Appendix E State and Event Codes
Code Display Text
0xA101 over temp
shutdown
0xB001 REbus fault
0xB011 REbus no load
0xB101 REbus over
voltage
0xB201 REbus over
current
0xB411 RSS fault
0xC001 ground fault
0xC011 ground fault
lockout
0xC301 input over
current
0xC302 input over
current
0xC600 arc fault
0xC611 arc fault lockout
0xC901 Input over
voltage
0xE100 EEPROM
failure
0xE200 FLASH fault
0xF000 default trap
0xF010 address error
trap
0xF020 stack error trap
0xF030 osc. fail trap
0xF040 math error trap
0xF050 dmac error trap
148
Table F-4. PV Link Events
Severity Description
Fault High temperature detected by internal electronics.
(High)
Fault REbus voltage measurement was detected low out of range.
(Low)
Fault PV Link was unable to push current to REbus.
(Med)
Fault REbus voltage measurement was detected high out of range
(Med)
Fault REbus current measurement was detected high out of range
(Med)
Fault PVRSS self-test failed to get accurate count of SnapRS or PVRSS was
(Med) misconfigured.
Fault PV Link detected ground fault or was unable to verify through self-test.
(Med)
Fault PV Link detected ground fault events and is locked out for 24 hours.
(High)
Fault PV Link measured current on PV Positive high out of range.
(High)
Fault PV Link measured current on PV Negative high out of range.
(High)
Fault PV Link detected an arc fault or was unable to verify through self-test.
(Med)
Error PV Link detected successive arc fault events and is locked out for manual
intervention.
Contact PWRcell Technical Support.
Fault PV Input overvoltage, voltage measurement is sampled fast. Unit will disconnect
(High) from PV input and timeout for 1 minute before trying again.
Error Internal processor issue. Contact PWRcell Technical Support.
Error Internal processor issue. Contact PWRcell Technical Support.
Fault Internal processor issue. Contact PWRcell Technical Support
(High)
Fault Internal processor issue. Contact PWRcell Technical Support.
(High)
Fault Internal processor issue. Contact PWRcell Technical Support.
(High)
Error Internal processor issue. Contact PWRcell Technical Support.
Fault Internal processor issue. Contact PWRcell Technical Support.
(High)
Fault Internal processor issue. Contact PWRcell Technical Support.
(High)
