Goodrive880 Series Inverter Unit Hardware Manual
Model
GD880-51-0144-6-XX
GD880-51-0192-6-XX
GD880-51-0217-6-XX
GD880-51-0270-6-XX
GD880-51-0340-6-XX
GD880-51-0410-6-XX
GD880-51-0530-6-XX
GD880-51-0600-6-XX
GD880-51-0650-6-XX
GD880-51-0720-6-XX
Note: In the Connection terminal column, OT/185-12 indicates that the cable is connected to a OT-type
terminal, the matching cable diameter is 185mm

4.4.9 Electrical installation checklist

No.
Checked the input and output power wiring and ensured the wiring
1
positions and voltages were correct.
Ensured that the input and output power wiring was correct and
2
fastened.
Ensured that the input and output power cable carrying capacity
3
selection was correct.
Ensured that routing the input and output power cables that were
4
shielded complied with EMC regulations.
Checked the external auxiliary power wiring and ensured the wiring
5
positions and voltages are correct.
The date of manufacture can be known from the inverter unit
nameplate. If the interval to the first commissioning time or the
power module downtime is less than 2 years, precharge for the DC
6
bus capacitors is not needed; if the downtime is more than 2 years,
precharge for the DC bus capacitors is needed. For details about
precharge, see section
Routed the control power cables and power cables separately,
7
complying with EMC regulations.
202311 (V1.0)
Number of cables per
phase*cable diameter (mm
1*70
1*120
1*120
1*150
1*185
2*120
2*150
2*185
2*185
2*240
, and the screw hole size is M12.
2
Operation
7.2.1 Capacitor.
Electrical installation
Connection terminal
)
2
OT/70-8
OT/120-12
OT/120-12
OT/150-12
OT/185-12
OT/120-12
OT/150-12
OT/185-12
OT/185-12
OT/240-16
Compliant Completed
□
□
□
□
□
□
□
□
□
□
□
□
□
□
72
