PWRcell Inverter Lid Replacement
Section 11

Overview

Figure 11-1.

Required Tools

Figure 11-2.

Safety

Electrocution. Initiate a system-wide shutdown and turn the
PWRcell DC Disconnect Switch OFF on all connected
batteries before performing service. Failure to do so will
result in death, serious injury, or equipment and property
damage.

Prepare Lid For Removal

Figure 11-3.
Diagnostic Repair Manual
DANGER

Section 11 PWRcell Inverter Lid Replacement

Replacement instructions for PWRcell Inverter lid.
013126
Required Tools:
Digital Multimeter (DMM)
1.
2.5 mm Hex Driver
2.
Ratchet (¼" drive) with 6" or longer extension, 7
3.
mm socket (see Note)
Zip Ties
4.
Side Cutter
5.
Needle Nose Pliers (optional, not shown)
6.
000000
013127
NOTE: 7 mm nut driver is also suitable for use.
(000600)
Disable all REBus devices and inverter.
1.
Secure
2.
will turn off).
Verify absence of voltage at AC and DC terminals
3.
using digital multimeter (DMM).
Place lid in open position.
4.
NOTE: If replacing the lid of an inverter while it is
mounted, be sure to lift lid completely and push into
inverter housing.
013128
AC power to inverter (the inverter screen
