Inverter Events
When the inverter experiences an event, or a sequence of events, it will change states accordingly. Display texts for
events are transient. Display texts can be viewed at the inverter device page only at the time the event is experienced.
Refer to inverter states table for troubleshooting.
To view the last known event, logon to the Installer Configuration Tool by accessing the local Wi-Fi signal from the
Generac REbus Beacon. Navigate to 'Inverter' then select 'REbus Status.' To view the last four events, select 'Inverter
Split Phase' and reference event codes.
Faults: Low = low impact to performance, device will recover; Med = noticeable impact to performance but still
recoverable; High = high impact to performance or could render device inoperable - device will try to recover.
Errors: Requires manual intervention before device can operate.
Code Display
0x8010 power up
0x8020 Supply under voltage
0x8030 daily event
0x8040 firmware received
0x8060 ct cal = success, 1, 2, 3, 4, etc.
0x8080 ct cal fault
0x8100 enable
0x8200 disable
0x8220 external estop
0x8300 sysmode change
0x8400 unauthorized sysmode
0x8FF0 hardware version mismatch
0x9000 interrupt fault
0x9200 int. timer fault
0x9300 mux Stuck
0x932A relay fault
0x932B relay fault
0x932C relay fault
Diagnostic Repair Manual
Table F-2. Inverter Events
Severity Description
Normal Successful internal voltage power on
Fault (High) Internal supply voltage issue. Expected during a power
cycle. Fault if it occurs during operation.
Normal Daily event code/ daily check-in
Normal Remote firmware update received
Normal CT calibration was manually requested- refer to inverter
manual for CT calibration table.
Fault (Low) CT calibration failed due to disconnected or broken CT
Normal Inverter received enable command
Normal Inverter received disable command
Normal ESTOP was activated and system shut down
Normal System operating mode was changed
Fault (Low) Device was asked to change to a system operating mode
that may have been locked to the user
Error Hardware version does not match firmware. Contact
PWRcell Technical Support.
Error Attempt to power cycle the inverter. If persistent, contact
PWRcell Technical Support.
Error Internal processor issue. Contact PWRcell Technical
Support.
Error Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) The inverter was backfeeding the grid on Line 1. The
hardware could be damaged, or the configuration of the
system is wrong (has a transfer switch but not configured
for one).
Fault (High) The inverter was backfeeding the grid on Line 2. The
hardware could be damaged, or the configuration of the
system is wrong (has a transfer switch but not configured
for one).
Fault (Low) The grid frequency went out of spec while the inverter was
trying to drive the relays inactive, this can happen with grid
outages.
Appendix E State and Event Codes
