Generac Power Systems PWRcell Reference Manual page 98

Section 10 PWRcell Power Core Replacement
M
Figure 10-15.
P
Figure 10-16.
Figure 10-17.
R
Figure 10-18.
94
013522
P
N
013117
Q
Diagnostic Repair Manual
Gripping the Power Core from the bottom, push up
3.
and to the right to align bottom studs with bottom
holes (M).
NOTE: The Power Core should now rest on all 4 studs.
Tighten two 10 mm nuts (N) inside the Power Core
4.
using a 10 mm socket. Tighten nuts securely.
Install plastic caps (P) in two top access holes of
5.
Power Core.
Install and tighten the bottom nuts (Q) using a 10
6.
mm socket. Tighten nuts securely.
013521
Align the AC wiring terminal assembly with the
7.
mounting studs and install two retaining nuts (R)
using a 7 mm socket. Tighten nuts securely.
013115
