PWRcell Inverter
Section 4

Device Profile

The PWRcell Inverter, complete with its control panel LCD and its REbus Beacon, should be thought of as the central
device in a PWRcell system. The PWRcell Inverter facilitates system-level functionality. It is important to follow all
safety precautions when servicing this equipment. Initiate a
levels prior to servicing.
A
Inverter Control Module (ICM)
B
REbus Beacon
PWRcell DC disconnects
C
D REbus bi-directional DC
terminals
E Internet connection
REbus DC fuses
F
G Current Transformers (CTs)
accessory ports
H Automatic Transfer Switch (ATS)
accessory port
REbus Beacon port
I
J Authorized use only
K STOP terminals
L Protected Loads Disconnect
AC Grid Connection terminals
M
N Protected Loads terminals
O Grounding bar
P RGM PWR / Gen Inhibit
Fast Blow Mini Fuses 1A 250V
Q

Diagnostics

The diagnostics defined below detail inspections for
common scenarios. Reference and use in the order
prescribed by in Troubleshooting.
Table 4-1
1. AC Configurations
•
Review the permitted site plans to verify the sys-
tem is properly configured and wired based on the
approved plan set.
Diagnostic Repair Manual
System Shutdown
A
B
C
D
E
Figure 4-1. Inverter Component Locations
NOTE: Mistakes can often be revealed by reviewing the
overall site configuration and retracing the installation.
2. AC Wiring

Section 4 PWRcell Inverter

and bring all voltages to safe working
F G H I
O
•
Verify all connections are secure without loose wir-
ing at the inverter, AC panel, backfeed breaker,
combiner box, disconnect, tap, or otherwise.
J K
L
M
Q
P
N
011986a
