S
Figure 10-19.
U
Figure 10-20.
Recommission Inverter With Replacement Power Core
Figure 10-21.
Activate Warranty / Register New Power Core
Figure 10-22.
Diagnostic Repair Manual
T
V
X
W
Section 10 PWRcell Power Core Replacement
Connect accessory cables (S) and plug in green
8.
screw terminals (T) if previously removed.
013519
Connect AC wiring, grounds, the DC wiring
9.
connector, and LCD cable to Power Core.
•
Connect the DC wiring connector (U) and the LCD
cable (V).
•
Connect ground wires (W) and AC wiring (X).
013520
Refer to Inverter Installation and Owner's Manual
1.
for commissioning steps.
NOTE: Modify any non-default set points and access
the Installer Configuration Tool to update any advanced
settings per Utility interconnection requirements.
NOTE: The original Power Core will show up as "Device
Offline" on the LCD screen. This page should be
removed to not confuse which inverter is operating at the
13124 site. Access the inverter device settings sub-menu and
select "Remove Device".
Create
1.
www.generac.com/resources-and-tools/ce-
installer-resources/technical-support
following info:
•
Registration email
•
New inverter's RCPn (see Note)
•
In subject line, enter "Power Core Swap Registra-
tion"
013125
NOTE: See
Figure
device page sub-menu.
a service ticket
10-22. This is shown in the Inverter
at https://
with the
95
