panel power receptacles) North America: Each switch is shipped with one standard AC line cord for North America (UL and CSA approved).

  • Page 45: Diagnostics

    Otherwise, the system will hang.* The components tested include: System ROM System EEPROM Ports * Note: If the system should hang, take note of the LED indicators and contact SMC Technical Support.

  • Page 46: Making Network Connections

    An overview of the rules for both Ethernet and Fast Ethernet collision domains is provided below. 10 Mbps Ethernet Collision Domain SMC 5 - 4 - 3 Rule Between any two PCs or other stations in the same 10 Mbps collision domain, there may be: •...
  • Page 47 • up to 3 link segments and • up to 2 Class II repeaters (hubs) SMC 2 - 1 Rule for Class I and Class II Repeaters Between any two PCs or other stations in the same 100BASE-T collision domain, there may be: •...

  • Page 48: Twisted-Pair Cabling Guidelines

    NSTALLATION Twisted-Pair Cabling Guidelines Each 10BASE-T or 100BASE-TX connection requires an unshielded twisted-pair (UTP) cable with RJ-45 connectors at both ends. For 10BASE-T connections, two pairs of 100 Ohm Category 3, 4 or 5 cable are required. 100BASE-TX connections require two pairs of certified Category 5 cable. Every twisted-pair connection must have a wiring crossover to transmit and receive data.

  • Page 49: Connecting 10Base-T/100Base-Tx Ports

    NSTALLATION Connecting 10BASE-T/100BASE-TX Ports Fixed Crossover Ports Insert the RJ-45 connector on one end of a twisted-pair cable into an unused 10BASE-T/100BASE-TX port on the TigerSwitch 100, and the RJ-45 connector on the other end into a port on the other device. 1.

  • Page 50: Connecting 100Base-Fx Ports

    NSTALLATION Connecting 100BASE-FX Ports TigerSwitch 100M fiber modules are equipped with either SC or ST connectors. Connect one end of a fiber optic cable to the appropriate fiber connector on the front panel of the TigerSwitch 100M, and the other end to the connector on the other device.

  • Page 52: Configuration And Management

    HAPTER ONFIGURATION AND ANAGEMENT Configuration Options ....4-3 Basic Port Settings ..... 4-4 Advanced System Configuration .
  • Page 53 ONFIGURATION AND MANAGEMENT System Monitoring ..... 4-19 Monitoring via the Configure Button and LEDs ......4-19 Advanced System Monitoring .

  • Page 54: Configuration Options

    SNMP (Simple Network Management Protocol). This SNMP agent permits the switch to be managed from any PC in the network using optional in-band management software (i.e., SMC’s EliteView). The System Configuration Program and the SNMP agent support management functions such as: •...

  • Page 55: Basic Port Settings

    ONFIGURATION AND MANAGEMENT Basic Port Settings When using the Configure button to set port communication modes: 1. Use a long press (>2 seconds) to begin function selection. The Status LED will start to flash to indicate that functions may be selected. Use short presses (<2 seconds) to cycle through the status LEDs until the Full/Half LED lights.

  • Page 56: Advanced System Configuration

    ONFIGURATION AND MANAGEMENT Advanced System Configuration Required Connections and Switch Access Console Port (Out-of-Band) Connections 1. Plug the female end of a standard RS-232 null-modem cable into the switch connector labeled “Console”. Plug the other end of the cable into the serial connector on either a PC (typically COM1 or COM2) running a terminal emulation program or a VT100-compatible Terminal.

  • Page 57: In-Band Connections

    You can access the TigerSwitch 100’s on-board SNMP agent from any PC in the network that is running an SNMP-based manager (i.e., SMC’s EliteView). However, prior to accessing the switch this way, it must first be configured with a valid IP address, subnet mask, default gateway and community string using an out-of-band connection.

  • Page 58: System Configuration Program Login Screen

    MMMM MMM M M MMM SSSSSSSS SSSSSSSS MMMMM MMMMM CCCCCCC TigerSwitch 100 (c) Copyright SMC, 1997-All rights reserved. Hardware Main Board Version W.WW Firmware Main Board Version X.XX Hardware Agent Module Version Y.YY Firmware Agent Module Version Z.ZZ Password : Type Password, then press <Enter>...

