Section 10 PWRcell Power Core Replacement

Remove Power Core

Electrocution. Initiate a system-wide shutdown and turn the
PWRcell DC Disconnect Switch OFF on all connected
batteries before performing service. Failure to do so will
result in death, serious injury, or equipment and property
damage.
Figure 10-9.
1
Figure 10-10.
Figure 10-11.
92
DANGER
2
Diagnostic Repair Manual
NOTE: Power Core outer sheet metal may be warm/hot
to the touch. If so, use of protective hand wear is
recommended.
(000600)
See Figure
1.
bottom of the Power Core and left hand on top-left
near the intake fan.
•
Lift Power Core assembly upward while pulling
bottom out to clear bottom studs.
NOTE: Once clear of bottom studs, the Power Core will
shift down, to the left, and rest only on top studs.
NOTE: Use caution. Hold onto the Power Core tightly.
013118
See
Figure
2.
bottom of Power Core to lift and align top
clearance holes with top nuts.
013119
Pull the Power Core assembly outward.
3.
013120
10-9. Place right hand under the
10-10. Use the hand holding the
