queue bandwidth

This command assigns weighted round-robin (WRR) weights to the eight
class of service (CoS) priority queues. Use the no form to restore the
default weights.
Syntax
queue bandwidth weight1...weight4
no queue bandwidth
weight1...weight4 - The ratio of weights for queues 0 - 3 determines
the weights used by the WRR scheduler. (Range: 1 - 15)
Default Setting
Weights 1, 2, 4, 6, 8, 10, 12, 14 are assigned to queues 0 - 7 respectively.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
WRR controls bandwidth sharing at the egress port by defining
scheduling weights.
Example
This example shows how to assign WRR weights to each of the priority
queues for port 5.
Console#configure
Console(config)#int eth 1/5
Console(config-if)#queue bandwidth 1 3 5 7 9 11 13 15
Console(config-if)#
Related Commands
show queue bandwidth (4 -227)