  • Page 59: System Configuration Program Main Menu

    ONFIGURATION AND MANAGEMENT Main Menu The Main Menu provides access to all the sub-menus necessary to configure and monitor the switch. Main Menu Information & Statistics System Information... Port Status... Statistics... Address Table... Spanning Tree Information... Configuration System Configuration... Port Configuration... SNMP Configuration...
  • Page 60 ONFIGURATION AND MANAGEMENT Configuration: System Configuration: Shows basic IP setup and identifies system by name, location and contact. SNMP Configuration: Configures communities and trap managers. Password Configuration: Sets Administrator and User passwords. Virtual LAN Configuration: Assigns switch ports to form up to 8 independent LAN groups.

  • Page 61: Password Configuration Screen

    It is recommended that you assign an administrator password as soon as possible to prevent unauthorized switch re-configura- tion. If a password is set and then forgotten, contact SMC Tech support to regain system access. 4-10...

  • Page 62: Console Configuration Screen

    ONFIGURATION AND MANAGEMENT Console Port Configuration The communications parameters for the RS-232 port can be set using the System Configuration Program. Figure 4-3 (below) illustrates the factory default settings. Console Configuration 9600 Console Time-Out (In Minutes) Return to Previous Menu Use cursor keys to choose item.

  • Page 63: System Configuration Screen

    1. Highlight “System Configuration” in the Main Menu and press <ENTER>. This will access the System Configuration Screen (See below). System Configuration System Name SMC TigerSwitch 100 System Location System Contact SMC Technical Support Dept. 192.72.24.31 Default Gateway 192.72.24.202 Subnet Mask 255.255.255.0 IP State BootP When Needed...
  • Page 64 CONFIGURATION AND MANAGEMENT 6. Highlight “Default Gateway” and press <ENTER> to set the default gateway IP address to which the unit will send IP packets destined for a different subnet. Press <ENTER> again to confirm entry. 7. Highlight “Subnet Mask” and press <ENTER> to set the sub- net mask corresponding to the assigned IP address.

  • Page 65: Port Configuration Screen

    CONFIGURATION AND MANAGEMENT Port Configuration 1. Highlight “Port Configuration” in the Main Menu and press <ENTER>. This will access the Port Configuration Screen illustrated below. Port Configuration Port Enabled Duplex AgingTime SwitchingMode FlowControl Auto Auto Auto Auto Half Auto Auto Return to Previous Menu Selecting Half or Full Duplex? Use cursor keys to choose item.
  • Page 66 CONFIGURATION AND MANAGEMENT 5. Highlight the setting under the “SwitchingMode” column to adjust the switching method for the chosen port. Press <ENTER> to use the arrow keys to cycle through Cut-through (CT), Store-and-forward (S&F), Adaptive cut- through (A-CT) or Fragment-free (FgFree) modes. Press <ENTER>...

  • Page 67: Spanning Tree Configuration Screen

    CONFIGURATION AND MANAGEMENT Spanning Tree Configuration The Spanning Tree Protocol (STP) is used to detect and disable network loops and to provide link back-up. It requires certain parameter settings. The factory default settings (See Figure 4-6) should be acceptable in most networks. To change the default settings, proceed as follows: Spanning Tree Configuration Priority...
  • Page 68 CONFIGURATION AND MANAGEMENT 4. Highlight “Hello Time” and press <ENTER> to input a value (1 to 10 seconds) for the rate at which hello frames are to be generated. Press <ENTER> again to confirm the chosen value. 5. Highlight “Maximum Message Age” and press <ENTER> to input a value (6 to 40 seconds) for the amount of time any port within the Spanning Tree network will wait before timing out its protocol information.

  • Page 69: Virtual Lan Configuration

    CONFIGURATION AND MANAGEMENT Virtual LAN Configuration Switches do not inherently support broadcast domains. Use the Virtual LAN Configuration screen (Figure 4-7) to assign any port on the switch to up to 8 broadcast domain groups*. All ports on the switch are assigned to a single group by default. Port Grouping Configuration Port Group1 Group2 Group3 Group4 Group5 Group6 Group7 Group8 Return to Previous Menu...

  • Page 70: System Monitoring

    CONFIGURATION AND MANAGEMENT System Monitoring The TigerSwitch 100 units can be monitored using either the front-panel Configure Button and LEDs, SNMP and Telnet or the Console Interface. Monitoring via the Configure Button and LEDs The Configure button may be used with the front-panel LEDs to display various system operations characteristics.
  • Page 71 CONFIGURATION AND MANAGEMENT Status LEDs LEDs Functions Power Indicates that the switch is receiving power. Indicates that the optional Redundant Power Unit is supplying power to the switch. Status Indicates that the LED array is displaying status information for each port (This is the default display mode).

