PV Link Events

When the PV Link experiences an event or a sequence of events, it will change states accordingly. Display texts for
events are transient. Display texts can be viewed at the battery device page only at the time the event is experienced.
Refer to the S2502 PV Link states table for troubleshooting.
To view the last known event, logon to the Installer Configuration Tool by accessing the local Wi-Fi signal from the
Generac REbus Beacon. Navigate to 'PV' then select 'REbus Status.'
Faults: Low = low impact to performance, the device will recover; Med = noticeable impact to performance but still
recoverable; High = high impact to performance or could render device inoperable - device will try to recover.
Errors: Requires manual intervention before device can operate.
Code Display Text
0x8010 power up
0x8021 supply under
voltage
0x8030 daily event
0x8041 firmware
received
0x8102 enable
0x8202 disable
0x8300 sysmode
change
0x8301 sysmode
change
0x8302 sysmode
change
0x8303 sysmode
change
0x8304 sysmode
change
0x8305 sysmode
change
0x8306 sysmode
change
0x8400 unauthorized
sysmode
0x850B debug trace
recorded
0x8FF1 hardware
version
mismatch
0x900A interrupt fault
0x9900 transistor
failure
Diagnostic Repair Manual
Table F-4. PV Link Events
Severity Description
Normal Happens on startup. If persistent call PWRcell Technical Support.
Fault Power supply measurements were out of range. PV Link will wait for valid power
(low) supply voltage to operate.
Normal Daily event code to show the PV Link is still communicating.
Normal PV Link received firmware update
Normal PV Link was enabled
Normal PV Link was disabled
Normal Sysmode change to Shutdown Mode
Normal Sysmode change to Grid Tie
Normal Sysmode change to Self Supply
Normal Sysmode change to Clean Backup
Normal Sysmode change to Priority Backup
Normal Sysmode change to Remote Arbitrage
Normal Sysmode change to Sell
Fault PV Link instructed to enter an unauthorized sysmode.
(Low)
Normal Diagnostic trace recorded in device memory
Error The hardware version in configuration does not match with the hardware version
of device firmware
Fault May indicate an internal processor issue. Contact PWRcell Technical Support.
(Med)
Error Damage to the internal switching mechanism has occurred. Contact PWRcell
Technical Support.
