Generac Power Systems PWRcell Reference Manual page 144

Appendix E State and Event Codes
Code Display Text
0x0810 disconnecting
grid
0x0820 grid
connected
0x0830 islanded
0x4200 REbus over
voltage
0x7000 error
0x700F error
0x7510 Error: REbus
fault
0x7520 Error: int DC
fault
0x7705 Configuration
Error
0x770B Configuration
Error
0x770C Configuration
Error
0x7710 Bad Reset
Error
140
Table F-1. Inverter States
Transient/ Severity Description
Steady
Transient Normal Inverter is connected to REbus
and disconnecting from its grid
connection
Steady Normal Inverter is connected to the grid
Steady Normal Inverter is islanded / disconnected
from the grid
Steady Fault REbus is too high for the inverter
(Low) to operate safely
Steady Error General error state
Steady Error General error state/ inverter did
not enter a state of operation
Steady Error Inverter experienced a fault on
REbus and stopped moving
power
Steady Error Inverter experienced a fault on its
internal DC bus and stopped
moving power
Steady Error The inverter is configured to use a
transfer switch but not allowed to
island
Steady Error A 3 Phase inverter has been
installed on split phase grid
Steady Error The inverter is not configured to
calibrate its CTs but is configured
to enforce Export Override, which
requires CTs
Steady Error The inverter experienced a bad
reset error after losing power or
updating firmware
Diagnostics
N/A
N/A
N/A
- Check Inverter Settings
- Check REbus Devices
- Disable / Enable
- Disable / Enable
- Power Cycle
- Basic Function Test
- Check REbus Wiring
- Check REbus Fuses
- Basic Function Test
- Check REbus Devices
- Check REbus Wiring
- Check REbus Fuses
- Basic Function Test
- Check REbus Devices
- Check Inverter Settings
- Check Inverter HW Type
- Check AC Wiring
- Check Inverter Settings
- Contact PWRcell Technical
Support
Diagnostic Repair Manual