  • Page 72: Advanced System Monitoring

    Interface Description Ethernet 802.3/802.3u System Name SMC TigerSwitch 100 System Location System Contact SMC Technical Support Dept. System Up Time 19Day, 2HR, 41Min, 5Sec No of Reset Since Power On Return to Previous Menu Use cursor keys to choose item.

  • Page 73: Port Status

    CONFIGURATION AND MANAGEMENT Port Status This screen displays the current status of each port on the switch. Port Status Port MediaType Enabled Link Speed Duplex AgTime SwhMode FlowCntl Half A-CT Down --- Full 100M Half A-CT 100M Half A-CT 100M Full 100M Half...

  • Page 74: Statistics

    CONFIGURATION AND MANAGEMENT Statistics This screen displays statistical information for any port or the entire switch, depending on the display mode chosen. (See Item 1 below) Statistics Time Since Last Reset Switch Statistics : 0Day, 2Hr, 5Min, 2Sec No of Reset Switch Statistics Since Power On: 0 Local Frame Received CRC Errors Forwarded Frames...
  • Page 75 CONFIGURATION AND MANAGEMENT Statistics Screen Items Item Description Time Since Last Number of times this port (or whole switch) or Reset of Statistics address table has been reset since power on Local Frames Number of frames confined to this segment and Received not forwarded Forwarded...

  • Page 76: Address Table

    CONFIGURATION AND MANAGEMENT Address Table Address Table Time Since Last Clear Switch Address Table: 0Day, 2Hr, 5Min, 2Sec No of Clear Switch Address Table Since Power On: Address Port Address Port 00 00 E8 C0 00 01 00 00 E8 C1 23 56 1 00 00 E8 C0 10 51 00 00 E8 00 43 22 1 00 00 E8 C5 23 47...

  • Page 77: Spanning Tree Information

    CONFIGURATION AND MANAGEMENT Spanning Tree Information The screen illustrated in Figure 4-12 shows a summary of the Spanning Tree configuration. This screen is only accessible if the Spanning Tree Protocol is enabled (See the section entitled, “Spanning Tree Configuration” in this chapter). Current Spanning Tree Information Hello Time Max Message Age...
  • Page 78 CONFIGURATION AND MANAGEMENT Spanning Tree Information Screen Items Parameter Description Hello Time Displays the rate (in seconds) at which hello frames are generated. Forward Delay The amount of time (in seconds) any port in the Spanning Tree will wait before changing states (i.e., listening to learning, etc.).

  • Page 79: Downloading System Software

    IP address for the TFTP server. Press <ENTER> to confirm entry. 3. Highlight “Download Filename” and press <ENTER> to input the file to be downloaded, if required. The file should be a *.bin file from SMC. Press <ENTER> to confirm entry. 4-28...

  • Page 80: Downloading Via The Console Port

    CONFIGURATION AND MANAGEMENT 4. Highlight “Execute Network Download” and press <ENTER>. The system will ask for confirmation. Press <ENTER> to initiate download after confirmation. Downloading via the Console Port Software update files can be downloaded through the Console port using any terminal emulation program that can transmit binary files using Xmodem communications protocol.

  • Page 81: Resetting The Switch

    CONFIGURATION AND MANAGEMENT Resetting the Switch Reset Display Diagnostics While Power-On Reset Unit with Diagnostics Reset Unit without Diagnostics Clear Address Table Reset EEprom to Factory Default Value Use cursor keys to choose item. Press <ENTER> to confirm choice. Press <CTRL><N> to return to the Main Menu. Figure 4-15.

  • Page 82: Management Via Snmp

    HAPTER SNMP ANAGEMENT VIA SNMP Protocol ..... . . 5-2 MIB Objects ......5-3 SNMP Parameter Configuration .

  • Page 83: Snmp Protocol

    SNMP ANAGEMENT VIA SNMP Protocol SNMP (Simple Network Management Protocol) is a communica- tion protocol designed specifically for the purpose of managing devices or other elements on a network. Network equipment commonly managed with SNMP includes hubs, switches, bridges, routers and host computers. SNMP is typically used to configure these devices for proper operation in a network environment, as well as monitor them to evaluate performance and detect potential problems.

  • Page 84: Mib Objects

    SNMP ANAGEMENT VIA the manager software, and result in a response by the agent. The third operation type, the TRAP, allows the agent to send an unsolicited message to the manager. This operation is typically used as an alert to a potential problem, or a change in device status.

