Figure 12-9.
Figure 12-10.
Diagnostic Repair Manual
Section 12 DC Breaker Assembly Replacement
6. Connect DC wiring connector to Power Core.
NOTE: This connector is a plug with red and blue wires
coming from the DC breaker assembly to the Power
Core.
013138
7. Connect all REbus DC wiring connected to DC
assembly terminal block.
013112
