Table 4-48 Show Lacp Counters - Display Description; Table 4-49 Show Lacp Internal - Display Description - SMC Networks 6152L2 - annexe 1 Management Manual

C L
OMMAND INE
Field
LACPDUs Sent
LACPDUs Received Number of valid LACPDUs received on this channel
Marker Sent
Marker Received
LACPDUs
Unknown Pkts
LACPDUs Illegal
Pkts
Console#show lacp internal
Channel group : 1
-------------------------------------------------------------------
Oper Key:
Admin Key: 0
Eth 1/ 2
-------------------------------------------------------------------
LACPDUs Internal:
LACP System Priority: 32768
LACP Port Priority:
Admin Key:
Oper Key:
Admin State: defaulted, aggregation, long timeout, LACP-activity
Oper State:
. .
.
Field
Oper Key
Admin Key
4-174
I
NTERFACE

Table 4-48 show lacp counters - display description

Description
Number of valid LACPDUs transmitted from this channel
group.
group.
Number of valid Marker PDUs transmitted from this
channel group.
Number of valid Marker PDUs received by this channel
group.
Number of frames received that either (1) Carry the Slow
Protocols Ethernet Type value, but contain an unknown
PDU, or (2) are addressed to the Slow Protocols group
MAC Address, but do not carry the Slow Protocols
Ethernet Type.
Number of frames that carry the Slow Protocols Ethernet
Type value, but contain a badly formed PDU or an illegal
value of Protocol Subtype.
3

Table 4-49 show lacp internal - display description

Description
Current operational value of the key for the aggregation port.
Current administrative value of the key for the aggregation
port.
30 sec
32768
3
3
distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
