Device Confirmation - Generac Power Systems PWRcell Reference Manual

2. Check Inverter Settings
a. If 'NumTranSwtchs' is set to a value other than
'0' without an external transfer switch correctly
installed, the inverter may not correctly
recognize the grid.
(1) If external transfer switch is installed,
check ATS CAT5 cable.
Stuck in Shutdown Mode
1. Check the 'STOP' terminals to verify the presence
of a jumper between the two terminals.
2. Verify a field-installed external shutdown switch is
in the 'closed' position (for a common residential
light switch this would be the ON position).
3. Use the center button and follow directions on the
inverter screen to recover from Shutdown mode.
NOTE: If site has more than one inverter, system may be
stuck in shutdown mode due to crosstalk. See
Cross-talk Recovery Procedure
Inverter.
4. If unable to recover, Call Generac PWRcell
Technical Support 855-635-5186.
Unknown Devices 'Offline'
1. Log into the Beacon Installer Configuration Tool.
a. Select 'Inverter'.
b. Select 'PWRcell Configuration'.
c. Select 'Clear Display'.
d. Click 'Submit'.
e. Inverter screen should blank out, pixilate, and
test its LEDs. Try again if this does not happen.
f. Wait for screen to re-boot then scroll through
device pages. Unknown devices should be
cleared.
Diagnostic Repair Manual

Device Confirmation

1. Confirm LEDs at the inverter are:
2. All icons on ICM are present on the home screen,
3. Power flow arrows at home screen display
4. DC and AC voltages at the home screen display
PLM
in
Appendix B
5. Wattage is being produced at the home screen and
6. PV Links are making power if the sun is shining; or
7. Battery is charging, discharging, or in standby
8. Settings for the inverter are set properly for the
9. Protected loads breaker is 'on' for systems with a
10. Verify that the system will island and provide
Section 4 PWRcell Inverter
•
Green for Inverter indicating it is enabled and
grid-connected.
•
Green for REbus indicating all devices are
enabled and functioning normally.
•
Blue for Internet
including the power pole icon in the lower right-
hand corner to indicate CTs are working properly.
expected directionality and values are as expected
for the chosen system mode and current sun state/
charge state.
within correct value ranges for the installation (e.g.
REbus is nominally 380–420 VDC and AC
connections are 120/240
nominal).
the inverter device screen.
displaying Low Sun if the sun has gone down.
based on chosen system mode and environmental
circumstances.
installation and desired performance.
battery where backup power is desired.
backup power to loads by simulating an outage.
or 120/208 VAC
19
