Figure 13-27.
Enable PWRcell Battery
Diagnostic Repair Manual
Section 13 PWRcell Battery BMU Replacement
16. Connect the battery string connector on the right
side of PWRcell Battery frame. It is behind the
REbus terminal blocks.
013149
17. Connect DC connector on battery module.
013147
18. Connect 12V positive lead to the BMU battery.
013150
117
