Tests - Generac Power Systems PWRcell Reference Manual

Section 9 Other Accessories
State LED State
1 second flash
Shed
(1 On – 1 Off)
Lockout 3 second flash
(30 minutes) (3 On – 3 Off)
Lockout 6 second flash
Switch Active (6 On – 6 Off)
Lockout
ON
Switch Active
Normal ON
Test 1 second flash

Tests

Utility Test
1. Turn utility power ON and enable all module
feeding circuits.
2. Verify LED begins to flash at one second intervals.
3. All contactors will close after five minutes. LED will
illuminate, and stay ON.
4. Wait 30 seconds after contactor closes, then press
TEST button and verify module load shed. LED will
flash at one second intervals.
5. Wait five minutes, plus predefined priority set time
for module to recover.
6. Contactor will CLOSE and LED will illuminate, and
stay ON.
Generator/PWRcell Inverter Test
1. Enable Islanding and verify load shed settings.
2. Simulate a utility loss by turning main line circuit
breaker (MLCB - service disconnect) OFF while
generator is in AUTO and inverter is configured
with EnaIslanding ON.
3. All modules will lose power and LEDs will disable
when power is supplied via generator. When
82
Table 1-5. LED States
Mode
Module detected an overload and shed its load. This state only occurs in
Generator/
generator mode, or during a first time utility power-up for five minutes of
Inverter
initial operation.
Module detected an overload while trying to recover from a shed situation.
Generator/
Operation is disabled for 30 minutes.
Inverter
This state only occurs in generator mode.
Module output is disabled and there is no power to the appliance while in
Generator/
generator mode and generator is overloaded. Lockout switch must be ON.
Inverter
Table 1-3
See
Lockout switch operates in generator mode only. It has no function in
utility mode. LED is solid, indicating the load is connected. Lockout switch
Utility
must be ON. See
Indicates the appliance has power. This is the default in utility mode. It is
Generator or
the normal operating state in generator/inverter mode when an overload is
Utility
not detected.
Test button triggers a typical shed condition and overrides all other states
except generator lockout switch ACTIVE state.
Generator or
NOTE: Actual test time varies depending on SMM priority setting. Use the
Utility
following formula to calculate test time:
Time = (P-1) x 15 seconds, where P represents priority setting.
Example: SMM Priority 6 test time = (6-1) x 15 seconds, or 75 seconds.
Note
.
Table 1-3
.
powered by inverter there will be a quick blink of
the LED.
4. Generator will power on after preset delay. Inverter
will transfer to Island mode.
5. All LEDs will flash when generator transfers. When
on Inverter power the SMM will go into its
programmed control state.
6. Allow each module to enable output per its priority
setting.
7. After predefined priority time elapses, each
contactor will CLOSE and LED will illuminate and
stay ON.
8. Once LED stays ON, press TEST button and verify
load shed occurs.
9. Once load shed occurs, LED will flash at one
second intervals.
10. Allow time for each module to enable contactor
output per priority setting.
11. After predefined priority set time, each contactor
will CLOSE and LED will illuminate and stay ON.
NOTE: Depending on load size, the SMM module may
immediately go into load shed mode or lockout during
test. In this event, remove one or more higher priority
loads to allow testing of each module.
Diagnostic Repair Manual
