Generac Power Systems PWRcell Reference Manual page 104

Section 11 PWRcell Inverter Lid Replacement
Figure 11-10.
Figure 11-11.
Figure 11-12.
100
Install lid pivot bolts with washers and spacers in
2.
correct placement.
NOTE: See
between lid and housing. Use needle nose pliers or the
2.5 mm hex driver to help position the spacer.
Figure 11-10
pivot bolts. The rubber washer is directly under the head
of the bolt against the inverter housing.
The white plastic spacer goes between the inverter
housing and the lid.
Tighten pivot bolt using 2.5 mm Hex Driver until
3.
013132
bolt is tight by hand. Lid should pivot freely and not
bind at any point.
NOTE: Lift upwards on the lid to help position bolt
threads to bolt hole.
Connect inverter screen electrical connector by
4.
pushing in until the lock tab clicks securely in
place.
013401
Secure the inverter screen cables and strap to the
5.
lid using zip ties.
NOTE: Zip tie points are designated by the outer edge
of the T-shaped ends. Zip ties should land on the inside
of those ends.
NOTE: Do NOT over tighten zip ties. Cables can
become internally pinched.
Cut zip tie excess length.
6.
NOTE: Discard excess zip tie ends. Do not allow the
excess to drop into DC breaker assembly.
IMPORTANT NOTE: Removing DC breaker assembly
013135
cover to retrieve loose objects will void the warranty.
Figure 11-10. Spacer must be installed
shows the order of assembly for the lid
Diagnostic Repair Manual
