Setting Lockout (Later, Normally Closed Contactor)

Two steps are required for setting SMM to enable standard lockout mode:
1. See 9-2. Slide the lockout switch (1) to LOCKOUT LOAD ON GENERATOR.
Figure
2. Move the mode selector jumper (4) on the control board as directed in
Table 9-4. Lockout Switch Settings (Later, Normally Closed Contactor)
Lockout Switch
Setting
LOCKOUT LOAD ON
GENERATOR/
INVERTER
LOCKOUT LOAD ON
GENERATOR/
INVERTER
LOCKOUT DISABLED
LOCKOUT DISABLED
NOTE: PWRcell systems do not support the operation of Mode Select Jumper in B position.

Jumper Locations

See 9-2. Later SMM control boards are equipped
Figure
with two movable jumpers (2). Jumper locations are indi-
cated on the diagram:
•
(3) Frequency (50 Hz/60 Hz) Jumper
•
(4) Mode Selector Jumper (identified on control
board as "Lock Out Jumper").
C12
Figure 9-2. Jumper Locations (Later, Normally Closed Contactor)
Diagnostic Repair Manual
Mode
Selector
Mode
Jumper
Position
GENERATOR
A
/INVERTER
A UTILITY
GENERATOR
A
/INVERTER
A UTILITY
LED
SW3
C4
Module sheds load and does not reconnect until utility returns.
This setting is considered standard for most installations.
Power is available on module output.
Module operates with standard load shed logic.
Table 1-1
See for more information.
Power is available on module output.
The frequency jumper is factory set at the 60 Hz position.
The mode selector jumper is factory set at position "A"
which is considered standard for most installations.
IMPORTANT NOTE: For PWRcell applications jump-
ers should remain in the factory positions.
1 2
SW1
3
LOCK OUT
J2
JUMPER
50Hz 60Hz
JUMPER
L1
J1
Section 9 Other Accessories
Jumper Locations.
Function
4
007115
