Appendix E Battery

Battery Status LED

LED Color / Interval
Orange, solid
Orange, strobe (2s)
Green / Orange, alternating
Green, solid
Green, rapid blinking (0.5s)
Green, strobe (2s)
Red, rapid blinking (0.5s)
Red, strobe (8s)

Module Status LED

State
Standby
Ready
Discharging
Charging
Full Charge
Alarm
Error
Shutdown

Module SOC LED

State
80.1–100
60.1–80
40.1–60
20.1–40
10.1–20
0–10
Shutdown
134
Table E-2. Battery Status LED (On Battery Cabinet)

Table E-3. Module Status LED

Table E-4. Module SOC LED
LED Battery Status
Disabled

Waiting

Initializing
Charging

Discharging

Standby

Error

Sleeping

LED Description

Orange ON

Green ON

Green Blink (2Hz)

Green Blink (1Hz)
Green ON [3 sec]
Blink (1Hz) [1 sec]

Red ON

Red Blink (2Hz)

OFF
LED Description

Green ON

Green Blink (1Hz)

Orange ON

Orange Blink (1Hz)

Red ON

Red Blink (1Hz)

OFF
