Code Display
0xD117 island overload
0xD118 island overload
0xD119 island overload
0xD11A island overload
0xD11B island overload
0xE100 EEPROM failure
0xE200 FLASH fault
0xE500 event pattern lockout
0xE600 bad reset error
0xE700 PLM fault
0xF000 default trap
0xF010 address error trap
0xF020 stack error trap
0xF030 osc. fail trap
0xF040 math error trap
0xF050 dmac error trap
Diagnostic Repair Manual
Table F-2. Inverter Events
Severity Description
Fault (Med) Line 1 and line 2 experienced an overload in current
(>35A) for more than 6s. If installed, the inverter will
trigger SMMs to shed loads. Otherwise, loads should be
shed manually.
Fault (Med) The inverter timed out attempting to validate hardware
and exited islanding.
Fault (Med) The inverter timed out attempting to validate hardware
due to low bus voltage and exited islanding.
Fault (Med) The inverter was unable to determine whether the
connection to line 1 was open or closed.
Fault (Med) The inverter was unable to determine whether the
connection on line 2 was open or closed.
Error Internal processor issue. Contact PWRcell Technical
Support.
Error Internal processor issue. Power cycle inverter. If
persistent, contact PWRcell Technical Support.
Normal Expected behavior during normal operation
Error Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) Internal communication issue. Contact PWRcell Technical
Support.
Fault (High) Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) Internal processor issue. Contact PWRcell Technical
Support.
Error Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) Internal processor issue. Contact PWRcell Technical
Support.
Fault (High) Internal processor issue. Contact PWRcell Technical
Support.
