Section 12 DC Breaker Assembly Replacement
Figure 12-6.
Figure 12-7.
Figure 12-8.
106
013139
013140
A
B
013112
4. Remove the DC breaker assembly (see note
below) and replace with the new DC breaker
assembly.
NOTE: See
Figure
12-7. DC wiring assembly connector
feeds through a hole built into inverter housing which
may prevent the connector from being removed without
handling.
5. See
12-8. Install the indicated fasteners:
Figure
•
TOP (A): QTY 2 - 7 mm nuts
•
BOTTOM (B): QTY 2 - Phillips head screws (No.
1)