  • Page 85: Snmp Parameter Configuration

    SNMP ANAGEMENT VIA SNMP Parameter Configuration In order to access the SNMP agent resident in the TigerSwitch 100 units, the switch must be configured with a valid IP address, default gateway and subnet mask. This is accomplished through the System Configuration Program, which can be accessed in-band or out-of-band (See Chapter 4, “Configuration and Management”).

  • Page 86: Community Strings Screen

    SNMP ANAGEMENT VIA 3. Highlight “Community Strings” and press <ENTER>. This will access the Community Strings screen (Figure 5-2). Community Strings Index Community Names Mode Read/Write public Read Return Add Entry Delete Entry Change Entry Clear Entry Use cursor keys to choose item. Press <ENTER>...

  • Page 87: Trap Receivers Screen

    SNMP ANAGEMENT VIA 5. Highlight “Trap Receivers” in the SNMP Configuration screen (Figure 5-1) and press <ENTER> to access the Trap Receivers screen (Figure 5-3). Trap Receivers Index IP Address Community Names 10.148.72.66 Add Entry Delete Entry Change Entry Clear Entry Use cursor keys to choose item.
  • Page 88 PPENDIX ROUBLESHOOTING Switch Indicators ..... . A-2 Diagnostic Tests ..... . . A-3 System Diagnostic Tests .

  • Page 89: Switch Indicators

    Defective power outlet, power cord or internal power supply. Solution: Check the power outlet by plugging in another device that is functioning properly. Check the power cord with another device. If these measures fail to resolve the problem, contact SMC Technical Support for assistance.

  • Page 90: Diagnostic Tests

    ROUBLESHOOTING Diagnostic Tests Upon power-up, the TigerSwitch 100 units perform self- diagnostic tests (See Chapter 3). Diagnostic tests similar to those performed on power-up can be run using the Configure button: 1. Use a long press (>2 seconds) to begin function selection. The Status LED will start to flash to indicate that functions may be selected.

  • Page 91: System Diagnostics

    If you still cannot isolate the problem, then the internal power supply may be defective. In this case, contact SMC Technical Support for assistance. Installation Verify that all system components have been properly installed.

  • Page 92: Communication Mode

    ROUBLESHOOTING Communication Mode The communication mode of each port (half or full duplex and 10 Mbps or 100 Mbps) must be identical to the mode of the attached device. Verify that each port is set to the same communication modes used by the attached device. Each 100BASE-FX port must be configured for half- or full-duplex operation.

  • Page 93: Management Interface

    ROUBLESHOOTING down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation comply with recommendations. (See “Making Network Connections” in Chapter 3.) Management Interface Terminal Emulation If the terminal attached to the console port is not operating properly, check that: 1.

  • Page 94: System Integrity

    SMC Technical Support for further assistance. Be sure to check the Login Screen (Figure 4-1.) for the version of the System Configuration Program (Chapter 4) installed on your TigerSwitch 100. Keep this information close at hand when you contact SMC Technical Support.
  • Page 96 PPENDIX SSIGNMENTS RJ-45 Pin Assignments ....B-2 Straight-through Wiring ....B-3 Crossover Wiring .

  • Page 97: Pin Assignments

    SSIGNMENTS RJ-45 Pin Assignments Caution: Regulations regarding the connection of equipment to telephone networks vary from country to country. Check with your local telephone network supplier before using existing telephone wiring. An Ethernet twisted-pair link segment requires two pairs of wires—Category 3, 4 or 5 for 10 Mbps connections and Category 5 for 100 Mbps connections.
  • Page 98 SSIGNMENTS Straight-Through Wiring If the twisted-pair link segment is to join two ports and only one of the ports has an internal crossover, the two pairs of wires must be straight-through. Straight-Through RJ-45 Pin Assignments End 1 End 2 1 (Tx+) 1 (Tx+) 2 (Tx-) 2 (Tx-)

  • Page 99: Console Port Pin Assignments

    SSIGNMENTS Console Port Pin Assignments The DB-9 serial console port on the front-panel is used to connect the switch to a console device, either directly or remotely. The pin assignments for connection to another DB-9 port or a DB-25 port are provided below and on the following pages.

  • Page 100: Console Port

    SSIGNMENTS Console Port to 9-Pin COM Port on PC Switch Port PC Port DB-9 Pin No. Signal DB-9 Pin No. 1 (DCD) 2 (RXD) 3 (TXD) 4 (DTR) 5 (SGND) SGND 6 (DSR) 7 (RTS) 8 (CTS) 9 (RI) Console Port to 25-Pin DCE Port on Modem Switch Port 25-Pin Modem Port DB-9 Pin No.
  • Page 101 SSIGNMENTS Console Port to 25-Pin DTE Port on PC Switch Port 25-Pin PC Port Null Modem DB-9 Pin No. DTE Pin No. 1 (DCD) 8 (DCD) 2 (RXD) 3 (TXD) 3 (TXD) 2 (RXD) 4 (DTR) 20 (DTR) 5 (SGND) 7 (SGND) 6 (DSR) 6 (DSR)
  • Page 102 PPENDIX PECIFICATIONS All Models ......C-2 Model SMC6608T ..... . C-4 Model SMC6608M .

  • Page 103: Specifications

    PECIFICATIONS All Models Switching Methods Adaptive Cut-through Cut-through Store-and-forward Fragment-Free Memory Buffer 256K per port Filtering/Forwarding/Learning Rates Full line rate MAC Address Table 4,096 entries Latency <20 µsec VLAN Support Port-based grouping, up to 8 groups with port overlapping Flow Control Back pressure mechanism (limits fiber cable distance to 180 m in half-duplex mode) In-Band Management...
  • Page 104 PECIFICATIONS Full/Half Diagnostic LED Array Tx/Rx (60%) 100Mbps (30%) Full-Duplex (10%) Select/Link (1%) Button Configure Size 17.25 in. x 13.75 in. x 1.75 in. (43.8 cm x 34.9 cm x 4.4 cm) Input Power Universal AC input 100 to 240 VAC, 50 to 60 Hz Power Consumption 80 watts max @ 100-240 VAC Operating Temperature...

  • Page 105: Smc6608T

    PECIFICATIONS Model SMC6608T Ports 8 10BASE-T/100BASE-TX, Auto-Negotiation support Network Interface 10BASE-T RJ-45 connector, 100 Ohm, UTP cable; 2 wire pair; EIA/TIA Categories 3, 4, 5 100BASE-TX RJ-45 connector, 100 Ohm, UTP cable; 2 wire pair; EIA/TIA Category 5 Weight 8.2 lbs. (3.7 kg) Model SMC6608M Weight (without modules) 7.8 lbs.
  • Page 106 PECIFICATIONS Network Interface 10BASE-T RJ-45 connector, 100 Ohm, UTP cable; 2 wire pair; EIA/TIA Categories 3, 4, 5 100BASE-TX RJ-45 connector, 100 Ohm, UTP cable; 2 wire pair; EIA/TIA Category 5 100BASE-FX SC or ST connector, multimode fiber cable, 50/125 or 62.5/125 core...

  • Page 108: Glossary

    PPENDIX LOSSARY Glossary ......D-2...
  • Page 109 LOSSARY 10BASE-T IEEE specification for 10 Mbps Ethernet on two pairs of Category 3, 4 or 5 twisted-pair cable. The point-to-point cable segment can be up to 100 m (328 ft.) in length. 100BASE-FX IEEE specifications for 100 Mbps Fast Ethernet on multimode fiber optic cable.
  • Page 110 LOSSARY Collision A condition in which packets transmitted over the cable interfere with each other. Their interference makes both signals unintelligible. Crossover Port An RJ-45 port which crosses the receive and transmit signals internally so it can be connected with straight-through twisted- pair cable to a workstation, server or any other device having a straight-through port.
  • Page 111 LOSSARY ICMP (Internet Control Message Protocol) Commonly used to send echo messages (i.e., Ping) for monitoring purposes. In-Band A way of communicating with a network device from inside the network (i.e., a local connection). Light emitting diode used for monitoring a device or network condition.
  • Page 112 LOSSARY Terminator A resistor placed at each end of a thick or thin coax cable to make sure that signals do not reflect back and cause errors. Simple Network Management Protocol (SNMP) The application protocol offering network management services in the Internet suite of protocols. Straight-through Port An RJ-45 port which does not cross the receive and transmit signals internally so it can be connected with straight-through...
  • Page 113 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (8:30 AM - 8:00 PM Eastern Time) (800) SMC-4-YOU; (516) 435-6250; (516) 434-9314 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1344 420068; 44 (0) 1344 418835 (Fax)

This manual is also suitable for:

6608t-intTigerswitch smc6608tTigerswitch smc6608m
